- Page 1 INSTALLATION AND OPERATION MANUAL Heater kit for air to water heat pump system EKMBUHBA6V3...
- Page 2 OTES ≥ 2 ≥ 3 ≥ 5 ≥ 2 ≥ 3...
-
Page 3: Table Of Contents
ELECTRIC SHOCK, SHORT-CIRCUIT, LEAKS, FIRE OR OTHER DAMAGE TO THE EQUIPMENT. BE SURE ONLY Maintenance instructions: TO USE ACCESSORIES MADE BY DAIKIN WHICH ARE Instruction manual specified for a certain product or application, SPECIFICALLY DESIGNED FOR USE WITH THE which explains (if relevant) how to install, configure, operate and/or EQUIPMENT AND HAVE THEM INSTALLED BY A maintain the product or application. -
Page 4: General Safety Precautions
Be sure only to use accessories and optional equipment made by Daikin which are specially designed for use with Install the power wire at least 1 meter away from the products as of subject in this manual and have them installed by televisions or radios to prevent image interference or an installer. -
Page 5: Introduction
The total system (indoor and outdoor unit) is designed for 3.3. Model identification combination with a Daikin heater kit. In case another heater kit is being used in combination with the Daikin indoor unit, Daikin cannot guarantee neither good operation nor reliability of the system. For those reasons Power supply reference Daikin cannot give warranty of the system in such case. -
Page 6: Installation Of The Heater Kit
6.2. Dimensions and service space Unit of measurement: mm. Dimensions of the heater kit, see figure 2. Required service space, see figure 3. Installation and operation manual EKMBUHBA6V3 Heater kit for air to water heat pump system 4PW63549-1 – 08.2010... -
Page 7: Installing The Heater Kit
Be sure to install an earth leakage protector in accordance with relevant local laws and regulations. Failure to do so may cause electrical shock. EKMBUHBA6V3 Installation and operation manual Heater kit for air to water heat pump system 4PW63549-1 – 08.2010... - Page 8 For details on benefit kWh rate power supplies, refer to the outdoor unit installation manual. Installation and operation manual EKMBUHBA6V3 Heater kit for air to water heat pump system 4PW63549-1 – 08.2010...
-
Page 9: Start-Up And Configuration
Connect the indoor unit control signal to X2M 14, 15, 16. Connect the heater kit error feedback signal to X801M 2, 5 of the demand PCB. Only relevant wiring is shown. EKMBUHBA6V3 Installation and operation manual Heater kit for air to water heat pump system 4PW63549-1 – 08.2010... -
Page 10: Final Check And Test Run
field wiring have to be carried out at regular intervals. Before switching on the heater kit, read the following: This maintenance should be carried out by your local Daikin When the complete installation and all necessary settings have technician. -
Page 11: Troubleshooting
