Page 1: Instruction Manual
TECHNOLOGIE FÜR DEN HAUSHALT TECHNOLOGY FOR DOMESTIC USE 06.06.2019 Instruction manual & H UILT BIC4 GKU IX 4 BIC4 2KB GKU IX 4 www.pkm-online.de... -
Page 2: Table Of Contents
1.1 Signal words ........................ 54 1.2 Safety instructions ...................... 54 2. Installation ( ) ..........59 BIC4 GKU IX 4 BIC4 2KB GKU IX 4 2.1 Unpacking and positioning ..................60 2.2 Pre-installation requirements ................... 60 2.3 Selection of installation equipment / Dimensions ..........61 2.4 Installation of the hob .................... - Page 3 7.6 Removing of the inner glass panel................89 8. Trouble shooting ......................89 9. Technical data ........................92 ......................92 BIC4 GKU IX 4 ..................... 93 BIC4 2KB GKU IX 4 10. Waste management ......................94 11. Guarantee conditions ....................95 Do not dispose of this appliance together with your domestic waste.
-
Page 4: Safety Information
EU - D ECLARATION OF ONFORMITY The products, which are described in this instruction manual, comply with the harmonized regulations. The relevant documents can be requested from the final retailer by the competent authorities. 1. Safety information READ THE SAFETY INFORMATION AND SAFETY INSTRUCTIONS CAREFULLY BEFORE YOU OPERATE THE APPLIANCE FOR THE FIRST TIME. -
Page 5: Signal Words
MAKE SURE THAT THIS MANUAL IS AVAILABLE TO ANYONE USING THE APPLIANCE AND MAKE SURE THAT IT HAS BEEN READ AND UNDERSTOOD PRIOR TO USING THE APPLIANCE. 1.1 Signal words indicates a hazardous WARNING! indicates a hazardous DANGER! situation which, if ignored, will result in situation which, if ignored, could result death or serious injury. - Page 6 WARNING! 1. Operate the appliance with 220 ~ 240 V AC / 50 Hz only. 2. Disconnect the appliance from the mains before you clean or maintain it. 3. The technical data of your energy supply must meet the data on the rating label.
- Page 7 17. Cooker-hoods should be installed according to their manufacturers' instructions. 18. The safety distance between the hob and a wall cupboard above should be at least 760 mm. 19. The safety distance between the hob and an extractor hood above should be at least 760 mm.
- Page 8 CAUTION! 1. The appliance becomes hot while operating. Do not touch the hot components inside the oven. 2. Do not put any cookware or backing trays directly on the base inside the oven. Do not cover the base inside the oven with aluminium foil. 3.
- Page 9 NOTICE 1. When you move the appliance, hold it at its base and lift it carefully. Keep the appliance in an upright position. 2. Never use the door for moving the appliance as you will damage the hinges. 3. Do not put any heavy items on the hob. 4.
-
Page 10: Installation
2. Installation (BIC4 GKU IX 4 and BIC4 2KB GKU IX 4) DANGER! All electrical work must be carried out by a qualified professional. Do not modify the energy supply. The connection must be carried out in accordance with the current local and legal regulations. RISK... -
Page 11: Unpacking And Positioning
2.1 Unpacking and positioning 1. Unpack the appliance carefully. Dispose of the packaging as described in chapter WASTE MANAGEMENT 2. The accessories of the appliance may be equipped with transport protections. Be very careful and do not use any aggressive or abrasive detergents to remove residuals of the transport protection. -
Page 12: Selection Of Installation Equipment / Dimensions
2.3 Selection of installation equipment / Dimensions DANGER! The appliance must be installed by a qualified professional only. Do not carry out the installation yourself. RISK OF ELECTRIC SHOCK! AFETY INSTRUCTIONS FOR THE INSTALLATION NOTICE! Never seal the hob using a sealant (e.g. silicon). Appliance and worktop can be damaged when dismounting the appliance. -
Page 13: Installation Of The Hob
IMENSIONS OF THE INSTALLATION OPENING MINIMUM CLEAR SPACE B = W C = D IDTH EPTH REQUIRED AROUND THE INSTALLATION OPENING 564 mm 494 mm mind. 50 mm 2.4 Installation of the hob DANGER! The appliance must be installed by a qualified professional only. - Page 14 The seal must be fitted tightly on the bottom edge of the hob (no overlaps, no gaps etc.) to prevent liquids etc. from entering the installation opening subsequently. OUNTING OF THE FIXING BRACKETS 2. Install the fixing brackets on the sides of the hob using the appropriate screws: screw one end of the fixing brackets into the predrilled holes on the sides of the hob (s.
-
Page 15: Installation Of The Oven
2.5 Installation of the oven DANGER! The appliance must be connected to the mains by a qualified professional, who is familiar with and adheres to the local requirements and supplementary regulations of your electricity supplier. DANGER! All electrical work must be carried out by a qualified professional. - Page 16 All dimensions in fig. 1 are given in millimetres. . 2): IMENSIONS OF THE INSTALLATION OPENING All dimensions in fig. 2 are given in millimetres.
-
Page 17: Electrical Connection Of The Oven
2.6 Electrical connection of the oven DANGER! The appliance must be connected to the mains by a qualified professional, who is familiar with and adheres to the local requirements and supplementary regulations of your electricity supplier. DANGER! Do not carry out the installation yourself. RISK OF ELECTRIC SHOCK! NSTRUCTIONS FOR THE INSTALLER QUALIFIED PROFESSIONAL... -
Page 18: Connection Diagram
2.6.1 Connection diagram Voltage heating elements 220 - 240 V. Recommended Any kind of connection: the type of safety wire must connection lead. connected to the terminal. ➢ For 220 - 240 V earthed one-phase connection. ➢ Bridges connect 1 - 2 - 3 H05VV-F3G4 terminals 4 - 5... -
Page 19: Electrical Connection: Oven And Hob Connection
N = neutral; the colour of these wires is usually blue. Pay attention to the correct N - connection. E = ground wire; the colour of these wires is usually green / yellow. 2.7 Electrical connection: oven and hob connection ERMINAL BLOCK BIC4 GKU IX 4 IGHT RONG CONNECTION CONNECTION... - Page 20 BIC4 2KB GKU IX 4 WHITE...
-
Page 21: Description Of The Appliance
3. Description of the appliance 3.1 Oven and hob ( BIC4 GKU IX 4 BIC4 2KB GKU IX 4) BIC4 GKU IX 4 Fig. similar: modifications are possible. PERATING PANEL ANDLE OF THE DOOR OF THE OVEN OOR OF THE OVEN Ø... - Page 22 BIC4 2KB GKU IX 4 Fig. similar: modifications are possible. PERATING PANEL ANDLE OF THE DOOR OF THE OVEN OOR OF THE OVEN Ø 140 / 1200 W Ø 140 / Ø 180 // 700 W / 1700 W Ø 175 / Ø...
-
Page 23: And Bic4 2Kb Gku Ix 4 )
3.2 Operating panel ( BIC4 GKU IX 4 BIC4 2KB GKU IX 4 BIC4 GKU IX 4 Fig. similar: modifications are possible. OTARY KNOB TO CONTROL THE FRONT LEFT COOKING ZONE Turn clockwise or anticlockwise to turn on this cooking zone. - Page 24 BIC4 2KB GKU IX 4 Fig. similar: modifications are possible. OTARY KNOB TO CONTROL THE FRONT LEFT COOKING ZONE Dual cooking zone. See also chapter 4.3.3 H OW TO ACTIVATE THE FLEXIBLE COOKING ZONES Turn clockwise to turn on this cooking zone. OTARY KNOB TO CONTROL THE REAR LEFT COOKING ZONE ...
-
Page 25: Operation
4. Operation (BIC4 GKU IX 4 and BIC4 2KB GKU IX 4) Read the complete instruction manual before you operate the appliance for the first time. Strictly observe the safety guidelines! Remove the complete protective film! 4.1 Before the first use 1. -
Page 26: Use Of The Hob
WARNING! Never touch the cooking zones while the residual heat indicator is still on. RISK OF BURNS! 4.3.1 Rotary knobs of the cooking zones (BIC4 GKU IX 4 / BIC4 2KB GKU IX 4) BIC4 GKU IX 4 OTARY KNOBS OF THE COOKING ZONES (s. - Page 27 Cooking zone is switched off. OWER LEVEL Suitable for keeping dishes warm. Lowest setting. OWER LEVEL Suitable for stewing, the steaming of vegetables and slow cooking. OWER LEVEL Suitable for the cooking of soups and larger dishes. OWER LEVEL ...
- Page 28 BIC4 2KB GKU IX 4 OTARY KNOBS OF OTARY KNOB OF OTARY KNOB OF COOKING ZONES COOKING ZONE COOKING ZONE (s. fig. in chapter 3.1 (s. fig. in chapter 3.1 (s. fig. in chapter 3.1 et seq.) et seq.) et seq.) VEN AND HOB VEN AND HOB VEN AND HOB...
-
Page 29: How To Activate The Flexible Cooking Zones ( Bic4 2Kb Gku Ix 4 Only)
Localisation of the COOKING ZONE Symbol for the ACTIVATION OF THE FLEXIBLE COOKING ZONE cooking zone. OVAL see also fig. in chapter 3.1 O et seq. VEN AND HOB Symbol for the ACTIVATION OF THE FLEXIBLE COOKING ZONE cooking zone ... -
Page 30: Use Of The Oven
. The cooking zones will be switched off. 4.4 Use of the oven ( BIC4 GKU IX 4 and BIC4 2KB GKU IX 4 CAUTION! The interior parts of the oven become extremely hot. Do not touch any parts inside the oven if you handle your cookware. RISK OF BURNS! CAUTION! Be careful if you open the door. - Page 31 OTARY KNOB OTARY KNOB OVEN FUNCTIONS OVEN TEMPERATURES NOTICE! Turn the rotary knob for the selection of the oven temperature in clockwise direction only. After you have set a temperature, you can turn the knob back to its home position. Otherwise you may damage the rotary knob.
-
Page 32: Functions Of The Oven
4.5 Functions of the oven OTARY KNOB FOR THE SELECTION OF THE OVEN FUNCTIONS YMBOLS ESCRIPTION OF THE FUNCTIONS NTERNAL LIGHT ➢ turn the rotary knob to this symbol to switch on the internal light. ➢ the oven does not heat. OTTOM HEAT ➢... -
Page 33: Environmental Protection
NOTICE! If you select the oven function incl. fan (top and bottom heat and fan) and set the temperature control of the oven to « 0 » at the same time, just the fan operates and you can cool down food / dishes or the inside of the oven. -
Page 34: Cooking Guidelines
❖ Heat can escape through spillages on the door seals. Clean up any spillages immediately. ❖ Do not install the cooker near of refrigerators / freezers. Otherwise the energy consumption increases unnecessarily. 6. Cooking guidelines WARNING! Be very careful when frying, because oil and fat heat up very fast especially when operating a high power level. -
Page 35: Tips For Baking And Frying
3. Rub both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and place the steak into the pan. 4. Turn the meat just once while cooking. The exact cooking time depends from the size of your steak and your individual preferences (medium, medium rare etc.). -
Page 36: Cleaning And Maintenance
7. Cleaning and maintenance WARNING! Switch off the appliance and let it cool down before cleaning. Disconnect the appliance from the mains before maintenance (fuse box of your household power supply)! WARNING! Never use a steam cleaner to clean the appliance. The steam will cause serious damage to the electric components of the appliance. - Page 37 IND OF CONTAMINATION TRATEGY SAFETY GUIDELINES AILY CONTAMINATION OF THE GLASS CERAMIC FINGERPRINTS STAINS CAUSED BY FOOD SUGARY SPILLAGES 1. Disconnect the appliance from the ➢ While the appliance is disconnected mains (fuse-box). from the mains the residual heat 2. Use a suitable detergent for glass indicator does not work, so the ceramic while the glass ceramic is still cooking zones may be still hot.
-
Page 38: Cleaning Of The Oven
7.2 Cleaning of the oven ➢ Clean the oven after each use. ➢ Switch on the internal light while cleaning. ➢ Clean the interior using warm water and a little bit of washing-liquid. Use a sponge or a soft cloth. Never use abrasive or aggressive detergents. ➢... -
Page 39: Replacing Of The Illuminant
7.4 Replacing of the illuminant WARNING! Switch off the appliance and let it cool down completely. Disconnect the appliance from the mains before maintenance (fuse box of your household power supply)! RISK OF ELECTRIC SHOCK! NOTICE! When you replace the bulb, always use a clean cloth or gloves. Never touch the new bulb with your bare hands. -
Page 40: Removing Of The Inner Glass Panel
2. Close the door slightly. 3. Lift the door and pull it towards your direction. 4. To reassemble proceed in reverse order. 5. Check that the groove of the hinge bracket is positioned properly in its guide. 6. After reassembling the door close the safety catch carefully. 7. - Page 41 MERGENCY MEASURES 1. Switch off the entire appliance. 2. Disconnect the appliance from the mains (fuse box of your household power supply). 3. Contact the customer service. ➢ Check the schedule below before you contact the customer service. RROR AUSES EASURES HE APPLIANCE DOES NOT WORK AT ALL ➢...
- Page 42 HE APPLIANCE OR A COOKING ZONE HAS BEEN SWITCHED OFF AUTOMATICALLY AND UNEXPECTEDLY AN ACOUSTIC SIGNAL SOUNDS AND AN ERROR CODE IS DISPLAYED TYPICALLY ALTERNATING WITH ONE OR TWO DIGITS ON THE TIMER DISPLAY ➢ Technical malfunction. ➢ Note the complete error code disconnect the appliance from the mains and contact the shop you purchased the appliance at...
-
Page 43: Technical Data
9. Technical data 9.1 BIC4 GKU IX 4 ECHNICAL DATA Model Built-in oven with hob Control panel Stainless steel panel Glass ceramic incl. stainless steel frame Energy efficiency category Energy consumption / conventional 0.75 kW/h Energy consumption (fan) 0.74 kW/h Net volume oven in l 59.00... -
Page 44: Bic4 2Kb Gku Ix 4
9.2 BIC4 2KB GKU IX 4 ECHNICAL DATA Model Built-in oven with hob Control panel Stainless steel panel Glass ceramic incl. stainless steel frame Energy efficiency category Energy consumption / 0.75 kW/h conventional Energy consumption (fan) 0.74 kW/h Net volume oven in l 59.00 Size of the appliance Medium size: volume... -
Page 45: Waste Management
10. Waste management 1. While unpacking, the packaging materials (polythene bags, polystyrene pieces, etc.) should be kept away from children. CHOKING HAZARD! RISK OF INJURY! 2. Old and unused appliances must be sent for disposal to the responsible recycling centre. Never expose to open flames. 3. -
Page 46: Guarantee Conditions
11. Guarantee conditions for large electric appliances; PKM GmbH & Co. KG, Neuter Wall 2, 47441 Moers This appliance includes a 24-month guarantee for the consumer given by the manufacturer, dated from the day of purchase, referring to its flawless material- components and its faultless fabrication. -
Page 47: Service Information
TECHNOLOGY FOR DOMESTIC USE Sie finden alle Informationen zum Kundendienst auf der Einlage in dieser Bedienungsanleitung. Aftersales service information on the leaflet inside this instruction manual. Subject to alterations PDATED 06/06/2019 © PKM GmbH & Co. KG, Neuer Wall 2, 47441 Moers...
