  • Page 1 Book 2 of 2 02/18...
  • Page 2 Contents: Section Page Low Level Louvre (Optional) Auto Louvre Installation (Optional)
  • Page 3 Low Level Louvre (Optional) Diagram 134 EV0975 EV0976 Inside Outside EV1059 EV1059 First assemble louvre, follow instruction on page 25. Insert one of the plain boards (EV1059) into the greenhouse on the left hand side below the mid 525mm x 100mm rail (diagram 135), secure this with a piece of panel D729...
  • Page 4 Auto Louvre Installation (Optional) Once the louvre is installed in the greenhouse you can replace the manual handle with the automatic unit. First of all remove the screw to release the arm (diagram 137). Next Remove the handle from the frame of the louvre (diagram 138).
  • Page 5 Auto Louvre Installation (Optional) With the louvre in the Diagram 141 closed position you need to mark the frame to drill the 2 holes. Offer the opener up to the frame with plates washers and slide the louvre arm into position. This now gives you the correct location for the opener...
  • Page 6 Notes...
  • Page 7 Notes...
  • Page 8 Alton Greenhouses, TGP Ltd, Blythe Park, Cresswell, Stoke-on-Trent, ST11 9RD Telephone: 01782 385 409 www.Altongreenhouses.co.uk sales@altongreenhouses.co.uk...
