VIGO INDUSTRIES INSTALLATION GUIDE FOR SHOWER DOOR (MODEL VG06080)
!
SAFETY PRECAUTIONS
This Installation Guide uses the following symbols to indicate important information.
Always observe the instructions indicated by these symbols.
!
WARNING
Instructions that, if ignored, could result in death or serious personal injury caused by
incorrect handling or installation of the product. These instructions must be observed for
safe installation.
IMPORTANT
Maintenance and other important non-personal injury and non-material damage instructions
or statements that should be observed.
It is highly advised to dry fit the unit prior to any installation.
1
Advertisement
Related Manuals for VIGO FERRARA VG06080
Summary of Contents for VIGO FERRARA VG06080
- Page 1 VIGO INDUSTRIES INSTALLATION GUIDE FOR SHOWER DOOR (MODEL VG06080) SAFETY PRECAUTIONS This Installation Guide uses the following symbols to indicate important information. Always observe the instructions indicated by these symbols. WARNING Instructions that, if ignored, could result in death or serious personal injury caused by incorrect handling or installation of the product.
- Page 2 MODEL VG06080 FERRARA INSTALLATION INSTRUCTIONS FOR SHOWER DOOR PLEASE READ INSTRUCTIONS BEFORE PROCEEDING 11. Handle (1pc) Parts List 1. Hex screw 1 5/8" (4pc) 12. Threshold end clip (1pc) 2. Plastic anchors white (4pc) 13. Threshold (1pc) 3. Structural rail (1pc) 14.
- Page 3 36" x 74" 71 1/2" - 72 1/2" 74" 30 1/2" - 31 1/2" VG06080XXCL7274 40" x 73 1/2" A, B & C DIMENSIONS WERE MEASURED AFTER SHOWER ENCLOSURE WAS COMPLETELY INSTALLED Product lines may change, contact your Vigo representative. MODEL VG06080...
-
Page 4: Before Starting
Compare items on your invoice with what you have received. Carefully review the Parts List on page 2. If any items are missing, please call Vigo Industries at 1-866-591-7792. Please check our website at www.vigoindustries.com for additional information or instructional videos. - Page 5 IMPORTANT Verify that the overall size of the shower door opening is appropriate for the shower enclosure. Due to individual site variations, exact guidelines for every situation cannot be supplied. The recommended framing and dimensional requirements are shown for a typical application and may vary depending on the site requirements.
-
Page 6: Installation Steps
INSTALLATION STEPS *NOTE: Prior to any installation, mark lines on the floor and wall for proper DOOR PANEL (#9) INSIDE OF dry fit. Proper planning is imperative THE SHOWER for proper installation. The measurement of 71" should just be used as a guide. Your actual dimensions may vary. - Page 7 Attach seal strip (#5) to the fixed panel (#6) on the side that sits against the wall. Start at the bottom and work your way up, using the heel of your hand to firmly press the seal WALL SIDE strip onto the glass. The fixed panel holder (#21) is already installed on the structural rail (#3).
- Page 8 Position the fixed panel (#6) and the structural rail assembly (#3) into the shower opening. Position the door DOOR PANEL (#9) INSIDE OF bottom guide (#14) on the floor making THE SHOWER sure the edge of the fixed panel (#6) ends at the middle portion of the door bottom guide.
- Page 9 INSTALLING THE FIXED PANEL Remove the fixed panel (#6) and structural rail (#3) assembly from the shower door opening. Find the center of the marked circumference on the wall. Mark holes on the wall for the mounting screws. Drill holes and place plastic anchors (#2) inside them.
- Page 10 Remove the wall mount bracket assembly (#4) from the structural rail assembly (#3). Unthread the plate from the bracket PLATE assembly body. There is a 13mm adjustment 13mm SCREW built into the plates for minor modifications. BRACKET BODY BRACKET BODY PLATE Place plates to the wall over the plastic anchors.
- Page 11 Place wall mount bracket body back on the BRACKET rail. BODY BRACKET BODY Place the fixed panel with the structural rail PLATE assembly in its proper position and thread BRACKET the bracket body to the plates. BODY Tighten the hex screws on the brackets with the hex key (supplied).
- Page 12 Mark holes on the wall for the mounting screws for the glass supports (#18). Remove the fixed panel and drill holes into the wall. Insert plastic anchors (# 2) into the holes. Not necessary if installing into studs. Studs are the preferred means of installation, anchors can pull out of the wall causing property damage and bodily There is a 15mm...
- Page 13 Check that the structural rail is level. I f it is not level and the rail is not at the correct height, then remove the rail and use the built-in adjustments in the plates to modify as needed. INSTALLING THE TOWEL BAR Assemble the towel bar (#17) to the fixed panel (#6).
-
Page 14: Installing The Door
INSTALLING THE DOOR Remove the rollers (#8) from the box, SMALL HEX note that these are fully assembled. HOLE Carefully unthread the cap with a small ROLLER (8) head allen key. You will see a big hex screw, this is referred to as the roller height adjustment screw. - Page 15 Place the two top rollers and the door panel (#5) assembly onto the structural rail (#10). Note that the rollers have a built-in mechanism that will provide adjustment for walls that are not 100% perpendicular to the floor. If necessary, loosen the adjustment screw and rotate the individual roller.
- Page 16 Screw the roller guides (#10) to the door panel as illustrated in step C2. INSTALLING THE THRESHOLD Place the threshold (#13) into the door bottom guide (#14). Note that the end of the threshold should go halfway inside the door bottom guide.
- Page 17 Remove the threshold. Apply silicone to the underside of the threshold. Place the threshold back into its shower base location. Align the threshold and press firmly down. Apply silicone to the threshold around the inside and outside of the shower base. Remove any excess silicone from the threshold.
-
Page 18: Installing The Handle
Replace the threshold end clip (#12) and screw to the floor with a 1 1/8" phillips screw (#15). Then cover the screw with the 8mm plastic cap (#19). INSTALLING THE HANDLE GLASS Assemble the outside handle to the position SUPPORT on the door (#9) as illustrated. - Page 19 INSTALLING THE WATER SEAL STRIP Attach the F-shaped side seal strip (#7) to the fixed panel. Start at the bottom and work your way up, using the heel of your hand to firmly press the seal strip onto the glass. This end must look inside the shower...
- Page 20 Trim the flange on the seal strip so that there is enough clearance for the door to roll without the seal strip hitting against the rollers. Trim the flange of the seal strip (#7) to below this point Flange APPLYING THE SILICONE Apply clear silicone caulking along the wall and floor of the fixed panel interior.
- Page 21 In order to keep your shower enclosure in optimal working condition, Vigo recommends regularly inspecting your enclosure and tightening any hardware that may have loosened during use. This simple step will insure optimal results from your Vigo shower enclosure for many years to come.
- Page 22 IMPORTANT ROLLER ADJUSTMENTS TO ACCOMMODATE OUT OF SQUARE OPENINGS NOTE: There is a 3mm adjustment in the roller to use in the case that your walls are not plumb and level. Using an allen key, you will be able to adjust the roller to accommodate for the variance.
- Page 23 The small hex hole on the roller The small hex will be facing up hole on the roller on this roller. will be facing up, on this roller. ROLLER (3) ROLLER (3) WALL WALL STRAIGHT WALLS ROLLER "A" ROLLER "B" WALL DIRECTION SMALL HEX HOLE SMALL HEX HOLE...
- Page 24 VIGO or an authorized VIGO dealer. VIGO warrants the seal strip components of the Product to be free from defects in workmanship and materials under normal use and service for a period of one (1) year from the initial date of purchase by the owner or end-user, contractor, or builder, from VIGO or an authorized VIGO dealer.
