DeVilbiss MPV-625 Service Bulletin

IMPORTANT: Read and follow this
service literature before you use the
respirator. The literature explains the
proper use, care and safety precau-
tions for your respirator. Keep for
future reference.
PERMISSIBLE
Supplied Air Respirator
Type C Continuous-Flow Class
LIMITATIONS
Approved for respirator protection against
atmospheres not immediately dangerous
to life or health. Not for use in atmospheres
containing less than 19.5 percent oxygen.
165013 (MPV-625)
AIR SUPPLIED RESPIRATOR
This respirator must not be worn
in any atmosphere immediately
dangerous to life or health.
Follow the manufacturer's in-
structions for providing a supply
of respirable air.
In making renewals or repairs,
parts identical with those fur-
nished by the manufacturer un-
der the pertinent approval shall
be maintained.
This respirator shall be selected,
fitted, used and maintained in ac-
cordance with The National Insti-
tute for Occupational Safety and
Health, Occupational Safety and
Health Administration and other
applicable regulations.
Severe or long term illness can
occur if the wrong type of respira-
tory protection is used. This res-
pirator will only provide protec-
tion against certain kinds and lim-
ited amounts of materials. Never
use this respirator for protection
against:
• Asbestos containing dusts and
mists
• Sandblasting
• Any material used in a closed or
poorly ventilated area
A respirator must be properly
prescribed and fitted to your
needs. OSHA and industry stan-
dards require:
• A qualified safety expert or in-
dustrial hygienist select the
correct respirator
• The correct respirator can only
be selected after finding out
the kinds and amounts of toxic
materials to which you will be
exposed.
8
DESCRIPTION
This air supplied respirator has a light-
weight, fully adjustable headband and
browguard. The detachable acetate visor
can be lifted up from the face when the
operator is not working in a hazardous
area. Two half turn tension knobs adjust
the visor movement. Two disposable visor
covers are provided.
The visor air feed tube is connected to a
filter/regulator attached to the waist belt.
The preset compressed air pressure regu-
lator maintains a constant flow of air to the
visor. See table on page 2 for approved
hose length and pressure ranges. Operat-
ing inlet pressure range is 45 psi (3.1 bar)
to 100 psi (6.8 bar) (see table on page 2).
Nominal flow rate to the visor is 6.0 CFM
(170 liters/min.). The disposable activated
carbon filter removes odor, particulates
and oil vapor and incorporates a color
change indicator. The filter should be
changed when odors are no longer effec-
tively removed or when oil vapor
activates the start of a color change from
white to red. Appropriate filters should be
fitted at the supply hose inlet to provide
Grade D breathing air, such as a DeVilbiss
breathable air panel.
A storage bag is supplied to keep the visor
safe and clean when not is use.
SERVICE BULLETIN
SB-25-050-A
Replaces SB-25-050
Risk of illness or death. Follow
all instructions. The activated
carbon filter does not remove
carbon monoxide or carbon di-
oxide.
This air supplied respirator is
designed to provide a high level
of protection in contaminated
atmospheres when worn and
used correctly. It is not for use
in atmospheres immediately
dangerous to life or health; and,
if accidentally disconnected or
removed, the wearer must be
able to safely reach a clean,
breathable air supply. The com-
pressed air supply to the respi-
rator must be of breathable
quality (Grade D) and conform
to 42 CFR 84.141 (a) (b) and
relevant national standards.
