DS LED System Assembly / Page 1
digitalsputnik.com
this guide helps you to
assemble one module light
fixture and also explains how
build up dual or multiple
module light fixtures.
ASSEmbLy of SingLE Light moDuLE fixturE
FIG 1
FIG 3
FIG 5
onE moDuLE
Light fixturE
ATTACHING THE FIRST DIFFUSER BOX SIDE
ATTACHING THE NEXT
DIFFUSER BOX SIDE
SLIDE
LOCKING THE BARNDOOR
CLICK
DuAL moDuLE
Light fixturE
FIG 2
CLICK
FIG 4
FIG 6
powEr SuppLy
LOCKING THE DIFFUSER
BOX SIDE
ATTACHING
THE BARNDOOR
INSERTING
THE DIFFUSER
LENS
SLIDE
