/ Perfect Charging / / Solar Energy Installationsanleitung TTB 160 - 500 Brennerkörper wechseln WIG Hand-Schweißbrenner Changing the Torch Body Installation Instructions TIG manual welding torch 42,0410,2405 004-04022020 Fronius prints on elemental chlorine free paper (ECF) sourced from certified sustainable forests (FSC).
Page 3
Brennerkörper wechseln Brennerkörper wechseln - gasge- kühlte Schweiß- brenner 180° HINWEIS! Beim Wechseln des Brennerkörpers da- rauf achten, dass nur zusammengehö- rende Systeme montiert werden. ► Keine gasgekühlten Brennerkörper auf wassergekühlte Schlauchpakete mon- tieren und umgekehrt! 180° * O-Ring vor der Montage einfetten!
Page 4
180° WICHTIG! Beim Montieren des Brennerkörpers darauf achten, dass dieser bis auf An- schlag eingeschoben und eingerastet ist. Brennerkörper Stromquelle abschalten und vom Stromnetz trennen; wechseln - was- Nachlaufphase des Kühlsystems abwarten sergekühlte Schweißbrenner Bei vorhandenem Kühlgerät CU 600 MC: Schweißbrenner-Schlauchpaket mittels Stromquelle oder Schweißbrenner entleeren Bei anderen Kühlgeräten: Schlauch für Kühlmittel-Vorlauf am Kühlgerät absstecken...
Page 5
Kuppelstelle am Schlauchpaket mit Druckluft reinigen Brennerkörper mit einem Tuch abtrocknen Schutzkappe am Brennerkörper anbringen HINWEIS! Beim Wechseln des Brennerkörpers darauf achten, dass nur zusammengehörende Systeme montiert werden. ► Keine gasgekühlten Brennerkörper auf wassergekühlte Schlauchpakete montieren und umgekehrt! 180° * O-Ring vor der Montage einfetten!
Page 6
180° WICHTIG! Beim Montieren des Brennerkörpers darauf achten, dass dieser bis auf An- schlag eingeschoben und eingerastet ist. Brennerkörper montieren Stromquelle am Netz anschließen und einschalten An der Stromquelle die Taste Gasprüfen drücken Für 30 s strömt Schutzgas aus. Kühlmittel-Durchfluss überprüfen: Im Kühlmittel-Behälter muss ein einwandfreier Kühlmittel-Rückfluss ersichtlich sein.
Page 7
Changing the Torch Body Changing the Torch Body – Gas-cooled Weld- ing Torches 180° NOTE! When changing the torch body, ensure that only the related systems are moun- ted. ► Do not mount gas-cooled torch bodies on water-cooled hosepacks or vice ver- 180°...
Page 8
180° IMPORTANT! When mounting the torch body, ensure that it is pushed all the way in and snaps into place. Changing the Switch off the power source and disconnect from the grid Torch Body – Wa- Wait for the post-run time of the cooling system ter-Cooled Weld- ing Torches When cooling unit CU 600 MC is available:...
Page 9
Clean the interface at the hosepack using compressed air Dry the torch body with a cloth Put the safety cap on the torch body NOTE! When changing the torch body, ensure that only the related systems are mounted. ► Do not mount gas-cooled torch bodies on water-cooled hosepacks or vice versa. 180°...
Page 10
IMPORTANT! When installing the torch body, ensure that it is pushed all the way in and snaps into place. Connect the power source to the grid and switch on Press the gas-test button on the power source Shielding gas flows out for 30 s. Check the coolant flow: You must be able to see a perfect coolant return flow in the coolant container.
Page 12
FRONIUS INTERNATIONAL GMBH Froniusstraße 1, A-4643 Pettenbach, Austria E-Mail: sales@fronius.com www.fronius.com Under www.fronius.com/contact you will find the addresses of all Fronius Sales & Service Partners and locations...
