AT&T SMART WI-FI EXTENDER Simple Setup Manual page 2

Alternate Setup Method
Power Up
Push
Plug in
the power cord to the Power
your Wi-Fi Extender button on
and then plug it into a the back
power outlet close to of the Wi-Fi
your Wi-Fi Gateway. Extender.
Tip:
For a successful setup, make sure:
• Both the 2.4GHz and 5GHz radio bands are enabled. For help, use the
Smart Home Manager app or go to att.com/enhancedwifi
•
If you have dual SSIDs make sure they have the same name and password
Watch Press
for the light to and release
blink GREEN. the WPS
button on
your Wi-Fi
Gateway.
Tip:
Once the Wi-Fi Extender is successfully
paired and placed in the home, the
Extender provides two optional wired
Ethernet connections for devices, such
as game consoles, connected TVs, etc.
Pair
Press Wait
and release about 3 minutes
the WPS for the devices to
button on automatically pair.
your Wi-Fi The blinking light
Extender. will turn solid GREEN
when paired.
Note: If it does not light up solid
GREEN within 5 minutes, repeat
the pairing process or refer to the
Troubleshooting section.
Place
Unplug Move
your Wi-Fi your Wi-Fi Extender
Extender to its new location
from the between your Wi-Fi
power Gateway and the area
outlet. where you want a
stronger signal.
Tip: Max distance between nearest
Gateway or Extender is 40 ft, two walls,
or one floor away. Extenders work best
when placed up off the floor and on open
surfaces away from large obstructions
and things that can cause interference
(e.g., microwaves, wireless devices, etc.).
Plug
your Wi-Fi
Extender into
a power outlet
and wait a few
minutes for the
connection to
re-establish and
the light to turn
GREEN.
You're done!
