Hobbies & Helis Octane Dominator 20 Instruction Manual

Pro/sport helicopter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Page 1 of 105

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Octane Dominator 20 and is the answer not in the manual?

Questions and answers

Related Manuals for Hobbies & Helis Octane Dominator 20

Summary of Contents for Hobbies & Helis Octane Dominator 20

  • Page 1 Page 1 of 105...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION CUSTOMER SERVICE FEATURES FRE-ASSEMBLY INFORMATION REQUIRED TOOLS HARDWARE & OPTIONAL ACCESSORIES OTHER HARDWARE & OPTIONAL ACCESSORIES OTHER REQUIREMENTS PART LIST SECTION 1: UPPER FRAMES SECTION 2: LOWER FRAMES SECTION 3: LANDING GEAR ASSEMBLY SECTION 4: DRIVING SYSTEM SECTION 5: TAIL ASSEMBLY SECTION 6: CONTROL SYSTEMS SECTION 7A: ROTOR HEAD SPORT VERSION...

  • Page 3: Introduction

    INTRODUCTION Congratulations and thank you for the purchase of great product! It is our sole desire for you to enjoy the quality workmanship and performance of any of our helicopters. We believe we have the latest designs and technology incorporated into our model helicopters. Our CNC parts are produced using the best high density materials &...

  • Page 4: Customer Service

    CUSTOMER SERVICE Quickworldwide Websites: http://www.hhiheli.com 201 South 3 . St. & 309 N. http://www.quickheli.com Coopersburg, PA 18036 http://www.giantscaleplanes.com Phone: (610)-282-4811 E-mail: Jon or chris or Fax: (610)-282-4816 Irwin@quickworldwide.com Office Hours: Mon – Fri: 8:30 – 6:00 Sat: 8:30 – 4:00 (Eastern Time) Technical Support Personnel: Irwin –...

  • Page 5: Features

    FEATURES Little Dominator 1. Frame Construction: Little Dominator frames are made of the highest quality Carbon Fiber or Black G-10. These frames are not only thick and rigid but will provide excellent vibration absorption. One-Way Hex Start Shaft System: The one-way bearing allows the engine to continue to run after the starter motor has been stopped.

  • Page 6: Fre-Assembly Information

    PRE-ASSEMBLY INFORMATION Warning The radio-controlled model helicopter contained in this kit is not a toy. Rather, it is a sophisticated piece of equipment. This product is not recommended for use by children without adult supervision. Radio controlled models such as this is capable of causing both property damage and/or bodily harm to both the operator/assembler and spectators if not properly assembled and operated.

  • Page 7: Required Tools

    REQUIRED TOOLS MAT 1001 HHI 7332 (4) piece Allen Driver Set HHI 7010 Ball link pliers set HHI 7052 Ball end drivers Bubble Balancer Pitch Guage HHI7001 Universal HHI 7005 Fly bar Shaft Checker Phillips Screw Ball end drivers Driver Lock HHI7050,7051 + HHI7040...

  • Page 8: Hardware & Optional Accessories

    HARDWARE & OPTIONAL ACCESSORIES GLUES AND THREAD LOCK COMPOUNDS RADIO MOUNTING ACCESSORIES Receiver Hold down Straps HHI55** 2 pk $4.99 (yellow, orange, Pink, Black) HHI55-4 4 pk $8.99 (2yellow & 2orange or 2Pink & 2Black) Velcro Pads (VEL1) Wire Ties Spiral Wrap HHIWT01X HHI2811 3’...
  • Page 9 ENGINES, SPARK PLUG, ENGINE KILL SWITCH AND EXHAUST SYSTEM ENGINES: we recommend Zenoah G200PUH Tuned Pipes TK4000 MUFFLER ENGINE KILL SWITCH Zimmerman TK 4005-2 FUEL SYSTEM Tube Ends Part # QUI9001 Fuel Filter Part # QUI9002 Mini Cock Straight Part # QUI9 Dubro #505 Tygon Fuel Tubing Triangle Joint Part # QUI9...

  • Page 10: Other Hardware & Optional Accessories

    OTHER HARDWARE & OPTIONAL ACCESSORIES Servo Wheels 60 SIZE SKID STOPS HHI1010B(blue), HHI1010G(GOLD) HHI 200 AVAILABLE IN COLORS HHI 2004B SERVO ARM SET LANDING GEAR DAMPENERS Page 10 of 105...
  • Page 11 BASE LOAD ANTENNA HHI 53** AVAILABLE IN BLUE, GOLD, PURPLE AND IN 40, 50, AND 72 MHz FINISHING CAPS • Adds color and style • Distributes force across larger surface area (20 pcs in a package) (8 pcs in a package) BLACK HHIM11100B HHIM11100...

  • Page 12: Other Requirements

    OTHER REQUIREMENTS Radios: Any radio that supports EMS/CCPM Mixing will work fine. Note: Please consult the instruction for your Gyro for setting the overall travel and limits to ensure proper operation and travel of Tail Pitch Slider. Servos: Any premium, sport, or high quality servo will offer acceptable performance. However, because servos operate all critical functions of the helicopter, they can be the single most important component that contributes to proper function of the helicopter.

  • Page 13: Part List

    PART LIST • n your kit, parts are bagged according to each major assembly and are labeled “Bag 1, Bag 2, etc.” You will note that the heading for each assembly indicates which bag correlates with each assembly. • For a good installation, only open up the bags that you need for particular assembly. •...
  • Page 14 Step 1 Read the entire manual to become familiar with the layout of the machine and these instructions. Verify the parts in each bag with the Pick list that came with your kit. Be careful to set up a good work area so parts do not get lost and always reseal the bags when you are finished working or have taken out the parts you plan to install in the current work session.
  • Page 15 Step 2 Check and layout the parts for the lower frame assembly. The table below shows the parts and tools necessary for this work session. Building this part first will give you a strong base for the entire assembly. It will help to keep your hands free eliminating the need for a third hand.
  • Page 16 2-1 FUEL TANK SUB FRAME ASSEMBLY Part# Description QFG014 M3X100 Square Cross QFG013 Fuel Tank Sub frame HHI3M08C M3x8 Cap Head Bolt Assemble the frames to the crossmembers with 2-(3mm x 8mm SHCS).Fuel Tank Frame Assy.avi QFG014 QFG013 HHI3M08C Set these aside and proceed to step 3. Page 16 of 105...
  • Page 17 Step 3 Attach the gas tank assemblies to the right lower frame with two 3 x 8mm SHCS as shown below. Be sure to face them away from each other as it will make the area that touches the tank larger and more stable. Use a frame angle or any flat surface to press against the bottom of the crossmembers making them aligned parallel to each other as you tighten them.
  • Page 18 Step 4 Attach bulkhead to left side of frame: Insert 3 x 25 mm screws through holes as shown. Put a standoff QFG018 on each one and thread into bottom two holes of bulkhead. Again blue Loctite here HHI3M25C QFG018RND QFG654 Shown to the left with finishing Caps applied to the frame and frame angle.
  • Page 19 Step 5 Attach right side of frame: Take right side of frame and insert two 3mm x 25mm screws as shown. Slide on the standoffs and attach to bulkhead. Insert screws for fuel tank sub assemblies and the lower frame will now stand on its own, giving you a solid base from which to build. QFG0018RND HHI3M25C HHI3M12C...
  • Page 20 Step 6 Attach Right Side Frame Angle: Insert 3mm x 12mm socket head cap screw through third hole in right side frame angle, then through the last bottom hole in the right side front lower frame, then thread into cross member 3. Insert a 3mm x 8 mm SHCS through the holes as shown and assemble with 3 mm flat locknuts.
  • Page 21 2-2 FUEL TANK ASSEMBLY Bag# Description In box Tank Clunk In box Medium Tygon Hose(gasoline line) In box Long Tube In box Tank Rubber Plug In box Short Tube In box Tank Fuel Plug Bottom Flange In box Tank Fuel Plug Top Flange In box M3x25 Cap Head Bolt Fuel Tank...
  • Page 22 Lay Fuel Tank into frame: Insert fuel tank onto the bottom fuel tank sub assemblies. Frames should be facing away from each other to give them a wider holding area. The fuel tank sits in place as shown below QF501A Page 22 of 105...
  • Page 23 Step 7 Insert the upper fuel tank sub assemblies with the four 3mm x 8mm screws as shown below. Be patient, it is a tight fit. Leave the screws slightly loose until the radio tray is installed this will ensure that the radio tray lays flat on the four crossmembers and the flathead screws seat nicely.
  • Page 24 Step 8 Attach cross members 4 and 5: Insert a 3mm x 8mm SHCS from the inside of each frame piece to attach the canopy standoffs as shown to the holes directly under the cross member holes. This part may be straight with no flare.
  • Page 25 Step 9 Install radio tray: If not already done, you must prepare the radio tray for the flathead screws by beveling the holes with a 45 degree countersink bit. If using a drill press, set it up with the bit lowered to any hole and drill in small increments until you reach the proper depth then set the depth stop on the drill press for the rest of the holes.
  • Page 26 Step 10 Attach Left Rear Frame: Slide the back end of the left rear frame behind the left frame angle. Mount the front of the left rear frame through the holes shown with (2) 3mm x 25mm SHCS. Leave them slightly loose until all screws are in for the piece.
  • Page 27 Step 11 Attach right side rear frame: Slide the back end of the right rear frame behind the right frame angle. Mount the front of the right rear frame through the holes shown with (2) 3mm x 25mm SHCS. Leave them slightly loose until all screws are in for the piece.
  • Page 28 Assemble and install Landing Gear Bag# Description Landing Gear Strut Landing Gear Skid Landing Gear End Cap M2.5x6 Self Taping M3x14 Cap Head Bolt M3 Locknut 7***** CA Glue 8***** Optional skid feet • Drill 4 holes in the Landing Gear Struts with a 3mm drill bit with a spacing of 92mm •...

  • Page 29: Section 1: Upper Frames

    SECTION 1: UPPER FRAMES Bag 1 • n your kit, parts are bagged according to each major assembly and are labeled “Bag 1, Bag 2, etc.” You will note that the heading for each assembly indicates which bag correlates with each assembly.
  • Page 30 1-1 ELEVATOR SHAFT BEARINGS Bag# Description Fram Upper Frame (from Frame Bag) 5X10X4 Flanged Bearing Note: The holes on the frames are designed for “push-fit” feature. Sometime you may have to sand them a little bit before pushing the bearings in. The bearing flange mates against the inside of the frame.
  • Page 31 1-2 LEFT AILERON & RUDDER SERVO SUBASSEMBLY Bag# Description Remem Ste1-1 L. Upper Frame Subassembly ber to apply 2*** Servo Loctite for the Screws ( see M2.5x16 Cap Head Bolt “Loctite Warning” M2.5 Locknut section ) Fixing Plate ***** Part No. with ***** means that part is not included in the kit. Note: Be sure to use the rubber grommets and eyelets that are provided by the servo manufacturer.
  • Page 32 1-3 RIGHT AILERON & ELEVATOR SERVO SUBASSEMBLY Bag# Description Step 1 R. Upper Frame Subassembly 2*** Servo M2.5x16 Cap Head Bolt M2.5 Locknut Fixing Plate ***** Part No. with ***** means that part is not included in the kit. Note: Be sure to use the rubber grommets and brass eyelets that are provided by the servo manufacturer.
  • Page 33 1-4 INNER ELEVATOR CONTROL ARM SUBASSEMBLY Description Remember to apply Inner elevator control arm Loctite for the Screws Elevator Control Shaft ( see “Loctite Warning” M3x5 Set Screw section ) M3x4 Pivot Ball Stud Note: Elevator Control Shaft is designed to fit tightly in M5x11x4 Flange Bearings on the Upper Frames.
  • Page 34 1-5 TAIL TRANSMISSION ASSEMBLY Description The Bearing Blocks shown may look differently -Install Counter Gear to Counter Counter Gear Gear Shaft using Counter Gear Lock Pin (No. Counter Gear Shaft 3) and M4 E-clip to secure it. Apply JP Weld Counter Gear Lock Pin around the Pin.
  • Page 35 1-6 ELEVATOR CONTROL ARM-RIGHT SIDE Bag# Description Step 1-3 R. A&E Arm Subassembly (step 1-3) Step 1-4 Inner El. Ctrl. Arm Subassembly Outer Elevator Control Arm M3x5 Set Screw M3x4 Pivot Ball Stud Right Aileron Control Lever M3x12 Cap Head Bolt QC527 QC524R HHI3M12C...
  • Page 36 1-7-B ANTI-ROTATION GUIDE ASSEMBLY PRO VERSION Bag# Description Step 1-6 Right Upper Frame Subassembly Swashplate Anti-Rotation Guide Base Frame Swashplate Anti-Rotation Guide M3x8 Cap Head Bolt M3x6 Cap Head Bolt QSF003LD QF317A HHI3M08C Loctite HHI3M06C Note: The frame shown is pro version. Page 36 of 105...
  • Page 37 1-8 RIGHT SIDE ASSEMBLY Bag# Description Step 1-7 Right Upper Frame Long Canopy Standoff (40mm) M3x26 Cross Member Upper Main Shaft Bearing Block Clutch Bearing Block Assembly Step 1-5 Tail Transmission Assembly Lower Main Shaft Bearing Block 10x24x9 Thrust Bearing M3x8 Cap Head Bolt M4x10 Cap Head Bolt M3x7 Flat Washer...
  • Page 38 HHI2730 (20PAK) USED IN SETS OF 2 WITH TEETH LOCKED TOGETHER Page 38 of 105...
  • Page 39 1-9 UPPER FRAME INSTALLATION Bag# Description Step 1-2 Left Upper Frame Assembly Long Canopy Standoff (40mm) M3x8 Cap Head Bolt Step 1-8 Right Upper Frame Assembly Boom Holder M3x40 Cap Head Bolt M3 Locknut Left Aileron Arm Control Lever M3x4 Pivot Ball Stud M3x5x3 Spacer M3x12 Cap Head Bolt M4X10 Cap Head Bolt...
  • Page 40 QC524L QF567 HHI3M4PS HHI3M12C Page 40 of 105...
  • Page 41 1-10 CLUTCH BELL ASSEMBLY Bag# Description *The thread portions of some Pinion Pinion Gear* Gears are a bit too long. This Clutch Bell will make pinion touch Clutch Shoe clutch bell bearing. In this M4x4 Set Screw case, just sand down the Start Coupler thread portion a little to Start Shaft...
  • Page 42 Red Loctite: between bearing and outside of pinion. QD315 You may need 2 5x7x2 shims here if you received the long start shaft QD659 Insert a shim washer between this point and the bearing. Note: Start Coupler and Start Shaft have to be installed no matter what you choose to use an electric starter or a hand pull starter.

  • Page 43: Section 2: Lower Frames

    SECTION 2: LOWER FRAMES Bag 2 Page 43 of 105...
  • Page 44 2-7 ENGINE PLATES & THROTTLE CONTROL LEVER ASSEMBLY Bag# Description 1***** Engine crew the Lower Engine Plate Carburetor of Upper Engine Plate the engine, M5x14 Flat Head Bolt rotate it 180 Frame Fan Shroud Mount clockwise, M3x6 Flat Head Bolt and then Throttle Extension screw it again.
  • Page 45 Magnet Installation for Electronic Ignition The magnet can protrude slightly from the bottom of the hub but not more than 1mm or 1/16”. Page 45 of 105...
  • Page 46 2-8 ENGINE ASSEMBLY Bag# Description Step 2-7 Engine Fan Hub Cooling Fan M3x6 Flat Head Bolt Clutch Lower Engine Collet Upper Engine Collet M6x25 Hex Head Bolt (or Socket Cap M4x8 Cap Head Bolt M6 Nord-Lock Washer QD662 QD669 Also available in aluminum.
  • Page 47 Install the front and rear shrouds as shown below with two 4 x 6mm SHCS. QFG018CLD QFG017CLD Note: it is very important to use a Dialing Indicator to check the run out of the Engine Assembly. Most of the vibration problems come from this. The run out should be no more than 0.004 inch (0.10 mm).
  • Page 48 Sensor Installation Use the 4 x 6mm screws and the 4mm flat locknuts to attach the sensor to the mount. Before tightening slide the sensor up so it is high in the slots. Next attach the sensor and mount to the engine with the provided spacers as shown below.
  • Page 49 Mount the fan and Hub Slip the lower engine collet onto the engine shaft and follow with the hub/fan assembly. Insert the upper engine collet into the hole in the top of the hub. Slide the Nord lock set (Nord lock washers come in matched sets of 2) onto the 6 x 25mm Hex head bolt and insert down through the collets and hub and carefully tighten down.
  • Page 50 Attach Clutch The clutch is attached hollow side up with two 3 x 8mm SHCS. HHI4M08 QD635 If the clutch is a tight fit in the hub be sure to pull it down evenly by alternating turns on the screws. Page 50 of 105...
  • Page 51 2-9 FAN SHROUD ASSEMBLY Bag# Description Step 2-8 Engine In Box Fan Shroud M3x5x1 Spacer M2.5x10 Cap Head Bolt M3x7 Flat Washer M4 Well-nut M4 Well-nut Brass Insert Rubber U Channel 9***** CA Glue Run the Rubber U Channel along the center hole of the Fan Shroud and then apply CA glue onto it.
  • Page 52 2-11 ENGINE INSTALLATION Bag# Description Step 2-10 Step 2-10 Assembly Step 2-9 Step 2-9 Assembly Frame Rear Frame Frame Upper Doublers Frame Lower Doublers M4x18 Cap Head Bolt M4x10 Cap Head Bolt M4x10 Flat Washer It is recommended to use M4 Finishing Caps and/or M4 Nord-Lock Washers instead of M4x10 Flat Washers.
  • Page 53 2-12 FRAME ANGLE ASSEMBLY Bag# Description Outer Molded Spacer Inner Molded Cross Member M3x45 Cap Head Bolt M3x8 Cap Head Bolt Frame Frame Angle M3x10 Cap Head Bolt M3 Locknut M3x100 Cross Member M3x12 Cap Head Bolt Loctite HHI3M45C HHI3M08C Page 53 of 105...
  • Page 54 Note: If the pull starter is used, do not install the crossmember which is underneath the engine. Put two M3x12 Cap Head Bolts and two M3 Locknuts in the place of that crossmember. Put the pull starter back now. You may have to squeeze the pull starter a little to get it in. Page 54 of 105...

  • Page 55: Section 3: Landing Gear Assembly

    SECTION 3: LANDING GEAR ASSEMBLY Bag 3 These dampers will help greatly when landing. Page 55 of 105...
  • Page 56 • Install the Main Frames onto the Landing Gear Assembly and secure them with four M3x14 Cap Head Bolts and four M3 Lock Nuts. Note: It is recommended to use “Landing Gear Dampener” to reduce vibration. See “Other Hardware & Optional Accessories” to make order. Landing Gear Dampener is installed between the Landing Gear and the Landing Supports.

  • Page 57: Section 4: Driving System

    SECTION 4: DRIVING SYSTEM Bag 4 Page 57 of 105...
  • Page 58 4-1 MAIN GEAR ASSEMBLY Bag# Description Description 88T Main Gear Auto Hub Ring Auto-rotation M3x10 Cap Head Bolt Lower Main M3x6 Cap Head Bolt Main Gear *Main Gear Spacer may be one piece or stacking up of two pieces of composite material. QD601 QD654A QD751...
  • Page 59 4-2 MAIN GEAR INSTALLATION Bag# Description Bag# Description Step 4-1 Main Gear Assembly M3x30 Cap Head Bolt Step 3 Assembly up to step 3 M3 Locknut Main Shaft M3X5 Set Screw Main Shaft Collar • Bring the Main Gear Assembly in; slide the Main Shaft down through Upper Bearing Block, Main Shaft Collar (make sure the ridge is toward the Upper Bearing Block), and Lower Bearing Block, then secure with one M3x30 Cap Head Bolt and one M3 Locknut.

  • Page 60: Section 5: Tail Assembly

    SECTION 5: TAIL ASSEMBLY Bag 5 Page 60 of 105...
  • Page 61 5-1 TAIL PULLEY GEAR ASSEMBLY Bag# Description Tail Output Shaft Tail Pulley Gear M3x5 Set Screw M5x7x2 Spacer QT557 QT312 QT356 HHI3M05SS QT312 Page 61 of 105...
  • Page 62 5-2 TAIL ROTOR ASSEMBLY Description Bag# Description Tail Case Side Plate M3x5x1 Spacer Tail Pitch Lever M3x16 Cap Head 5X10X4Flange M3 Locknut M2x6 Phillips Screw Step 5- Tail Pulley Gear Tail Boom (in Box) M3x7 Pivot Ball Stud Timing Belt (in Box) M3x7 Flat Washer M3x6 Cap Head Bolt M3x25 Cap Head...
  • Page 63 Install Hand sand if the Bearings necessary. You may into the Tail use a rounded Case Side needle file Plates. The flanges should be inside. Sometimes, the holes are too tight; you have to sand them a little bit. QT363 Page 63 of 105...
  • Page 64 QT352 QT305 QT312 QT322 QT655 HHI3M25C QT323 HHI2021 QT356 QT665A QT312 QT320 QT321 QF107 QT350C QT151A QT350 Note: Normally you just need one M3x5x1 Spacer between the Tail Pitch Control Lever and Tail Pitch Lever Mount but you may need two of them in some cases (if you do not have enough clearance for the lever.) Page 64 of 105...
  • Page 65 5-3 TAIL BLADE ASSEMBLY No. Bag# Description Bag# Description Tail Rotor M3x22 Cap Head Bolt Tail Blade M3 Locknut Tail Blade Spacer M3x5 Set Screw Shim Ball* Spherical Link Spacer** M2x8 Phillips Screw* M2x12 Cap Head *Sport version only **Pro version only The Tail Rotor shown may look lightly differently from the one in the kit.
  • Page 66 Slide the Tail Blade Assembly into the Tail Output Shaft then secure it with two M3x5 Set Screws. Connect the Ball Links to the Shim Balls. Loctite Page 66 of 105...
  • Page 67 5-4 FIN INSTALLATION Bag# Description Horizontal Fin* Vertical Fin* Horizontal Fin Mount Part A Horizontal Fin Mount Part B Vertical Fin Mount Part A Vertical Fin Mount Part B M3x8 Cap Head Bolt 8***** Electric Tape *Carbon Fin Set is also available for upgrade. Wrap electric tape around the boom couple times where you are going to install the fin mounts.
  • Page 68 5-5 TAIL INSTALLATION Bag# Description Assembly up to step 4 Step 5-4 Tail Assembly In box Boom Support Rod Boom Support End M3x12 Cap Head Bolt M3x8 Cap Head Bolt M3 Locknut 8***** CA Glue • Wrap three or four rounds of electric tape around the end of Boom where the Boom Holders are going to touch it.

  • Page 69: Section 6: Control Systems

    SECTION 6: CONTROL SYSTEMS Bag 6 QC105 QC352 QC351 QC358 Page 69 of 105...
  • Page 70 6-1 SWASHPLATE ASSEMBLY Bag# Description Swashplate M3x7Pivot Ball M3 x7 Flat M2X4 Phillips Note: There are some kinds of the Swashplate. One has little M2 Tap holes on the Swashplate (maybe 7, 4, or 3 of them.) The others have no hole on it. Both work the same. If you got the one with holes, just fill them with M2x4 Phillips Screws.
  • Page 71 Loctite all screws and pivot ball studs Page 71 of 105...
  • Page 72 6-2 WASHOUT ASSEMBLY Description N Ba Description Washout M3x5 Set Screw Washout M3x7Pivot Ball Stud Washout M3x12 Cap Head Bolt Washout M3X5X1 Spacer Loctite all screws and pivot ball studs Note: There are some versions of the Washout Base (Item No. 1). All of them work the same but they should be installed appropriately: •...
  • Page 73 6-3 CONTROL SYSTEM INSTALLATION Bag# Description Swashplate Step Washout Step Assembly Swash Anti- Connect the Washout Links to the 3x7 Pivot Studs on the Swashplate. Page 73 of 105...

  • Page 74: Section 7A: Rotor Head Sport Version

    SECTION 7A: ROTOR HEAD SPORT VERSION Bag 7 7A-1 MAIN ROTOR HUB ASSEMBLY Bag# Description Bag# Description Main M3X5X3 Pitch Arm Head Center Thrust Hiller Arm 8x16x5 Head M4 Flange Dampener 8x16x5 M3x7 Pivot M3x12 M3x10 (*) or four M3x4 Pivot Ball Studs; two M3x14 Cap Head Bolts. Note: Some Center Hubs are designed for one O-ring each side.
  • Page 75 7A-2 FLYBAR & SEESAW ASSEMBLY Bag# Description Seesaw Seesaw collar M3 x 8 Cap Head Bolt Fly-Bar Control Arm Base Fly-Bar Control Arm M2.5 x 8mm SHCS In box 4mm Flybar 4mm Fly-Bar Paddle • There are two holes in the paddles. For regular setup, use the hole that is further from the letter “Quick”...
  • Page 76 7A-3 ROTOR HEAD INSTALLATION Bag# Description Step Completed Step Assembly M3x22 Cap M3 Locknut Install the Head Assembly into the Main Shaft, and then secure it by one M3x22 Cap Head Bolt and one M3 Locknut. Use Loctite it is very important this Use white HHI5M08C...

  • Page 77: Section 8: Linkage Rods And Settings

    SECTION 8: LINKAGE RODS AND SETTINGS Bag 8 Page 77 of 105...
  • Page 78 8-1 RUDDER PUSH ROD INSTALLATION Bag# Description Rudder Rudder Pushrod Shim Ball M2x8 6***** Servo Arm 7***** M3 Servo 2.3mm 9***** CA Glue 10***** Electric The diameter of the Pushrod Guide Clamp-on is a little bit bigger than the diameter of the boom.
  • Page 79 8-2A LINKAGE ASSEMBLY SPORT VERSION Bag# Description 2.3 Long 2.3x25mm 2.3x45mm 2.3x70mm 2.3x100mm 2.3x115mm Rod Assembly: All the Linkages should be assembled with dimensions measured center to center as following: Center 2.3x25mm 47 mm 2.3x45mm 67 mm 2.3x45mm 71 mm 2.3x70mm 88 mm 2.3x100mm...
  • Page 80 QP150A Page 80 of 105...
  • Page 81 Page 81 of 105...
  • Page 82 8-2B LINKAGE ASSEMBLY PRO VERSION There are two types of linkage rods you will construct: • Regular linkage rod: constructed by two ball ends and one metal rod. • Carbon Bag# Description linkage rod: 2.3 Long Ball End constructed by two 2.3 Medium Ball End ball ends, two rod 2.3 Short Ball End...
  • Page 83 Note: The lengths of Linkages are used for reference only. Final adjustments will be needed when you do radio setup. HHI4070E How to assemble a carbon linkage rod: First screw Ball End into the Rod End about 7mm. Apply CA glue at the ends of the rod. Insert the rod all the way in the Rod End. Use a piece of cloth to wipe off any excess glue.
  • Page 84 Page 84 of 105...
  • Page 85 Page 85 of 105...
  • Page 86 8-3 MUFFLER INSTALLATION Bag# Description Qty. 1***** Muffler 2***** M5x14 3***** Muffler Gasket Note: It is very important that Loctite (Red Loctite 626 recommended) is applied on the M5x14 Cap Head Bolts. Page 86 of 105...
  • Page 87 Nord Mount and screws Locks come with muffler. Note Muffler Gasket for cylinder head. You may use a little Permatex etc. to hold the gasket in place while you attach the muffler. HHI5M14 TK4005 Note: Muffler shown is just for illustrated purpose. Other mufflers may be used as well. 8-4 MAIN BLADE INSTALLATION Bag# Description...
  • Page 88 Page 88 of 105...
  • Page 89 8-5 KILL SWITCH & SPARK PLUG SHIELDING Bag# Description 1***** Engine Kill 2***** Male 3***** Ring M4x10 5***** Electric 6***** Spark Plug Install the Engine Kill Switch as following diagram. See drawing in next page to see where to put it on. Cut Electric Wire about 5cm long. Connect one end of the wire to the Male Connector. The Male Connector goes to female connector on the Black Lead of the engine.
  • Page 90 8-6 RADIO SETUP Bag# Description Step Helicopter ***** Radio ***** Receiver ***** Gyro ***** Battery for Before setting up the radio, you have to install the receiver, gyro, and batteries for your helicopter. See your radio, receiver, and gyro manuals for how to hook up. Instead of giving you the exact length of each linkage rod we will explain to you what you are trying to achieve.
  • Page 91 First, set your radio so that all travel values are at 100%. If you have a radio with Swash Mixing set, set those values to 50% (Aileron, Elevator, and Pitch.) Then use servo reversing so that all servos are moving in the right direction.
  • Page 92 Picture 5, Tail Center Picture 6, Tail Positive Thrust Picture 7, Tail Negative Thrust Picture 8, Tail Page 92 of 105...
  • Page 93 Pitch Travel Setup Collective Normal Aerobatic Position Flying Up (100%) Center (50%) Down (0%) Throttle Curve Setup Electric Fuel (non governor mode) Collective Position Normal Normal Aerobatic Aerobatic Flying Flying Up (100%) 100% 100% Center (50%) Down 100% (0%) First adjust servo arm position like you did with the swash, make sure your trim and sub-trim values are centered.
  • Page 94 adjust the max climb rpm by reducing throttle. There are other ways of achieving this by using cyclic mixing, however we will stay away from this for now. Follow the pitch guidelines in the table above, and if you need more pitch at max power because the rpm is increasing, then add pitch. 10 is just a guideline and will work in most setups, but a powerful motor or a light helicopter might need more.
  • Page 95 Page 95 of 105...
  • Page 96 Page 96 of 105...
  • Page 97 PRE-FLIGHT CHECKS • The rotor flybar and shaft must be straight. • The flybar and control paddles must tilt in the proper direction and operates smoothly throughout the whole range. • Check the swashplate to make sure it move smoothly and clean. •...

  • Page 98: Warnings

    WARNINGS • Do not operate helicopters in rainy, windy, or snowy condition. • Operate helicopter in a safe zone away from crowds, traffic, or distractions. • Use the proper batteries to prevent damage to the motor and equipment. • Make sure all the batteries are fully and properly charged and the fuel tank is full. •...

  • Page 99: Adjustments

    ADJUSTMENTS Tracking Adjustment: The tips of the main rotor blades should follow the same path when they rotate. We call the main rotor blades are in track. (a) Rev up the motor until the helicopter becomes light on its landing gear. Raise throttle gently and gradually...

  • Page 100: How To Hover

    • Rolls to the left, move the button to R • Rolls to the right, move the button to L (c) If the helicopter nose goes down or up, then: • Goes up, move the stick to U • Goes down, move the stick to D HOW TO HOVER Basic maneuver for a pilot is learning how to hover a helicopter.
  • Page 101 (c) Now, increase the throttle/collective gently to lift the helicopter landing gear off the ground to no more than 4 inches (10 cm). At the beginning, it is very difficult for the pilot to keep the helicopter from moving. It will also be difficult to know if the helicopter is in trim or not for a beginner. Keep going on the practice close to ground you will develop your skills.

  • Page 102: How To Fly Forward

    HOW TO FLY FORWARD Once you have mastered hovering fight: (a) Let’s begin the exercise of changing positions by practice moving the helicopter to the left or right slowly from 60 inches (1.5 m) above the ground. Hovering at 60 inches Page 102 of 105...
  • Page 103 (b) Once you have been comfortable with all the movements and controls in the previous step, start using some tail rotor control to make the helicopter point slightly to the left or right as you fly it to the left or right. Keep practicing the figure-eight path as shown below, you will master all basic control movements of a helicopter.

  • Page 104: After Flight Checks

    AFTER FLIGHT CHECKS After each flight, the helicopter should be thoroughly inspected: (a) Unplug the batteries. (b) Check every bolt, nut, and screw to make sure none has loosened due to vibration. (c) Check every rotating and movable part like head rotor, swashplate, tail rotor, to ensure they still move smoothly and properly.
