- Page 1 CF24118HR/CF34118HR PCI/104-Express CFast Drive Carrier User’s Manual BDM-610020139 Rev. B RTD Embedded Technologies, Inc. AS9100 and ISO 9001 Certified...
- Page 2 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com...
-
Page 3: Revision History
Failure to follow the instructions found in this manual may result in damage to the product described in this manual, or other components of the system. The procedure set forth in this manual shall only be performed by persons qualified to service electronic equipment. Contents and specifications within this manual are given without warranty, and are subject to change without notice. RTD Embedded Technologies, Inc. shall not be liable for errors or omissions in this manual, or for any loss, damage, or injury in connection with the use of this manual. -
Page 4: Table Of Contents
Connectors and Jumpers ................................10 3.3.1 CFast Connector 3.3.2 Bus Connectors CN1(Top) & CN2(Bottom): PCIe Connector CN16: PCI Connector (CF24118HR Only) Stacking Requirements ................................11 Steps for Installing ..................................11 IDAN Connections Module Handling Precautions ..............................12 Physical Characteristics ................................12 Connectors.................................... - Page 5 Figure 4: IDAN-CF24118HRS and IDAN-CF34118HR-1S Dimensions ......................... 12 Figure 5: IDAN-CF34118HR-2S Dimensions ................................. 13 Figure 6: Example IDAN System .................................... 14 Figure 7: CF24118HR/CF34118HR Block Diagram ............................... 15 Table of Tables Table 1: Ordering Options ......................................6 Table 2: Operating Conditions ....................................8 Table 3: Electrical Characteristics ....................................
-
Page 6: Introduction
The CF24118HR/CF34118HR CFast drive carrier modules provide a low cost removable drive solution for PC/104 systems. They utilize the SATA links on the PCIe/104 bus connector on select RTD PCIe/104 cpuModules. The onboard drive utilizes the first SATA link on the connector, while the other SATA link is lane-shifted up the stack to permit stacking multiple SATA drive carrier modules within one system. -
Page 7: Contact Information
If you are having problems with your system, please try the steps in the Troubleshooting section of this manual. For help with this product, or any other product made by RTD, you can contact RTD Embedded Technologies technical support via the... -
Page 8: Specifications
Each CFast card has its own individual operating conditions which will vary from one manufacturer to another. Installing third party CFast card on the CF24118HR/CF34118HR can affect the overall operating temperature of the system. Make sure to verify the operating conditions of third party 2.5”... -
Page 9: Board Connection
When removing it from the bag, hold the board at the edges, and do not touch the components or connectors. Handle the board in an antistatic environment, and use a grounded workbench for testing and handling of your hardware. Physical Characteristics A STEP model is available upon request; contact RTD Tech Support for more information. Weight: Approximately 0.16 lbs. (0.07 Kg) ... -
Page 10: Connectors And Jumpers
3.3.1 ONNECTOR The CF24118HR/CF34118HR includes a single CFast connector. Depending on the version of the board, it is either installed for “front load” or “side load” as shown in the Figure above. The CFast connector supports both CFast and CFast 2.0 cards. -
Page 11: Stacking Requirements
Stacking Requirements It is common that the host cpuModule of the system requires that high speed peripherals like the CF24118HR/CF34118HR are installed within six boards of the CPU. With today’s wide array of high speed modules (SATA, USB 3.0, PCI Express, etc.), PCI devices connected to PCI/104- Express cpuModules are forced to be stacked farther away from the cpuModule. -
Page 12: Idan Connections
Weight: Approximately 0.21 Kg (0.46 lbs.) Dimensions: 151.972 mm L x 129.978 mm W x 16.993 mm H (5.983 in L x 5.117 in W x 0.669 in H) Figure 4: IDAN-CF24118HRS and IDAN-CF34118HR-1S Dimensions CF24118HR/CF34118HR | www.rtd.com User’s Manual RTD Embedded Technologies, Inc. -
Page 13: Connectors
4.3.1 ONNECTOR The CF24118HR/CF34118HR includes a single CFast connector. Depending on the version of the board, it is either installed for “front load” or “side load” as shown in the Figure above. The CFast connector supports both CFast and CFast 2.0 cards. -
Page 14: Steps For Installing
10. Attach any necessary cables to the IDAN system. 11. Re-connect the power cord and apply power to the stack. 12. Boot the system and verify that all of the hardware is working properly. Figure 6: Example IDAN System CF24118HR/CF34118HR | www.rtd.com User’s Manual RTD Embedded Technologies, Inc. -
Page 15: Functional Description
The CFast connector allows you to install a readily-available CFast or CFast 2.0 card to provide high-speed, removable storage to your system. Multiple CF24118HR/CF34118HR board may be used in a system, and they may be used with other SATA drive carriers. The total number is limited by the number of SATA links provided by the CPU. -
Page 16: Power
Power A power supply is provided to convert 5V from the PCIe/104 bus to 3.3V for the CFast card. CF24118HR/CF34118HR | www.rtd.com User’s Manual RTD Embedded Technologies, Inc. -
Page 17: Troubleshooting
If problems persist, or you have questions about configuring this product, contact RTD Embedded Technologies via the following methods: Phone: +1-814-234-8087 E-Mail: techsupport@rtd.com Be sure to check the RTD web site (http://www.rtd.com) frequently for product updates, including newer versions of the board manual and application software. CF24118HR/CF34118HR | www.rtd.com User’s Manual... -
Page 18: Additional Information
A copy of the latest PC/104 specifications can be found on the webpage for the PC/104 Embedded Consortium: www.pc104.org PCI and PCI Express Specification A copy of the latest PCI and PCI Express specifications can be found on the webpage for the PCI Special Interest Group: www.pcisig.com CF24118HR/CF34118HR | www.rtd.com User’s Manual RTD Embedded Technologies, Inc. -
Page 19: Limited Warranty
RTD Embedded Technologies, Inc. warrants the hardware and software products it manufactures and produces to be free from defects in materials and workmanship for one year following the date of shipment from RTD Embedded Technologies, Inc. This warranty is limited to the original purchaser of product and is not transferable. - Page 20 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com Copyright 2016 by RTD Embedded Technologies, Inc. All rights reserved.
