PARTS
STAGE 3 Driver Board
1x Driver Board Cover
1x M3x12mm Screw
PARTS
STAGE 4 Button PCB
1x Button PCB
1x Power Button
2x M3 Washer
1x Driver Board
4x M3x8mm Screws
1x Button PCB Cover
1x Ribbon Cable
2x M3 Nut
1x Laser Unit
1x Enable Button
2x M3x12mm Screw
