USA
SERVICE OFFICE
Dometic Corp.
509 So. Poplar St.
LaGrange, IN 46761
(260) 463-4858
CANADA
Dometic Dist.
866 Langs Dr.
Cambridge, Ontario
CANADA N3H 2N7
(519) 653-4390
For Service Center
Assistance Call:
800-544-4881
This manual must be read and un-
derstood before installation, adjust-
ment, service, or maintenance is per-
formed. This unit must be installed
by a qualified service technician.
Modification of this product can be
extremely hazardous and could re-
sult in personal injury or property
damage.
INSTALLATION
INSTRUCTIONS
Form No. 3308443.005 12/03
(French 3308444.003)
©2003 Dometic Corporation
LaGrange, IN 46761
LA-03 MODEL AWNING INSTALLATION INSTRUCTIONS
A&E Systems
LATERAL ARM
AUTOMATIC AWNING
INSTALLATION INSTRUCTIONS
810(XX)*(XX)**.000U
MODEL SERIES AWNING
Replace (XX)* with color
Replace (XX)** with length
WARNING
!
RECORD THIS UNIT INFORMATION FOR FUTURE
REFERENCE:
Model Number
Serial Number
Date Purchased
LA-03
FOR
!
Lire et comprendre ce manuel avant
de procéder à l'installation, à des
réglages, de l'entretien ou des
réparations. L'installation de cet
appareil doit être effectuée par un
réparateur qualifié. Toute modification
de cet appareil peut être extrêmement
dangereuse et entraîner des blessures
ou dommages matériels.
810(XX)*(XX)**.000U
Important:
stay with unit. Owner read carefully.
1
AVERTISSEMENT
MODEL
Prod No.
958303540
Instructions must
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dometic LA-03
Summary of Contents for Dometic LA-03
-
Page 1: Installation Instructions
LA-03 MODEL AWNING INSTALLATION INSTRUCTIONS RECORD THIS UNIT INFORMATION FOR FUTURE A&E Systems REFERENCE: Model Number Serial Number Date Purchased LA-03 LATERAL ARM AUTOMATIC AWNING INSTALLATION INSTRUCTIONS SERVICE OFFICE Dometic Corp. 810(XX)*(XX)**.000U 509 So. Poplar St. LaGrange, IN 46761 (260) 463-4858... -
Page 2: Safety Instructions
This is the safety-alert symbol. When you see this 1. GENERAL INSTRUCTIONS symbol in this manual, be alert to the potential for The A&E LA-03 awning is designed and intended for use on Class A and higher motorhomes with straight sides. The personal injury. - Page 3 LA-03 MODEL AWNING INSTALLATION INSTRUCTIONS (1) Sensor Wind (1) Crank, Hand FIG. 1 Required parts installer supplied (3) Screws, #10 Stainless Plate, Backup (See specification chart) (1) Cable, Flat 4 Conductor-Max. 18' Awning (2) RJ-11 Terminal Requires 10” (1) Box, Outlet Type FS-Outdoor...
-
Page 4: Installation Procedure
LA-03 MODEL AWNING INSTALLATION INSTRUCTIONS b. Solid structure in the coach wall for mounting of the 4. INSTALLATION PROCEDURE mounting bracket plates is required and for supporting a. The mounting bracket plates must be installed at the the awning weight. (Mounting Bracket Location Chart same height horizontally with respect to each other. - Page 5 LA-03 MODEL AWNING INSTALLATION INSTRUCTIONS Note: Prior removal of the 2 set screws out of the locking d. Place the tip of the silicone tube behind the gasket and mechanism makes their installation easier. apply a generous bead between it and the side wall. See d.
- Page 6 LA-03 MODEL AWNING INSTALLATION INSTRUCTIONS c. Install a recessed AC outlet box (FS type outside water Place the cover with the connector plug and gasket on the junction box and tighten the screws. tight, not supplied). The electrical outlet box cover must g.
- Page 7 Turn the wind sensor switch to the "OFF" position and wait till the ambient tempera- ture is above 30° F. and turn switch back “ON”. If alarm is still sounding contact a Dometic Service FIG. 11 Center or a qualified service technician for assis- tance.
- Page 8 LA-03 MODEL AWNING INSTALLATION INSTRUCTIONS 9. INSTALLATION OF REMOTE SWITCH a. Coach should be parked on a flat and level surface, The remote switch can be located at any convenient loca- such as a concrete garage floor. tion to operate the awning from inside of the vehicle. A com- b.
- Page 9 LA-03 MODEL AWNING INSTALLATION INSTRUCTIONS Adjust the set screw in each of the rafter brackets until tend as the adjustment is made. See FIG. 17. the awning rail is level. See FIG. 15. Note: The left limit adjustment is above the lip on the front cover and hard to locate.
- Page 10 LA-03 MODEL AWNING INSTALLATION INSTRUCTIONS Remote CONNECTION WIRING DIAGRAM Switch FIG. 19 EXTEND Green (Bezel and Decal Brown User Supplied) Yellow RETRACT Pig Tail to Remote Switch Pig Tail to Ignition Yellow Isolator Green Brown + 12 VDC When Ignition Is On...
