OPTIONAL CCTV
AC or DC Power: Connect one end of a two conductor stranded wire cable to TB 1 on the main
processor board (see Figure 3 or Figure 4) and the other end to the transformer provided with the
system. Then plug the transformer into a 120 VAC outlet.
NOTES:
1. Line Loss: Refer to the chart below for wire sizes and distances.
Distance AC Power Wire
Under 30 Feet
(Infin. L-tib/fans: 12 AWG)
30 - 75 Feet
75 - 150 Feet
150 - 250 Feet
250 - 500 Feet
G. POWER ON
MAIN PROCESSOR BOARD
The Infinity main processor board has a power monitor that indicates if proper voltage is available.
It has two red LEDs labeled HI and LO, one green LED labeled IN, and a MONITOR CLEAR
button, all located in the upper right corner of the main processor board (see Figure 3 or Figure 4).
If input power is not in the acceptable range, the HI or LO LEDs light and remain lit until the
MONITOR CLEAR button is pressed. This allows continuous power monitoring and captures any
transients.
Check voltage using the power monitor as follows:
1. Apply power to the board. The IN and LO LEDs will light.
2. Press the MONITOR CLEAR button located next to the LEDs.
o If the IN LED lights, proper voltage is being provided.
o If the LO LED lights, the voltage is too low. Check the power connections, wiring, and
transformer.
o If the HI LED lights, the voltage is too high. Check the power connections, wiring, and
transformer.
CCTV POWER SUPPLY BOARD
Power comes on when the transformer or power supply is plugged in. There are no power
indicators on the board.
Page 12 of 31
Power Wiring Distances
DC Power Wire
14 AWG
(Infin. L: 16 AWG)
10 AWG
(Infin. L: 12 AWG)
N/A
(Infin. L: 10 AWG)
N/A
N/A
Wire Size and Distance Recommendations
Doc 6001565
Camera Power Wiring Distances
AC Power Wire
18 AWG
14 AWG
12 AWG
10 AWG
(Infin. L: N/A)
N/A
DC Power Wire
18 18
18 18
14 18
14 16
14 16
