VIGO INDUSTRIES INSTALLATION GUIDE FOR
SHOWER ENCLOSURE (MODEL VG06071)
!
SAFETY PRECAUTIONS
This Installation Guide uses the following symbols to indicate important information.
Always observe the instructions indicated by these symbols.
!
WARNING
Instructions that, if ignored, could result in death or serious personal injury caused by
incorrect handling or installation of the product. These instructions must be observed for
safe installation.
IMPORTANT
Maintenance and other important non-personal injury and non-material damage instructions
or statements that should be observed.
It is highly advised to dry fit the unit prior to any installation.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VG06071 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VIGO VG06071

  • Page 1 VIGO INDUSTRIES INSTALLATION GUIDE FOR SHOWER ENCLOSURE (MODEL VG06071) SAFETY PRECAUTIONS This Installation Guide uses the following symbols to indicate important information. Always observe the instructions indicated by these symbols. WARNING Instructions that, if ignored, could result in death or serious personal injury caused by incorrect handling or installation of the product.
  • Page 2 4. Door bottom seal strip (1pc + 1pc is extra) 5. Handle assembly (1pc) 6. Hex screw 1 5/8" (10pc) 7. Plastic anchor (white) (10pc) 8. Clear PVC shims (1 pack) GLASS THICKNESS:8mm NOTE: INSTALLATION MUST BE DONE BY A QUALIFIED, LICENSED PLUMBER. MODEL VG06071...
  • Page 3 6. HEX SCREW 1 5/8" 7. PLASTIC ANCHOR 98039 98038 MISC #3- DOOR (97027CL) MODEL DIMENSION "A"** HEIGHT** VG06071 34" 58" 34" X 57 3/8" - WITH HARDWARE - EXTERIOR SIZES A DIMENSION WAS MEASURED AFTER SHOWER DOOR WAS COMPLETELY INSTALLED MODEL VG06071...
  • Page 4: Before Starting

    GLASS BREAKAGE AND, CONSEQUENTLY, CAUSE PERSONAL INJURY OR DEATH. BEFORE STARTING Compare items on your invoice with what you have received. Carefully review the Packing List on page 2. If any items are missing contact Vigo Industries at 1-866-591-7792. REQUIRED TOOLS Square and/or Phillips #1 and #2 screwdriver Flat head screwdriver Electric drill plus 1/4"...
  • Page 5 NOTE: If the seal strips are not flat, use a hair dryer to apply minimal heat and press the seal strip back into position. MAKE SURE THE FLANGE IS ON THE INSIDE OF THE SHOWER HINGE OUTLINE FIG.1 MODEL VG06071...
  • Page 6: Hinge Installation

    HEX SCREWS VIEW FROM INSIDE THE SHOWER THIN GASKETS PLATE HEX SCREWS FIG.2 HINGE (2) HINGE (2) DOOR GLASS PANEL (1) INSIDE VIEW CLEAR PVC SHIM (8) DOOR GLASS CLEAR PANEL (1) PVC SHIM (8) INSIDE VIEW FIG.3 MODEL VG06071...
  • Page 7: Installing The Door

    Remove the door and drill holes into the wall where marked. Place plastic anchors (#7) inside the holes. Replace the door (#1) back on the shim and place it in the open position.Screw the door securely to the wall with 1 5/8" screws (#6). [SEE FIG.4A] 5/8" SHIM BATHTUB (NOT PROVIDED) FIG.4 MODEL VG06071...
  • Page 8 OPEN POSITION 5/8" SHIM BATHTUB (NOT PROVIDED) FIG.4A MODEL VG06071...
  • Page 9: Installing The Handle

    NOTE: If the seal strips are not flat, use a hair dryer to apply minimal heat and press the seal strip back into position. FIG.6 IMPORTANT WAIT 24 HOURS BEFORE USING SHOWER DO NOT ALLOW WATER TO DIRECTLY HIT DOOR SEAL STRIPS MODEL VG06071...
  • Page 10 LEFT CORNER INSTALLATION RIGHT CORNER INSTALLATION MODEL VG06071...
  • Page 11 Do NOT use abrasive cleaners, scrapers, metal brushes, or any items/products that would scratch and/or dull surface. Do NOT allow surface to come into contact with acetone (nail polish remover), dry cleaning solution, lacquer thinner, gasoline, or any other similar product. MODEL VG06071...
