PARTS
STAGE 2 Gantry Assembly
1x Homing Trigger
2x Motor Bracket
18x M3 Washer
4x M5 Lock Nut
4x Gantry Carriage
4x M5 Washer
1x Laser Carriage
Housing
(contains only 3
linear bearings)
2x Belt
2x Motor
2x Motor Pulleys
10x M3 Nut
8x Shoulder Bolt
16x Flanged Bearings
2x Long Gantry Rail
2x Short Gantry Rail
1x Belt Hub
18x M3x30mm Screw
4x Linear Bearing
4x Rail Bracket
4x M5 Nut
4x Spacer
