SINK SPECIFICATIONS
Glass Vessel Sink
Model VG07042
MODEL VG07042
FEATURES
PACKING LIST
For warranty purposes contact our toll free number:
TOLL FREE: (866) 591 - 7792
E-Mail: techmail@vigoindustries.com
www.vigoindustries.com
DIMENSIONS
MODEL #
SINK
DIAMETER
VG07042
16 1/2"
SINK
HOLE
HEIGHT
DIAMETER
6 "
1 3/4"
16 1/2"
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VIGO VG07042
Summary of Contents for VIGO VG07042
- Page 1 SINK SPECIFICATIONS Glass Vessel Sink Model VG07042 MODEL VG07042 FEATURES PACKING LIST DIMENSIONS MODEL # SINK SINK HOLE DIAMETER HEIGHT DIAMETER VG07042 16 1/2" 6 " 1 3/4" For warranty purposes contact our toll free number: TOLL FREE: (866) 591 - 7792 16 1/2"...
-
Page 2: Front View
16 1/2" FRONT VIEW TOP VIEW NOTE: GLASS THICKNESS 1/2" GLASS DIAMETER AND HEIGHT MAY VARY UP TO 1/ 2" MODEL VG07042 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"... - Page 3 Note: The Plumber's putty or Caulk stand comes as a free accessory with a Vigo style pop up. If you decide not to Caulking Gun purchase the Vigo style pop up, the stand can be purchased through the Vigo Tape Measure technical support department.
- Page 4 Subject to the Warranty Service provision below, any product reported to the authorized dealer or to VIGO as being defective within the warranty period will be repaired or replaced (with a product of equal value) at the option of VIGO. This warranty extends to the original owner or end-user and is not transferable to a subsequent owner.
- Page 5 FAUCET SPECIFICATIONS Vessel Bathroom Faucet Model VG03002 MODEL VG03002 FEATURES Solid brass construction Single hole construction Ceramic disk cartridge Single lever faucet Standard plumbing connections Finish resist corrosion and tarnishing PACKING LIST Faucet Assembly Gasket Lock nut Two Metal braided hoses Set screws Plate DIMENSIONS...
- Page 6 6 1/8" VG03002 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"...
-
Page 7: Maintenance
FOR LEAKS, ESPECIALLY AT HOOK-UPS TO parts are included and visually inspect the unit for any defects. SUPPLY LINES. TIGHTENING NUTS SLIGHTLY WILL If you have any questions please contact the Vigo Technical Support STOP ANY MINOR LEAKS. Department before proceeding with installation. -
Page 8: Troubleshooting
PARTS LIST - For any parts needed but not shown, please contact Vigo Technical Support SUPPLY DATE INDICATOR (INTERNAL USE ONLY) PART... - Page 9 VIGO or an authorized VIGO dealer, through the lifetime of the original owner or end-user. VIGO warrants the cartridge component of the Product to be free from defects in workmanship and materials under normal use and service for a period of five (5) years from the initial date of purchase by the owner, contractor, or builder, from VIGO or an authorized VIGO dealer.
- Page 10 DRAIN SPECIFICATIONS Bathroom Sink Pop-up Drain VG07000 Model FEATURES Solid brass construction Without an overflow Decorative ring Push down style pop-up Round pop-up cover NOMINAL DIMENSIONS HEIGHT INSTALLED WIDTH INSTALLED DEPTH 1" 2 3/4" 9" 2 3/4" 2 1/2" 1 1/4"...
- Page 11 VIGO warrants the Product to be free from defects in workmanship and materials under normal use and service for a period of one (1) year from the initial date of purchase by the owner or end-user, contractor, or builder, from VIGO or an authorized VIGO dealer.
