ERES35105HR
PCI Express Dual Synchro/Resolver/LVDT Interface
User's Manual
BDM-610020152 Rev. A
RTD Embedded Technologies, Inc.
AS9100 and ISO 9001 Certified

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERES35105HR and is the answer not in the manual?

Questions and answers

Related Manuals for rtd ERES35105HR

Summary of Contents for rtd ERES35105HR

  • Page 1 ERES35105HR PCI Express Dual Synchro/Resolver/LVDT Interface User’s Manual BDM-610020152 Rev. A RTD Embedded Technologies, Inc. AS9100 and ISO 9001 Certified...
  • Page 2 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com...
  • Page 3 Failure to follow the instructions found in this manual may result in damage to the product described in this manual, or other components of the system. The procedure set forth in this manual shall only be performed by persons qualified to service electronic equipment. Contents and specifications within this manual are given without warranty, and are subject to change without notice. RTD Embedded Technologies, Inc. shall not be liable for errors or omissions in this manual, or for any loss, damage, or injury in connection with the use of this manual.

  • Page 4: Table Of Contents

    Front End ....................................20 On-Board Excitation .................................. 20 EPLD ......................................20 Board Configuration Sensor Input Connections ................................ 21 6.1.1 Resolver Input Input Connections Jumper Configuration 6.1.2 Synchro Input Input Connections Jumper Configuration | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.
  • Page 5 Excitation Frequency (0x04) Output Data Input Data 7.5.5 Excitation Amplitude (0x05) Output Data Input Data Troubleshooting Additional Information PC/104 Specifications ................................37 PCI and PCI Express Specification ............................37 10 Limited Warranty | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.
  • Page 6 Table 3: Electrical Characteristics .................................... 9 Table 4: J1 Input / Output Pin Assignments ................................12 Table 5: IDAN-ERES35105HR-xS Panel Connectors and Mating Connectors ..................... 16 Table 6: IDAN Input / Output Pin Assignments ..............................17 Table 7: Bandwidth Filters ...................................... 20 Table 8: Resolver Input Connections..................................

  • Page 7: Introduction

    The Intelligent Data Acquisition Node (IDAN™) building block can be used in just about any combination with other IDAN building blocks to create a simple but rugged 104™ stack. This module can also be incorporated in a custom-built RTD HiDAN™ or HiDANplus ®...

  • Page 8: Contact Information

    If you are having problems with your system, please try the steps in the Troubleshooting section of this manual on page 28. For help with this product, or any other product made by RTD, you can contact RTD Embedded Technologies technical support via the...

  • Page 9: Specifications

    2V Configuration Voltage (Operating) 11.8V Configuration 10.0 13.4 Voltage (Operating) 90V Configuration 76.5 103.5 Voltage (Absolute Max) 2V Configuration Voltage (Absolute Max) 11.8V Configuration Voltage (Absolute Max) 90V Configuration -225 +225 | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 10: Board Connection

    When removing it from the bag, hold the board at the edges, and do not touch the components or connectors. Handle the board in an antistatic environment, and use a grounded workbench for testing and handling of your hardware. | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 11: Physical Characteristics

    Physical Characteristics STEP model is available upon request; contact RTD Tech Support for more information. • Weight: Approximately 0.16 lbs. (72 g) • Dimensions: 90.17 mm L x 95.89 mm W (3.550 in L x 3.775 in W) • Stand-off Height: 0.600 inches (15.240 mm) Figure 1: Board Dimensions | www.rtd.com...

  • Page 12: Connectors And Jumpers

    Table 4: J1 Input / Output Pin Assignments Pin Name Pin Name CH0_EXCITATION CH0_SINE+ CH0_COSINE+ CH0_REF_IN- CH0_REF_IN+ CH1_EXCITATION CH1_SINE+ CH1_COSINE+ CH1_REF_IN- CH1_REF_IN+ CH1_VELOCITY CH0_VELOCITY CH0_S3 CH0_S1 CH0_S4 CH0_S2_SYNCHRO CH0_S2_RESOLVER CH1_REF_IN+ CH0_REF_IN+ CH1_S3 CH1_S1 CH1_S4 CH1_S2_SYNCHRO CH1_S2_RESOLVER | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 13: Bus Connectors

    The jumper settings are described in Section 6 starting on page 21. JP116 JP115 JP114 JP111 JP117 JP112 JP119 JP121 JP110 JP118 JP120 JP113 JP216 JP215 JP214 JP211 JP217 JP212 JP219 JP221 JP210 JP218 JP220 JP213 Figure 3: Jumper Locations | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 14: Steps For Installing

    10. Attach any necessary cables to the PC/104 stack. 11. Re-connect the power cord and apply power to the stack. 12. Boot the system and verify that all of the hardware is working properly. Figure 4: Example 104™Stack | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 15: Idan Connections

    Weight: Approximately 0.21 Kg (0.46 lbs.) • Dimensions: 152.0 mm L x 130.0 mm W x 17.0 mm H (5.98 in L x 5.12 in W x 0.67 in H) Figure 5: IDAN Dimensions | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 16: Connector Locations

    The diagram below shows the connector locations for the headers of the ERES35105 as they are brought out on the front panels of the IDAN- ERES35105HR-xS. For a full description of each connector on the ERES35105, refer to the External I/O Connectors section of this manual on page 3.3.112.

  • Page 17: External I/O Connectors

    The PCIe connector is the connection to the system CPU. The position and pin assignments are compliant with the PCI/104-Express Specification. (See PC/104 Specifications on page 37) The ERES35105 is a “Universal” board, and can connect to either a Type 1 or Type 2 PCIe/104 connector. | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 18: Steps For Installing

    10. Attach any necessary cables to the IDAN system. 11. Re-connect the power cord and apply power to the stack. 12. Boot the system and verify that all of the hardware is working properly. Figure 7: Example IDAN System | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 19: Functional Description

    The CT uses a combination of amplifiers, switches, logic and capacitors in precision ratios to perform the calculation. | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 20: Bandwidth Filters

    You may separately purchase resistor networks for the standard voltages from RTD. They may be easily configured channel-by-channel by inserting the correct resistor network into the onboard sockets. The resistor networks are used as follows: DDC-49530 are used with 11.8V inputs...

  • Page 21: Board Configuration

    See Figure 3 on page 13 for jumper locations. Table 9: Resolver Jumper Settings Channel 0 Channel 1 Jumper Jumper Position JP110 JP210 JP111 JP211 JP112 JP212 JP113 JP213 JP114 JP214 JP115 JP215 JP116 JP216 JP117 JP217 JP118 JP218 | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 22: Synchro Input

    See Figure 3 on page 13 for jumper locations. Table 11: Synchro Jumper Settings Channel 0 Channel 1 Jumper Jumper Position JP110 JP210 JP111 JP211 JP112 JP212 JP113 JP213 JP114 JP214 JP115 JP215 JP116 JP216 JP117 JP217 JP118 JP218 | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 23: 2-Wire Lvdt Input

    An LVDT does not use the reference input. It does require an excitation source that may be supplied on-board or from an external source. An LVDT generally requires some scaling to make full use of the dynamic range of the ERES35105. In order to facilitate this, the signal path allows the addition of gain. Contact RTD Tech Support for more details. FEEDBACK HI...

  • Page 24: 3-Wire Lvdt Input

    An LVDT does not use the reference input. It does require an excitation source that may be supplied on-board or from an external source. An LVDT generally requires some scaling to make full use of the dynamic range of the ERES35105. In order to facilitate this, the signal path allows the addition of gain. Contact RTD Tech Support for more details. (CHx_S1)

  • Page 25: Direct Input

    Channel 0 Channel 1 Jumper Jumper Position JP110 JP210 JP111 JP211 JP112 JP212 JP113 JP213 JP114 JP214 JP115 JP215 Open (jumper removed) JP116 JP216 JP117 JP217 Open (jumper removed) JP118 JP218 | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 26: Reference Input

    Jumper Configuration See Figure 3 on page 13 for jumper locations. Table 19: Internal Reference Jumper Settings Channel 0 Channel 1 Jumper Jumper Position JP119 JP219 JP120 JP220 JP121 JP221 JP122 JP222 | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 27: Differential Externally Generated Reference

    Table 23: Single-Ended External Reference Jumper Settings Channel 0 Channel 1 Jumper Jumper Position JP119 JP219 JP120 JP220 2-3 (2V 1-2 (11.8V Open (90V JP121 JP221 2-3 (2V 1-2 (11.8V Open (90V JP122 JP222 | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 28: Register Address Space

    This register is used to select between the Index and Data register. All undefined bits may be written with a 0. B2: DATA 0 = Accessing Index register 1 = Accessing Data register B1:WR_STRB Writes take effect on 0 to 1 transition | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 29: Index_Data (Read/Write)

    Restore GPIOCD_CTRL bit-wise or’ed with the Read Value (to make sure the SELECT pins are always output) Restore SELECT and INDEX_DATA with the WR_STRB bit cleared (to make sure a write isn’t duplicated) | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 30: Writing To A Board Register

    Restore SELECT and INDEX_DATA with the WR_STRB bit cleared (to make sure a write isn’t duplicated) NOTE: If multi-thread safe operation is not required, steps 1, 2, 5, and 6 can be eliminated. | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 31: Reading Shift Register Status

    This register selects which of the various on-board devices the shift register is accessing. Possible options are below. All other values are reserved. 0x00: Channel 0 Mode 0x01: Channel 0 Velocity Trim 0x02: Channel 1 Mode 0x03: Channel 1 Velocity Trim 0x04: Excitation Frequency 0x05: Excitation Amplitude | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 32: Sr_Data_Out (Read/Write)

    If CHx_POSITION is interpreted as an unsigned integer, the range for θ is 0° to 359.99°. If CHx_POSITION is interpreted as a signed integer, the range for θ is -180° to +179.99°. | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 33: Shift Register

    Reads from the wiper that is attached to the Resolver to Digital Converter D1 pin. Input Data The lower 8 bits of the SR_DATA_IN register contain the wiper position after a read command is issued | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 34: Modes

    Reads the current wiper position. 0x8100 Read Offset Trim Wiper Reads the current wiper position. Input Data The lower 8 bits of the SR_DATA_IN register contain the wiper position after a read command is issued | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 35: Excitation Frequency (0X04)

    Value Amplitude (V Amplitude (V 0x00 0x3B 0x95 14.1 0xD1 19.8 Input Data The lower 8 bits of the SR_DATA_IN register contain the wiper position after a read command is issued. | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 36: Troubleshooting

    If problems persist, or you have questions about configuring this product, contact RTD Embedded Technologies via the following methods: Phone: +1-814-234-8087 E-Mail: techsupport@rtd.com Be sure to check the RTD web site (http://www.rtd.com) frequently for product updates, including newer versions of the board manual and application software. | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 37: Additional Information

    A copy of the latest PC/104 specifications can be found on the webpage for the PC/104 Embedded Consortium: www.pc104.org PCI and PCI Express Specification A copy of the latest PCI and PCI Express specifications can be found on the webpage for the PCI Special Interest Group: www.pcisig.com | www.rtd.com ERES35105 User’s Manual RTD Embedded Technologies, Inc.

  • Page 38: 10 Limited Warranty

    During the one year warranty period, RTD Embedded Technologies will repair or replace, at its option, any defective products or parts at no additional charge, provided that the product is returned, shipping prepaid, to RTD Embedded Technologies. All replaced parts and products become the property of RTD Embedded Technologies.
  • Page 39 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com Copyright 2019 by RTD Embedded Technologies, Inc. All rights reserved.
