OPERATION PANEL

9
8
1
POWER ON / OFF Button
2
INTELLIGENT MODE Button, Indicator Light (White)
3
CLEAN ION SHOWER Button, Indicator Light (White)
Plasmacluster Ion SPOT Button,
4
Indicator Light (White)
5
HUMIDIFY ON / OFF Button, Indicator Light (White)
6
MODE Button, Indicator Light (White)

FRONT DISPLAY

8
7
Humidity / Temperature Monitor
Indicates the approximate humidity level or tem-
perature in the room. The humidity setting cannot be
adjusted.
Humidity 20% to 90% is displayed.
20%
or less
1
o
Temperature 0
C to 50
-1
o
C
or less
Wattage Monitor
Indicates wattage by current operation.
Timer Monitor
Indicates setting time or remaining time of ON/OFF
timer.
2
Plasmacluster Ion Light (Blue)
Humidify Light
Green
Humidity ON
3
Off
Humidity OFF
Red(Flashing)
Unit needs water
Press the button with "
" to start.
10
7
6
5
6
5
90% or
more
o
C is displayed.
o
50
C or
more
E-6
UA-HG40E
4
3
2
ON / OFF TIMER Button, Indicator Light (White)
7
<Press 3 sec.> FILTER RESET Button
DISPLAY SELECT Button
8
<Press 3 sec.> CHILD-LOCK Button
9
CHILD-LOCK Indicator Light (White)
10
FILTER RESET Indicator Light (Orange)
11
Light Sensor
9
4
3 2
Patrolling Light (Green / Orange / Red)
4
(Ref.E-9, E-10)
Odour Light (White)
5
Indicates the Odour Sensor detects odours.
Dust Light (White)
6
Indicates the Dust(sensitive) Sensor detects usual
dust.
PM2.5 Light (White)
Indicates the Dust(sensitive) Sensor detects micro-
7
scopic dust. (particulate matter less than 2.5 mi-
crons)
8
Motion Sensor
(UA-HG60E / UA-HG50E)
Cleanliness Monitor
Indicates the air purity of the room in 7 levels with
colour changes.
9
Blue
Red
Clean
Impure
11
1
Front Louver
1
(UA-HG60E / UA-HG50E)
