vEdge 100wm Router
The vEdge 100wm router delivers highly secure site-to-site data connectivity to small business and home
offices (SOHO). The vEdge 100wm router is a fixed-port-configuration router with the following features:
• Built-in LTE modem with mini-SIM (or 2FF) card
• Two multiband swivel-mount dipole antennas
• Supports a 4G/3G/2G–capable modem to connect to cellular networks
• Wi-Fi access point capability
• Wi-Fi radio configurable for 2.4 GHz or 5.0 GHz
• Five built-in 10/100/1000–Mbps Ethernet ports
• Power over Ethernet (PoE) source support on one Ethernet port
• Encryption and QoS support
• 100 Mbps forwarding throughput (inclusive of encryption)
• Secure identification chip for anticounterfeit and secure authentication
• Integrated power supply
• Kensington security lock slot to physically lock down the router
• GPS input for geographical location
• Desktop mount or wall mount
Chassis Views
Figure 1 and Figure 2 show the front and back panels of the vEdge 100wm router, indicating the locations of
the power interfaces, status indicators, and chassis identification labels.
Figure 1: Front Panel of the vEdge 100wm Router
vEdge 100wm Router
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the vEdge 100wm Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Viptela vEdge 100wm Series

Summary of Contents for Viptela vEdge 100wm Series

  • Page 1 vEdge 100wm Router The vEdge 100wm router delivers highly secure site-to-site data connectivity to small business and home offices (SOHO). The vEdge 100wm router is a fixed-port-configuration router with the following features: • Built-in LTE modem with mini-SIM (or 2FF) card •...

  • Page 2: Declaration Of Conformity

    Exception ENC. As such, they are eligible for export according to Section 740.17 of the EAR. The Viptela solutions and products can be delivered to most end users worldwide, except to entities or end users in the following countries: Cuba, Iran, North Korea, Sudan, and Syria.

  • Page 3: Components And Specifications

    The Viptela software distribution policy allows only authenticated users to download the Viptela encryption software. Recipients of controlled technology are obliged to maintain adequate controls to prevent nationals from outside the U.S. and Canada from accessing Viptela information, subject to ECCN5E002, without first obtaining authorization from the U.S. government.
  • Page 4 vEdge 100wm Router Components and Specifications Item Specification 1.8 in. (4.5 cm) Chassis height Chassis width 9.25 in. (23.5 cm) Chassis depth 5.75 in. (14.6 cm) Chassis weight 1.45 lbs (0.67 kg) Wall-mount plate accessory Provided with the unit Packaging Specifications Package height 5.375 in.
  • Page 5 vEdge 100wm Router Components and Specifications Table 2: Platform Specification vEdge 100wm-AT 100wm-AT Carrier AT&T Modem Sierra Wireless MC7354 4G LTE Bands Band 2 (1900 MHz), Band 4 (AWS 1700/2100 MHz), Band 5 (850 MHz), Band 17 (700 MHz) Region United States vEdge 100wm-GB 100wm-GB...
  • Page 6 vEdge 100wm Router Components and Specifications Platform Specification 100wm-SP Carrier Sprint Modem Sierra Wireless MC7354 4G LTE Bands Band 25 (1900 MHz) Region United States vEdge 100wm-VZ 100wm-VZ Carrier Verizon Modem Sierra Wireless MC7354 4G LTE Bands Band 4 (AWS 1700/2100 MHz), Band 13 (700 MHz) Region United States Multiband Cellular Antenna Specifications...

  • Page 7: Front And Rear Panel Components

    vEdge 100wm Router Front and Rear Panel Components Item Specification Antenna Length: 6.37 in. (16.19 cm) dimensions Width: 0.9 in. (2.38 cm) Depth: 0.63 in. (1.59 cm) Humidity Noncondensing, 65°C, 95% RH Wi-Fi Specifications The vEdge 100wm router provides the following Wi-FI capabilities: •...
  • Page 8 vEdge 100wm Router Front and Rear Panel Components Table 4: Color Status Power Green/Red • Off: System is not on • Green: System power is healthy and operational • Red: Power supply fault System Green/Yellow/Red • Off: System is not on •...
  • Page 9 vEdge 100wm Router Front and Rear Panel Components Figure 1: Chassis Status LEDs in a vEdge 100wm Router (UPDATE) Rear Panel The rear panel of the vEdge 100wm router has two cellular antenna terminals, a GPS antenna input, a Kensington security lock slot, and a Reset button. See Chassis Views for the location of these components. Cellular Antenna Terminals The rear panel of the vEdge 100wm router has two SMA antenna terminals for attaching the two multiband swivel-mount dipole antennas that ship with the router.

  • Page 10: Ports And Connectors

    vEdge 100wm Router Ports and Connectors Ports and Connectors The vEdge 100wm router supports three types of ports: • RJ-45 Ethernet ports • USB port • USB serial console port. RJ-45 Ethernet Ports The vEdge 100wm router has five built-in RJ-45 Ethernet ports. These ports support 10/100/1000 Mbps and are numbered 0 through 4.

  • Page 11: Planning And Installation

    vEdge 100wm Router Power Supply and Cooling System Power Supply and Cooling System The vEdge 100wm router has an built-in AC-to-DC power supply unit. This article describes the AC power supply in the router and the cooling system and airflow through the router chassis. AC Power Supply in vEdge 100wm Router The vEdge 100wm router has an integrated AC power supply that exposes a C6 male AC inlet connector externally.

  • Page 12: Prepare For Router Installation

    vEdge 100wm Router Prepare for Router Installation • United States—National Fire Protection Association (NFPA 70), United States National Electrical Code. • Other countries—International Electromechanical Commission (IEC) 60364, Part 1 through Part • Evaluated to the TN power system. • Canada—Canadian Electrical Code, Part 1, CSA C22.1. •...
  • Page 13 Install the vEdge 100wm Router • The airflow to the router is from the top surface near the Viptela logo. To ensure that the airflow to the router is not blocked, keep an air gap of 2-3 inches (5-8 cm) above the router and do not place anything directly on top of the router.
  • Page 14 The packing list specifies the part number, name, and quantity of each item in the carton. If any part on the packing list is missing, contact your customer service representative or contact Viptela customer support from within the U.S. or Canada by telephone at 800-525-5033 or by email to support@viptela.com .
  • Page 15 vEdge 100wm Router Install the vEdge 100wm Router Table 7: Component Quantity Router chassis Multiband dipole antenna AC power cord appropriate for your geographical location (ferrite bead attached) USB console cable Wall-mount plate Quick Start document Install the SIM Card Into the vEdge 100wm Router Before you connect power to the vEdge 100wm router, you must install the SIM card that you received from your carrier.
  • Page 16 vEdge 100wm Router Install the vEdge 100wm Router 1. Slide the SIM card holder towards the socket cover hinge. Figure 4: Sliding the SIM Card Holder 1. Open the SIM card holder. Figure 5: Opening the SIM Card Holder vEdge 100wm Router...
  • Page 17 vEdge 100wm Router Install the vEdge 100wm Router 1. Insert the SIM card firmly into the SIM card holder. Figure 6: Inserting the SIM Card into the SIM Card Holder 1. Close and lock the SIM card holder. Then close the socket cover and screw it shut. Figure 7: Locking the SIM Card Holder and Closing the Socket Cover vEdge 100wm Router...
  • Page 18 vEdge 100wm Router Install the vEdge 100wm Router If you need to change the SIM card later, make sure you disconnect the router's power first, before installing the new card. Attach the Antennas to the vEdge 100wm Router The rear panel of the vEdge 100wm router has two antenna terminals. To attach the multiband antennas to the router: 1.
  • Page 19 vEdge 100wm Router Install the vEdge 100wm Router Mount the vEdge 100wm Router on the Wall In addition to the accessory box, you need the following tools to mount a vEdge 100wm router: • Number 2 Phillips (+) screwdriver • Tape measure or level To mount the vEdge 100wm router on the wall: 1.
  • Page 20 vEdge 100wm Router Install the vEdge 100wm Router 1. Mount the router on the mounting plate by aligning the two slots on the underside of the router chassis to the notches in the mounting plate. Then gently slide the router chassis down onto the notches. Figure 11: Mounting the vEdge 100wm Router on the Mounting Plate vEdge 100wm Router...
  • Page 21 vEdge 100wm Router Connect the vEdge 100wm Router 1. Secure the router with a Kensington security lock using the slot in the rear of the chassis. Figure 12: Securing the Router with a Kensington Security Lock Connect the vEdge 100wm Router This article describes how to connect the vEdge 100wm router to an AC power source and to a management console.
  • Page 22 $ screen /dev/tty.usbserial* 115200,cs8 vEdge 100wm Router Default Configuration Default Configuration for Software Releases 16.3 and Later For Releases 16.3 and later, the default configuration file looks like this: vEdge100wm# show running-config system host-name vedge vbond ztp.viptela.com vEdge 100wm Router...
  • Page 23 vEdge 100wm Router vEdge 100wm Router Default Configuration auth-order local radius tacacs usergroup basic task system read write task interface read write usergroup netadmin usergroup operator task system read task interface read task policy read task routing read task security read user admin password $6$kIUhwl5BwngDJKLk$Qt9Xj3WwN90bzIDL/mRmpJ33Q1nAnMGSSNK1SKhWCK/pjnM2047hYntW8C4PKUpPgYuW8FiS4KKZrN/Wx4uOY1...
  • Page 24 Default Configuration for Software Releases 16.2 and Earlier For Releases 16.2 and earlier, the default configuration file looks like this: vEdge100wm# show running-config system host-name vedge vbond ztp.viptela.com auth-order local radius tacacs usergroup basic task system read write task interface read write...

  • Page 25: Maintenance And Troubleshooting

    vEdge 100wm Router Maintenance and Troubleshooting vpn 0 interface cellular0 ip dhcp-client tunnel-interface encapsulation ipsec color lte no allow-service bgp allow-service dhcp allow-service dns allow-service icmp no allow-service sshd no allow-service netconf no allow-service ntp no allow-service ospf no allow-service stun 1428 profile technology auto (in Releases 16.3.2 and later)
  • Page 26 • Fan alarm—The router has a fixed built-in fan for system cooling which runs at a variable speed. The Viptela software maintains the fan at an optimal fan speed, raising the speed as the ambient temperature increases and decreasing the speed as the temperature decreases, to keep the router operating at the lowest possible temperature in the green temperature threshold.

  • Page 27: Return Hardware

    To perform a short press reset, press the Reset button for two seconds. The short press reset takes effect almost instantaneously and reboots the router. Return Hardware This article describes how to return a vEdge router or a hardware component to Viptela for repair or replacement. vEdge 100wm Router...
  • Page 28 Return Hardware Locate Serial and Model Number To return a vEdge router or a hardware component to Viptela, you need the serial and model number of the router or the component being returned. You can locate the serial and model number of a vEdge router in one of the following ways: •...
  • Page 29 1. If you do not have a vEdge 1000 router, skip this step. Otherwise: a. If the router is installed in a rack using the rack-mount kit from Viptela, remove the front stopper screwed along the front side of the rack-mount tray.
  • Page 30 vEdge 100wm Router Return Hardware 3. Pack each component in its original packing material. If you do not have the original packing material, ensure that the component is packed adequately with packing material to prevent any damage in transit. 4. Place the component in the original cardboard box or another cardboard box if the original is not available. 5.
