- Page 1 UGP-712 Vehicular swing gate operator INSTALLATION INSTRUCTION MANUAL PLATINUM ACCESS SYSTEMS™ www.BrushlessGateOpeners.com | (800) 878-7829 | Sales@BrushlessGateOpeners.com...
-
Page 2: Table Of Contents
Installation Instructions & Safety Information Manual UGP-712 UGP-712 Vehicular Swing Gate Operator Class I, Class II, Class III, and Class IV TABLE OF CONTENTS Parts Diagram ......................................2 Important Safety Instructions ................................3 Protection Against Entrapment ................................4 Use and Application .....................................5-6 Gate Operator Class Categories and Examples ..........................7 Mounting Instructions .....................................8... -
Page 3: Parts Diagram
Parts Diagram UGP-712 1. Cover 2. Gate Attachment 3. Intermediate Drive Arm 4. Manual Release Mechanism 5. Manual Release Key 6. Secondary Drive Arm 7. Primary Drive Arm with Hardware 8. Gearmotor Assembly 9. Casing with Hardware 10. Ball Bearing 11. -
Page 4: Important Safety Instructions
Important Safety Instructions UGP-712 WARNING: to reduce the risk of injury or death: 1. READ AND FOLLOW ALL INSTRUCTIONS. 2. Never let children operate or play with gate controls. Keep the remote control away from children. 3. Always keep people and objects away from the gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE. -
Page 5: Protection Against Entrapment
Protection Against Entrapment UGP-712 Usage Class Gate Operator Category Horizontal Slide, Vertical Lift, and Vertical Pivot Swing and Vertical Barrier (Arm) Primary type* Secondary Type* Primary Type* Secondary Type* B1, B2, or D A, or C B1, B2, C, or D... -
Page 6: Use And Application
Use and Application UGP-712 THE MODEL UGP-712 IS INTENDED FOR CLASS I AND CLASS II (RESIDENTIAL/LIGHT COMMERCIAL) UP TO 10 UNITS USAGE ON A VEHICULAR SWING GATE APPLICATION. a) Install the gate operator only when: 1) The operator is appropriate for the construction of the gate and the usage Class of the gate, 2) All exposed pinch points are eliminated or guarded. - Page 7 Use and Application UGP-712 i) For gate operators utilizing a non-contact sensor: 1) See instructions on the placement of non-contact sensors for each Type of application, 2) Care shall be exercised to reduce the risk of nuisance tripping, such as when a vehicle, trips the sensor...
-
Page 8: Gate Operator Class Categories And Examples
Gate Operator Class Categories and Examples UGP-712 READ AND FOLLOW ALL INSTRUCTIONS MANUAL BEFORE ATTEMPTING ANY INSTALLATION RESIDENTIAL VEHICULAR GATE COMMERCIAL/GENERAL ACCESS OPERATOR CLASS I VEHICULAR GATE OPERATOR CLASS II A vehicular gate operator (or system) intended for use in a home of one-to four single... -
Page 9: Mounting Instructions
Mounting Instructions UGP-712 NOTE: This type of installation DOES NOT reverse the gate all the way back to its limits when the sensors are obstructed. This is only to protect against entrapment and to comply with UL325. CONTACT SENSOR INSTALLATION: Only sensors compliant with UL 325 are recommended. -
Page 10: Manual Release Instructions
Manual Release Instructions UGP-712 MANUAL RELEASE INSTRUCTIONS In the event of failure or if there is no voltage: CUBIC6SBL: Insert the lock release key in the lock To block the door wings again: rotate the lock and rotate by 180o. Release any electric look. - Page 11 Mounting Instructions UGP-712 Step1, 2, 3, 4, 5, 6, 7, 8 2.56” Ø1.38” Ø1.38” R1.28” 16.6” 13.6” Upper Hinge min 2.56” Unit Casing Hinge Flexible To ECU Drain Pipe Main Board Metal Pipe STEP 1. Make sure the center of the upper hinge is 2.56” from the surface of the mounting pole. Weld it and secured it in place.
-
Page 12: Mounting Instructions
Mounting Instructions UGP-712 Digging Area 26.61”x14.48” GEARMOTOR 14.48” max 110° Step 3 STEP 3. Drawing the area that you need to put the unit. The Area should be at least 26.61” X 14.46” that mea- sure from the mounting surface of the mounting pole. - Page 13 Mounting Instructions UGP-712 STEP 6. Put on a flexible drain pipe from the unit chassis to where it can drain the water. Make sure the pipe has the proper angle to let water flow out from the chassis to outside of the chassis to prevent water accumu- lating inside of the chassis.
- Page 14 Mounting Instructions UGP-712 Step 10, 11, 12 STEP 10. Put some lubrication inside the Interme- diate Drive Arm D. Then put the ball bearing into this Arm D. Next put the arm D onto the hinge of the Chassis. STEP 11.
- Page 15 Mounting Instructions UGP-712 2.56” Ø1.38” Ø1.38” R1.28” 16.6” 13.6” Upper hinge needs to line up with unit casing hinge min 2.56” Electrical Box Unit needs to sit on at level Unit Casing Hinge Drainage Hose To Main Board Electrical Wires Step 14 STEP 14.
- Page 16 Mounting Instructions UGP-712 Limit Switch Cam Limit Switch Cam Limit Disc Limit Disc Right Right Limit Limit Switch Switch Drive Drive Left Left Limit Limit Switch Switch STEP 15. Adjusting the limit switches in the chassis to set the open limit and close limit.
-
Page 17: Edge Sensor (Contact Sensor) Installation
Edge Sensor (Contact Sensor) Installation UGP-712 WARNING - Not following these instructions may cause severe injury or death to persons. EDGE SENSOR (CONTACT SENSOR) INSTALLATION Secondary Entrapment Protection 3-Sided Edge Sensor 3-Sided Edge Sensor Safety Connector Loop Connector Edge sensor or like must be installed to reduce the 1. -
Page 18: Important Safety Instructions
Important Safety Instructions UGP-712 WARNING: to reduce the risk of injury or death: 1. READ AND FOLLOW ALL INSTRUCTIONS. 2. Never let children operate or play with gate controls. Keep the remote control away from children. 3. Always keep people and objects away from the gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE. -
Page 19: Maintenance Instructions
End users/home owners must call a qualified professional gate operator installer for programming changes, repairs and modifications. Although all Platinum Access Systems’ gate operators are virtually maintenance free to an end user/home owner, minimal maintenance is recommended to ensure a smooth operation of this unit. -
Page 20: Types Of Installations
Types of Installations UGP-712 STANDARD INSTALLATION RX - 4x0.5 mm² Description Transmitter Flashing light 24 V= Flashing light 115 V= Key selector Codified via radio control keyboard Magnetic loop detection device for traffic monitoring Control panel Foundation casing Level mechanism kit... -
Page 21: Installation: Electronic Controller Mounting
Installation: Electronic Controller Mounting UGP-712 The control box MUST be mounted within 5 feet of the gate operator. Mount the control box as high as possible for best radio reception. Make sure the control box is level. The control unit weight is approximately 28 lbs. -
Page 22: Electrical Installation
Electrical Installation UGP-712 WARNING: Verify the installation first to make sure everything is correct before connecting the power cable to the board. USE MIN . 14 AWG WIRE. FOLLOW ALL LOCAL ELECTRICAL CODES. Black To help protect the equipment from lightning and... -
Page 23: Installation: Primary/Secondary Connections
Installation: Primary/Secondary Connections UGP-712 The control board provides a connector for the secondary actuator unit and automatically synchronizes the secondary unit with the primary unit. Outside Inside Secondary Unit Primary Unit Simply connect the Secondary arm to its applicable position, IN for open inside or OUT for open outside. -
Page 24: Installation: Loop Rack
UGP-712 Installation: Loop Rack LOOP RACK INSTALLATION: Outside Twist Wire Outside the Loop 6 Twists/Foot Outside Safety Loop Rack (#GOC-LDR) Loop Until Its Connection to the Loop Rack Center Exit Safety Safety Safety Exit Center Loop Exit Center Center Inside Safety... -
Page 25: Installation: Selectable Features
DIP switch to ADV MLOK position. OPEN ON POWER FAIL: The Auto-Open feature in Platinum Access Systems Gate Operators enables the following functionality in the event of power failure: a. Open the gate in case of power failure (120 or 220 VAC). - Page 26 Installation: Selectable Features UGP-712 CLOSE TIMER: Close Timer Timer Feature when activated will close the gate automatically of a set number of seconds. This is adjustable from 3 to 60 seconds. LEAF DELAY: Leaf Delay An Overlap Delay has been provided for biparting gates that have an emblem or maglock for example.
-
Page 27: Installation: Selectable Features & Solar Installation
Installation: Selectable Features & Solar Installation UGP-712 FAIL SAFE/SECURE: Fail Safe/Secure On = Fail Safe Off = Fail Secure Battery Fail/Safety Output Detection Detection Normal Normal Secure Normal Fail Safe Low/OFF Normal Fail Safe Low/OFF Fail Safe Normal Normal Secure... -
Page 28: Installation: Selectable Features
Installation: Selectable Features UGP-712 - (Green) + (White) White Outlet & Receptacle White Reset Switch Black Solar Regulator (Black) Neutral “Out” (White) Earth Ground (Green/Yellow) Green Black Batteries Power Harness Plug www.BrushlessGateOpeners.com | (800) 878-7829 | Sales@BrushlessGateOpeners.com... -
Page 29: Installation: Accessory Connections
Installation: Accessory Connections UGP-712 ACCESSORY CONNECTIONS: To decrease the possibility of vehicle entrapment on the gate, vehicle loop detectors need to be installed. The edge sensor and the photo-electric beam can be used for secondary entrapment protection on every installation to prevent pedestrian or animal entrapment. These accessories must be UL325 compliant devices. - Page 30 Installation: Accessory Connections UGP-712 ACCESSORY CONNECTIONS (Continued): Radio Receiver Need to verify the proper connections before connecting the Radio Receiver. The maximum voltage that the control board / battery can provide is about 28V for external accessories. If there is an electrical shot in the power to the accessories, the control board will protect itself by shutting down and will remain shut down until the short is fixed.
-
Page 31: Guard Station
Installation: Accessory Connections UGP-712 ACCESSORY CONNECTIONS (Continued): Solenoid Connection The solenoid power connection must be provided an external power source. This will prevent damage to the battery in the event of a line power failure. Guard Station This will control the gate operator to Open, Stop, OPEN and Close the gate. - Page 32 Installation: Accessory Connections UGP-712 ACCESSORY CONNECTIONS (Continued): Locks Magnetic Lock (#PA-MAG13) Z-Bracket (Supplied with Lock Kit) (Supplied with Lock Kit) Green Black 24VDC White The Magnetic Lock power connection must be provided an external power source. This will prevent damaging the battery in the event of line power failure.
-
Page 33: Troubleshooting
Troubleshooting UGP-712 Gate does not open or close Check all motor connections to Check that the stop command is be fully engaged. not active. Check that the UL command Check that the vehicular loop Check that the radio command is (photo beam and/or edge sensor) detectors are working properly. - Page 34 www.BrushlessGateOpeners.com | (800) 878-7829 | Sales@BrushlessGateOpeners.com...
