  • Page 1 2010-12-10 5012603601-ECB1 Eaton Logic Controller PROFIBUS DP Distributed I/O Adapter Module INSTRUCTION SHEET [Applicable Distributed I/O Adapter Module] ELC-CAPBDP IL05004009E 002-1215820-02...
  • Page 2 I/O and module diagnostic information to PROFIBUS DP scanners. The power is supplied by a 24VDC power supply. The right side of ELC-CAPBDP is where the digital and analog I/O modules connect, and the RS-485 COM port is a standard Modbus master port that can be connected to Modbus slave stations.

  • Page 3: Function Specifications

    Invalid PROFIBUS addresses. NET LED will flash H’7E ~ H’FF red if the node address falls within this range. Example: If you need to set the node address of ELC-CAPBDP to 26 to “1” and x16 to “A”. 26 (decimal) = 1A (hex) = (decimal), set switch x16 1×16...

  • Page 4: Electrical Specifications

    Transmission cable Shielded twisted pair cable Electrical isolation 500VDC Communication Message type Cyclic data exchange Module name ELC-CAPBDP GSD document ETON09B9.GSD Product ID 09B9 Serial transmission 9.6kbps; 19.2kbps; 93.75kbps; 187.5kbps; 500kbps; 1.5Mbps; speed supported 3Mbps; 6Mbps; 12Mbps (bits per second)

  • Page 5: Installation

    2. Open the DIN rail clips on ELC-CAPBDP and I/O module. Insert ELC-CAPBDP and I/O module on the DIN rail. 3. Clip up the DIN rail clips on ELC-CAPBDP and I/O module to fix them on the DIN rail. LED Indication and Trouble shooting There are 5 LED indicators on ELC-CAPBDP: POWER, NET, RS-485, RUN and ALARM.

  • Page 6: Run Indicator

    ELC-CAPBDP and their order are consistent with the software configuration. RUN Indicator RUN LED displays whether ELC-CAPBDP is operating or in stop status. LED Status Indication Green light on ELC-CAPBDP is operating. ELC-CAPBDP is in stop status.
  • Page 7 LED Status Indication How to deal with The Modbus function has Green light not been enabled, or no flashes Modbus slave is configured Check if the RS-485 cable is All Modbus slaves are Red light on properly connected, and the off-line.
