Summary of Contents for Crosswater DBSSC0850
- Page 1 DBSSC0850 SINGLE PANE BATH SCREEN PBSBC0850 INSTALLATION INSTRUCTIONS...
- Page 2 IMPORTANT - Please read before installation Please read these instructions carefully before starting VERY IMPORTANT You must complete all tiling and grouting, and the bath MUST be installation and keep in a safe place for future reference. level and fully sealed to the tiles before installation. If you do not Check the contents of the pack carefully before installation.
- Page 3 CONTENTS SINGLE PANE BATH SCREEN Top Pivot Kit (LH) x 1 Top Pivot Kit (RH) x 1 M4 *50mm Screw x 4 Wall Profile Cover x 1 Top Pivot Cover x 1 Wall Plug x 4 Bottom Pivot Kit (LH) x 1 M4 *12mm Screw x 4 Top Pivot x 1 Bottom Pivot Kit (RH) x 1...
- Page 4 Please follow diagram below for the correct assembly for Left or Right hand installation. Left - Assemble pivot door (LH) Ensure that the frame with waterproof strip is positioned for assembly, so that the lip of the waterproof strip is going to be on the inside of the bath. Right - Assemble pivot door (RH) Ensure that the frame with waterproof strip is positioned for assembly, so that the lip of the waterproof strip is going to be on the inside of the bath.
- Page 5 Step 1 - FITTING AND POSITIONING WALL CHANNEL Place wall channel in position on the bath (20mm in from the edge of the bath), use a spirit level to ensure that it is vertical, and mark all 4 fixing holes on the wall. Drill holes in the positions marked using a 6mm masonry drill bit.
- Page 6 Step 4 For any further information please contact Crosswater Phone number, 0345 873 8840 Website, crosswater.co.uk Email address, sales@crosswater.co.uk The manufacturer reserves the right to make technical modifications without prior notice.
