- Page 1 ENARCO, S.A. AGUJAS CON MOTOR INTERNO ELECTRIC VIBRATING POKERS AIGUILLES A MOTEUR INTERNE RÜTTELLANZEN MIT INNENMOTOR Manual de instrucciones Instruction manual Manuel d'instructions Gebrauchsanweisungen MX-816-0903...
-
Page 2: Table Of Contents
INDEX INTRODUCTION VIBRATING POKERS CHARACTERISTICS USAGE CONDITIONS 3.1 WORK AREA 3.2 PERSONAL SAFETY 3.3 SERVICE 3.4 SPECIFIC SAFETY RULES OPERATION AND MAINTENANCE 4.1 GETTING STARTED 4.2 EXTENSION 4.3 INSPECTION 4.4 REGULAR MAINTENANCE 4.5 STORAGE 4.6 TRANSPORTATION LOCATING MALFUNCTIONS INSTRUCTIONS TO ORDER SPARE PARTS 6.1 INSTRUCTIONS TO ORDER SPARE PARTS 6.2 INSTRUCTIONS TO REQUEST WARRANTIES RECOMENDATIONS OF USE... -
Page 3: Introduction
INTRODUCTION Thank you for trusting the ENAR brand For the maximum performance of the equipment, we recommend to read carefully the safety recommendations, maintenance, and usage listed in this manual Defective parts should be replaced immediately to avoid major problems. -
Page 4: Vibrating Pokers Characteristics
VIBRATING POKERS CHARACTERISTICS M35AFP, M5AFP, M6AFP, M7AFP, M8AFP MODEL MP35AFP, MP5AFP, MP6AFP, MP7AFP TYPE Vibrating poker with motor in head working at 42 V 3-200 Hz. APPLICATION Compacting of concrete. CONNECTION CABLE TO 10 m length standard equipment, with plug CE type, and insulation CONVERTER 1 KV. -
Page 5: Usage Conditions
USAGE CONDITIONS WARNING! Read and understand all instructions. 3.1 WORK AREA KEEP your work area clean and well lit. DO NOT OPERATE power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. KEEP bystanders, children, and visitors away while operating a power tool. GROUNDED TOOLS MUST BE PLUGGED INTO an outlet properly installed and grounded in accordance with all codes and ordinances. -
Page 6: Service
CHECK for misalignment or binding of moving parts, breakage of parts, and any other condition that may affect the tools operation. If damaged, have the tool serviced before using. USE only accessories that are recommended by the manufacturer for your model. 3.3 SERVICE Tool service MUST BE PERFORMED only by qualified repair personnel. -
Page 7: Operation And Maintenance
OPERATION AND MAINTENANCE 4.1 GETTING STARTED Read item 3 USAGE CONDITIONS VIBRATING POKER CONNECTION TO CONVERTER The poker has sockets to connect the vibrating pokers. Firstly, connect the converter to the electrical supply; be sure that the connection is correct (specification and condition of cable according to standards of security). -
Page 8: Regular Maintenance
4.4 REGULAR MAINTENANCE Only an expert shall work on the electrical parts. Disconnect the vibrating poker of the converter before doing any maintenance In all maintenance operations, original parts will be used. Every 12 months of working a lubrication of the bearings of the vibrating pokers is recommended. -
Page 9: Storage
4.5 STORAGE Store the vibrating pokers in clean, dry and protected areas when it is not used for long periods. 4.6 TRANSPORTATION When transporting by vehicles, be sure the equipment is safe against slipping, overturning and blows. LOCATING MALFUNCTIONS Three phase 32 A Plug Cable to switch 4mm2 Cable to switch 4mm2 Cable to switch 4mm2... -
Page 10: Instructions To Order Spare Parts
INSTRUCTIONS TO ORDER SPARE PARTS 6.1 INSTRUCTIONS TO ORDER SPARE PARTS All spare parts request must include PART CODE NUMBER AS STATED IN THE PART LIST. We recommend to include ITEM´S MANUFACTURE NUMBER. The identification plate with manufacture and model number is located in the top part of the motor`s plastic frame. - Page 11 Do not push or force the vibrator against the reinforcement. Keep a distance of 7 cm minimum from the walls. Always remove the poker vertically with movements upwards and downwards so the concrete fills the empty space again. Do not switch off until you stop the vibration completely. Se speed of removing is approximately 8 cm per second.
- Page 12 ENARCO, S.A. ENARCO, S.A. Tfno. (34) 902 464 090 e-mail: enar@enar.es C/Tomás Edison, 19 (34) 976 144 578 Web: http://www.enar.es 50014 ZARAGOZA (34) 976 471 470 SPAIN...
