Planning and Installation

This article provides general safety standards to adhere to when installing or connecting a vEdge 100b router or its
components.
General Safety Standards
• Install your vEdge router in compliance with the following local, national, and international electrical codes:
◦ United States-National Fire Protection Association (NFPA 70), United States National Electrical Code.
◦ Other countries-International Electromechanical Commission (IEC) 60364, Part 1 through Part 7.
◦ Evaluated to the TN power system.
◦ Canada-Canadian Electrical Code, Part 1, CSA C22.1.
• Locate the emergency power-off switch in the room in which you are working. In case of an electrical accident, quickly
turn off the power.
• Disconnect power before installing or removing the router.
• If an electrical accident occurs, use caution and immediately turn off power to the router.
• Make sure that grounding surfaces are thoroughly cleaned and well-finished before grounding connections are made.
• Do not work alone if hazardous conditions exist.
• Always check that power is disconnected from a circuit. Never assume that it is disconnected.
• Carefully inspect your work area for possible hazards, such as moist floors, worn-out power cords, ungrounded power
extension cords, and missing safety grounds.
• Operate the device within marked electrical ratings and product usage instructions.
• To ensure that the router and the FRUs function safely and correctly, use the specified cables and connectors, and
make certain they are in good condition.
Additional Information
Install the vEdge 100b Router
Connect the vEdge 100b Router
vEdge Router Default Configuration
https://docs.viptela.com/02vEdge_Hardware/02vEdge_100b_Router/03Planning_and_Installation
Created on: Mon, 25 Jan 2016 18:36:33 GMT
Generated by: raj@viptela.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the vEdge 100b and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Viptela vEdge 100b

Summary of Contents for Viptela vEdge 100b

  • Page 1: Planning And Installation

    Planning and Installation This article provides general safety standards to adhere to when installing or connecting a vEdge 100b router or its components. General Safety Standards • Install your vEdge router in compliance with the following local, national, and international electrical codes: ◦...

  • Page 2: Prepare For Router Installation

    • High humidity conditions can cause moisture to penetrate into the chassis. The device supports 10% to 85% humidity levels, non-condensing. Rack Requirements You can mount the vEdge 100b router in a two-post or a four-post rack. Table 1 provides the rack requirements for the router. Table 1: Rack Requirements for vEdge 100b Routers...
  • Page 3 Rack secured to For maximum stability, secure the rack to ceiling brackets and to floor brackets. building structure Additional Information Install the vEdge 100b Router https://docs.viptela.com/02vEdge_Hardware/02vEdge_100b_Router/03Planning_and_Installation/01Prepare_for_Router_Installation Created on: Mon, 25 Jan 2016 18:36:33 GMT Generated by: raj@viptela.com...
  • Page 4 Unpack the vEdge 100b Router A vEdge 100b router is shipped in a cardboard carton and secured firmly in place with foam packing material. The carton contains a packing list and Quick Start instructions. It is recommended that you do not unpack the router till you are ready to install it.
  • Page 5 The packing list specifies the part number, name, and quantity of each item in the carton. If any part on the packing list is missing, contact your customer service representative or contact Viptela customer support from within the U.S. or Canada by telephone at 800-525-5033 or by email to support@viptela.com.
  • Page 6 • Tape measure or level Mount the vEdge 100b Router in a Rack You can mount the vEdge 100b router on two front posts in a 19-inch rack using simple rack mount ear accessories. To do so: 1. Place the router chassis on the floor or on a sturdy table near the rack.
  • Page 7 Figure 3: Positioning the vEdge 100b Router in the Rack 5. Secure the mounting ears to the two front posts of the rack using the four rack-mount screws (two on each side) in the packet marked B. Tighten the screws.
  • Page 8 Mount the vEdge 100b Router on the Wall You can mount the vEdge 100b router on the wall either horizontally or vertically. To mount the vEdge 100b router on the wall: 1. Measure the distance between the two wall-mount holes on the underside of the router chassis as shown in Figure 5.

  • Page 9: Connect Ac Power To The Router

    Note: It is strongly recommended that you use the power adapter supplied with the vEdge 100b router. Connect the Router to LAN and WAN Interfaces To connect the vEdge 100b router to the LAN, plug the appropriate cable into any port, except port 4, on the front of the router.
  • Page 10 Figure 2: Connecting a vEdge 100b Router to a Management Console Additional Information Log Into a Viptela Device vEdge Router Default Configuration https://docs.viptela.com/02vEdge_Hardware/02vEdge_100b_Router/03Planning_and_Installation/03Connect_the_vEdge_100b_Router Created on: Mon, 25 Jan 2016 18:36:33 GMT Generated by: raj@viptela.com...
  • Page 11 100b Router Default Configuration Each vEdge 100b router is shipped from the factory with a default configuration. The default configuration file sets the default CLI prompt to vsmart#, configures OMP, and enables logging of syslog messages to a file.
  • Page 12 Additional Information Viptela Overlay Network Bringup https://docs.viptela.com/02vEdge_Hardware/02vEdge_100b_Router/03Planning_and_Installation/vEdge_100b_Router_Default_Configura Created on: Mon, 25 Jan 2016 18:36:33 GMT Generated by: raj@viptela.com...
