- Page 1 User Manual...
- Page 2 Chauvet reserves the right to revise the content of this document without any obligation to notify any person or company of such revision, however, Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest version from www.chauvetprofessional.com...
-
Page 3: Table Of Contents
2 Ch..........................1 Ch..........................Configuration (Standalone) ................11 Static Mode ........................Auto Programs ....................... Master/Slave ........................Dimmer Profiles......................LED Frequency ......................Fan Mode ........................Back Light ........................System Information ......................Ovation P-56WW User Manual Rev. 4 TOC 1 of 2... - Page 4 Table of Contents Factory Reset......................... 5. Technical Information ..............Product Maintenance ..................13 6. Technical Specifications ............Photometrics Chart ..................15 7. Returns..................8. Contact Us .................. TOC 2 of 2 Ovation P-56WW User Manual Rev. 4...
-
Page 5: Before You Begin
If the box or the contents (the product and included accessories) appear damaged from shipping, or show signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. -
Page 6: Safety Notes
• In the event of a serious operation problem, stop using this product immediately! If your Chauvet product requires service, contact Chauvet Technical Support. Expected LED Lifespan LEDs gradually decline in brightness over time, primarily because of heat. LEDs that are arranged in clusters experience higher operating temperatures than single LEDs. -
Page 7: Introduction
NTRODUCTION Description The Ovation P-56WW is a bright, compact, silent par with exceptionally high CRI that is designed for theatrical and studio applications. This par product produces a homogenized, single-source, flat, even field of light with the same efficient warm white LED system found in the award-winning Ovation E-260WW ellipsoidal. -
Page 8: Product Overview
NTRODUCTION Product Overview Power 5-Pin DMX Menu In/Out Buttons 3-pin DMX In/Out Power In Fuse Bracket Gel Frame Holder Clip Gel Frame Tilt Adjustment Handle Page 4 of 18 Ovation P-56WW User Manual Rev. 4... -
Page 9: Product Dimensions
174 mm 8.15 in 6.65 in 207 mm 169 mm 4.72 in 120 mm 10.28 in 261 mm 17.76 in 451 mm 12.56 in 319 mm 7.52 in 191 mm Ovation P-56WW User Manual Rev. 4 Page 5 of 18... -
Page 10: Setup
DMX-compatible products with this product, you can control each individually with a single DMX controller. DMX Personalities The Ovation P-56WW uses a 3- or 5-pin DMX data connection for the 1 Ch, 2 Ch, 3 Ch, and 6 Ch DMX personalities. -
Page 11: Mounting
Procedure The Ovation P-56WW comes with a double-bracketed yoke to which you can either attach mounting clamps for hanging or simply use as a floor stand. You must supply the mounting clamps. Make sure the clamps are capable of supporting the weight of this product. Use at least one mounting point per product. -
Page 12: Alternate Lens Changing Procedure
ETUP Alternate Lens Changing Procedure The Ovation P-56WW has the ability to have different types of lenses installed. The interchangeable lenses allow the product to have alternate beam angles. To remove a lens: Pull knob up. Grab the Tab on the lens and pull it out of the fixture. -
Page 13: Operation
<DOWN> Navigates downward through the menu list or decreases the numeric value when in a function Control Options Set the Ovation P-56WW starting address in the 001–512 DMX range. This enables control of up to 85 products in the 6-channel 6 Ch personality. -
Page 14: Configuration (Dmx)
Go to the DMX Address main level. Select the starting address (001–512). The highest recommended starting address for each DMX mode is as follows: Personality Address 1 Ch 2 Ch 3 Ch 6 Ch Page 10 of 18 Ovation P-56WW User Manual Rev. 4... -
Page 15: Dmx Values
Auto programs allow for dynamic blinder effects without a DMX controller. Go to the Auto Show main level Select the desired auto program (Auto 1–3). Select the desired speed (1–100). The auto programs cannot be edited. Ovation P-56WW User Manual Rev. 4 Page 11 of 18... -
Page 16: Master/Slave
Select the desired option (Linear, Square, I Square, or SCurve). Dimmer Profiles This setting determines how fast the output of the Ovation P-56WW changes when you modify the output value. This setting provides four different options to simulate the dimming curve of an incandescent lighting product. -
Page 17: Technical Information
Softly drag any dirt or grime to the outside of the transparent surface. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Ovation P-56WW User Manual Rev. 4 Page 13 of 18... -
Page 18: Technical Specifications
I/O Connector Channel Range 3- and 5-pin XLR 1, 2, 3, or 6 Ordering Product Name Item Code UPC Number Ovation P-56WW 781462218485 781462218485 UL 1573 CSA C22.2 No. 166 E113093 Page 14 of 18 Ovation P-56WW User Manual Rev. 4... -
Page 19: Photometrics Chart
7.78 m 14.16 m 17.81 m 34.16 m 25 m 9.72 m 17.71 m 22.26 m 42.70 m 30 m 11.66 m 21.25 m 26.71 m 51.24 m Field Beam Field Ovation P-56WW User Manual Rev. 4 Page 15 of 18... - Page 20 4.25 m 1,670 15 m 2.89 m 6.38 m 20 m 3.85 m 8.50 m 25 m 4.81 m 10.63 m 30 m 5.78 m 12.75 m Field Beam Field Page 16 of 18 Ovation P-56WW User Manual Rev. 4...
-
Page 21: Returns
ETURNS ETURNS Send the product prepaid, in the original box, and with the original packing and accessories. Chauvet will not issue call tags. Call Chauvet and request a Return Merchandise Authorization (RMA) number before shipping the product. Be prepared to provide the model number, serial number, and a brief description of the cause(s) for the return. -
Page 22: Contact Us
Outside the US, UK, Ireland, Benelux, France, Germany, or Mexico, contact the dealer of record. Follow the instructions to request support or to return a product. Visit our website for contact details. Page 18 of 18 Ovation P-56WW User Manual Rev. 4...
