- Page 1 Library Construction Chromium™ Controller Readiness Test FOR USE WITH Chromium™ Controller & Accessory Kit PN-120223...
- Page 2 Rev A Legal Notices © 2016 10x Genomics, Inc. All rights reserved. Duplication and/or reproduction of all or any portion of this document without the express written consent of 10x Genomics, Inc., is strictly forbidden. Nothing contained herein shall constitute any warranty, express or implied, as to the performance of any products described herein.
- Page 3 READINESS TEST Chromium™ Controller Accessory Kit Product Description Part Number Chromium™ Controller Accessory Kit 110204 Power Cord 34000X 10x™ Vortex Adapter 330002 10x™ Chip Holder 330019 10x™ Gasket (3 pack) 10x™ Vortex Clip 230002 10x™ Magnetic Separator 230003 Chromium Test Chip V1 230024 __________________________________________________________________________________________________ Chromium™...
- Page 4 READINESS TEST Turn on the Chromium™ Controller a) Ensure the Chromium Controller is positioned in accordance with recommendations in the Chromium Controller Specifications. b) Turn on the Chromium Controller using the power switch on the back of the unit. c) The Chromium Controller touchscreen will indicate initialization is in progress. d) When initialization is complete, press the button on the touchscreen of the Chromium Controller to eject the tray and remove the foam strip used for protection during shipping.
- Page 5 READINESS TEST Assemble a Test Chip and a 10x™ Chip Holder a) Align the notch on the upper left corner of the Test Chip with the notch on the 10x Chip Holder and insert the left-hand side of the Test Chip under the guide. b) Depress the right-hand side of the Test Chip until the spring-loaded clip engages the Test Chip.
- Page 6 READINESS TEST Attach a Gasket & Run the Chromium™ Controller 3.1. Attach a 10x™ Gasket a) The notched cut of the 10x Gasket should be at the top left corner. Hold the 10x Gasket by the tongue and hook it on the left-hand tabs of the 10x Chip Holder. Gently pull the 10x Gasket toward the right and hook it on the two right-hand tabs.
- Page 7 READINESS TEST b) Place the Test Chip assembled in 10x™ Chip Holder with a 10x™ Gasket installed on the tray (align the diagonal etchings on the top left corner of the 10x Chip Holder and the back left corner of the tray). c) Press the button to retract the tray.
