Motorline MC6 Manual

Electronic Central MC6
Electronic central, for the automation of awnings, with option to
connect a tuned, operating via Radio commander and Wireless
Sensor (Sun/Wind/Rain).
T C
ECHNICAL HARACTERISTICS
- Supply:
- Exit motor:
- Exit Courtesy light:
- Working temperature:
- Radio receiver:
- Compatible radio commanders:
- Nr memorisable Radio commanders:
- Number memorisable Wireless Sensors:
- Dimensions casing:
- Container:
C T
ONNECTIONS ERMINAL
1:
Input connection Aarding.
2:
Input connection Aarding.
3:
Input line 230V~ ( Phase ).
4:
Input line 230V~ ( Neutral ).
5:
Exit Motor Up.
6:
Exit Motor General.
7:
Exit Motor Down.
8:
Exit Courtesy light 230V~ ( Neutral ).
9:
Exit Courtesy light 230V~ ( Phase ).
C T
ONNECTIONS ERMINAL
1:
Input mass antenna.
2:
Input pole antenna.
I O M
NITIAL PERATING ODE
The device is operational only in combination with one or more
radio commanders; upon switching on the central for the First
time, not a single radio commander code is stored in the
memory.
O A
PERATING WNING WITH SEVERAL
IT is possible to program several models of radio commanders:
by saving one code ( 1 key ) a cyclic operating Step - Step is
obtained (Up - Stop - Down), by saving two different codes ( 2
keys ) two different commandos are set up, the first for Up and
the second one for Down.
Operating Awning with radio commander 1 Key :
By operating the radio commander with one single key, the
functioning is executed as follows: the first impulse activates
the movement Up until timeout of the motor. The second im-
pulse activates the movement Down of the guiding systems; if
this impulse is made before the timeout of the motor, the cent-
ral will stop the guiding system, a next impulse has the motor
restart in the opposite direction.
Operating Awning with radio commander 2 Keys :
By operating the radio commander by means of 2 keys, the
functioning is executed as follows: the first key ( "Up" associ-
ated with the movement up ) operates Up until timeout motor
and the second key ( "Down" associated with the movement
Down ) operates the movement Down of the guiding system. If
a new command occurs during the movement Up, the central
will proceed with the movement Up, whereas if a commando
Down occurs, the central will stop the movement.
The same principle applies to the phase Down.
230V~ 50/60Hz 1000W max.
230V~ 500W Max.
230V~ 500W Max.
433,92
12-18 Bit - Rolling Code
130 x 70 x 40 mm.
ABS UL94V-0 ( IP40 )
B CN1
OX
B CN2
OX
R
ADIO COMMANDERS
GB
I
NVERSION OF THE ROTATION MOVEMENT
Whenever it occurs during the commando ( Up ) of the radio
commander the central associates the movement down in-
stead of up for the guiding system, one simply needs to repeat
the programming procedure by pressing the key ( Down ) in-
stead of ( Up ), or by inverting the cables Up and Down at the
motor.
C
-10÷55°C
ENTRALIZING A
MHz
Centralizing via radio by means of radio commanding
Centralizing one or more centrals via radio allows you moving
7 Max.
Up or Down simultaneously several Awnings.
1 Max.
Centralizing is done by the input of the same codes of a radio
commander ( keys ) at all of the centrals or a Group, located at
a distance of maximum 20 meters away from the commanding
point, so as to become a general or partial movement of sever-
al automations. In order to obtain a satisfying result of the cent-
ralization, the place where to install should be chosen with ut-
most care. The range not only depends on the technical char-
acteristics of the device, but varies also according to the radio
electrical conditions of the location.
F
UNCTIONING
It is also possible to programme an additional code ( 1 key ) for
radio commanding, to operate from a distance switching of a
lamp 230Vac connected to the terminal box ( 8 – 9 ) CN1 on
and off.
Important: each time the awning has been pulled up com-
pletely, the central will always switch off the courtesy light.
A
UTOMATIC
On the central, there is an automatic system Control Stop Up
provided for the use of roller blind awnings, each time there is
an excessive consumption of power at the main motor whilst
pulling up, due to a possible presence of an obstacle or by
reaching the fully up position, the central will interrupt the mo-
tor immediately.
P
ROGRAMME KEYS AND
Key SEL: select the type of function to be saved, the choice is
indicated by a blinking Led. By pressing several times on the
key, the function of your choice can be selected. The selection
remains active for 15 seconds, indicated by a blinking LED,
where after the central returns to the initial mode.
Key SET: executes programming the function, selected with
the key SEL.
Signalling Led's
Led on: option saved.
Led off: option not saved.
Led blinking: option selected.
---------------------- MAIN DMENU -----------------
Reference
1) CODE
2) CODE LAMP.
3) T. MOT.
1
G G
ROUP OR ENERAL
C R
OURTESY LIGHT BY ADIO COMMANDER
C S
ONTROL TOP FOR THE PHASE
S L
IGNALLING ED
Led Off
No code
No code Code Courtesy light Pgm.
Time motor 3 min.
U
P
'
S
Led On
Code Pgm.
Time Motor Pgm.
Rev. 1.3 19/03/09
