MPRO Floor-mount Tub Filler
US-PRO416
Installation Instructions

Introduction

The faucets in this range are single flow (hot and cold water mix in
the body) and should therefore be supplied with hot and cold
water at balanced pressures. If the faucets are not supplied at
balanced pressures then the mixer will not function correctly. The
minimum water pressure required for these faucets is 20 psi. The
maximum water pressure is 60 psi beyond which pressure-
reducing valves must be installed.
The faucets are fitted with quarter-turn ceramic disc cartridges
which provide a good flow rate with very smooth movement.
IMPORTANT: Please read these instructions carefully before
you begin and retain for future reference. These instructions
have been prepared for your guidance, you must exercise due
care at all times.
Before beginning installation, check for any damage that may have
occurred during transport.
Note: Damage claims cannot be made during or after
installation.
We do not accept responsibility for any problems that may
occur through incorrect installation.

Installation notes

The installation must comply with all plumbing codes including local
codes and be installed by a licensed plumbing contractor.
Anti-scald protection is the responsibility of the installer and
according to applicable codes.
Install US-418ROUGH first using the instructions provided with it.
IMPORTANT! Before installing a new faucet it is essential that the
supply pipes are thoroughly flushed in order to remove any remaining
debris, solder or other impurities. Failure to carry out this simple
procedure can cause problems or damage to the working of the
faucet.
Installing shut-off valves on incoming supply lines is recommended
for ease of maintenance.
Turn off the main water supply before connecting to any existing
pipework or doing any maintenance.
WARNING! Please check for any hidden pipes and cables, electric
or otherwise, before drilling holes in a wall or floor.

Tools required

Channel
locks
Plumbers' putty Adjustable
or caulking wrench

Dimensions

7-1/4"
Flat head Cross head
screwdriver screwdriver
9-3/8"
5-1/4" dia.
Hexagonal
key
