Elvox 85CE/240 Manual

AUDIO DOOR-ENTRY SYSTEM FOR 3 RESIDENCES

INSTALLATION

To open phone
For panel Art. 8103 see encluded instructions.

OPERATION

Make calls by pushing door panel and talk hands-free after receiving reply.
Answer calls by lifting phone handset. Operate electric lock by pushing appropriate button.

POWER SUPPLIES FOR AUDIO DOOR-ENTRY SYSTEMS

SAFETY INSTRUCTIONS FOR INSTALLERS

- Carefully read the instructions on this leaflet, they give important information on the safety,use and maintenance of the installation.
- After removing the packing, check the integrity of the set. Packig components (plastic bags, expanded polystyrene etc.) are dangerous for
children.
- Installation must be carried out according to national safety regulations.
- A safety switch, installed before the power supply is recommended.
- Before connecting the set, ensure that the data on the label correspond to those of the network.
- Use this set only for the purposes designed, i.e. to supply power to electric door-opener systems. Any other use may be dangerous.
- The manufacturer is not responsible for damage caused by improper, erroneous or irrational use.
- Before cleaning or maintenance, disconnect the set.
- In case of failure or faulty operation, disconnect the set and do not open it. For repairs apply to the technical assistance centre authorized
by the manufacturer.
- Safety may be compromised if these instructions are disregarded.
- Do not obstruct openings of ventilation/heat exit slits.
- Installers must ensure that manuals with the above instructions are left on connected units after installations, for user's information.
- All items must only be used for the purposes designed.
- This leaflet must always be enclosed with the power supply.
S6I.85C.E24
ART. 85CE/240
Wall-mounting
1 Partially fasten upper screw
"A" to back box leaving it out
for 2 or 3 mm.
2 Hook interphone to upper
screw "A" in rear hole and pull it
downwards. 1 - 2
3 Complete mounting with lower
screw "B" in prepared hole.
ed. 00 05/2004
