- Page 1 240V 30A Load Controller ® INSTEON 240V 30 Amp Load Controller (Dual-Band) Model : 2477SA1 (Normally Open) 2477SA2 (Normally Closed)
-
Page 2: Table Of Contents
Removing the X10 Address ........................10 ABOUT INSTEON ............................10 Using Dual-Band INSTEON Devices to Upgrade Your Network ............. 10 Important Note about INSTEON Networks; Split Single-Phase vs. 3-Phase Installation......11 Further Enhancing Reliability ........................11 ADDITIONAL RESOURCES ........................11 TROUBLESHOOTING .......................... -
Page 3: About 240V Load Controller
Load Active LED Key 240V Load Controller Features • After installation, setup is easy – installs and links to other INSTEON devices in minutes • Controls high-voltage appliances up to 240 Volts, 30 Amps, split-single phase (resistive loads only) •... -
Page 4: What Is Insteon
Reliable: every INSTEON device works as a network repeater, ensuring your commands will not be lost. • Affordable: INSTEON can be integrated into any number of devices easily and at a very low cost. An INSTEON home grows in value with each added INSTEON device, making life more convenient, safe and fun. -
Page 5: Installation
There are no user-serviceable parts inside. • Each 240V Load Controller is assigned a unique INSTEON I.D., which is printed on the device’s label. It is recommended that you prepare a list of all the devices you are installing, including their INSTEON I.D. and their location (e.g., 01.F7.G5, Mike’s bedroom light). -
Page 6: Installing 240V Load Controller
The 240V Load Controller Status LED will be solid green when the load is on and solid red when it is off. See the following table for the Load Active LED status: 240V Load Controller Model (SKU #) Relay Status Active Status LED Open Normally Open Relay (#2477SA1) Closed Solid green Open Normally Closed Relay (#2477SA2) Closed with load on... -
Page 7: Controlling 240V Load Controller From An Insteon Controller
Linking an INSTEON Controller to 240V Load Controller To use 240V Load Controller as a responder to an INSTEON controller, follow these steps to link 240V Load Controller and the controller together. Refer to the controller’s Owner’s Manual for detailed instructions on how to properly install and link it to 240V Load Controller. -
Page 8: Controlling Insteon Responders From 240V Load Controller
Linking 240V Load Controller to an INSTEON Responder To use 240V Load Controller as an INSTEON controller, follow these steps to link 240V Load Controller and an INSTEON responder (the device you wish to control with 240V Load Controller) together. Refer to the responder’s Owner’s Manual for detailed instructions on how to properly install and link it to 240V Load... -
Page 9: Creating An Insteon Scene
INSTEON scenes are very easy to set up – just link more than one responder to the same On/Off or Scene button on a controller. Then, when you press any of the linked buttons on the controller, all of the INSTEON devices linked in the scene will respond as a group. -
Page 10: X10 Programming Options
Status LED turn on solid green if the load is on will will or solid red if it is off ABOUT INSTEON Using Dual-Band INSTEON Devices to Upgrade Your Network What are phases? Page 10 of 14... -
Page 11: Important Note About Insteon Networks; Split Single-Phase Vs. 3-Phase Installation
It is possible that some audio-video devices, computers, power strips, or other electrical equipment may attenuate INSTEON signals on the power line. You can temporarily unplug suspected devices to test whether the INSTEON signal improves. If it does, then you can plug in filters that will permanently fix the problem. ADDITIONAL RESOURCES... - Page 12 Relink 240V Load Controller to your controller, while Controller, but it does 240V Load Controller may the load is on. See Linking an INSTEON Controller to not turn on when I send be linked at its off state. 240V Load Controller.
-
Page 13: Specifications, Certification, And Warranty
240V Load Controller Owner’s Manual SPECIFICATIONS, CERTIFICATION, AND WARRANTY Specifications View specifications for 240V Load Controller (Normally Open) at: www.smarthome.com/2477SA1.html or 240V Load Controller (Normally Closed) at: www.smarthome.com/2477SA2.html Certification This product has been thoroughly tested by ITS ETL SEMKO, a nationally recognized independent third- party testing laboratory. -
Page 14: Limited Warranty
For repair or replacement during the warranty period, call the INSTEON Support Line at 800-762-7845 with the Model # and Revision # of the device to receive an RMA# and send the product, along with all other required materials to: Smarthome, Inc.
