Introduction; Unpacking; Removing The Generator Cover - CPI CMP 200 Installation Manual

2
Installation
2.1.0

INTRODUCTION

This chapter contains instructions for unpacking and installing the CMP 200
generators. This chapter also describes the basic wiring and setup of the generator (console, X-ray tube,
AC mains, etc), allowing for initial power-up of the generator. This is followed by tube seasoning and auto
calibration.
2.2.0

UNPACKING

1. Inspect the shipping pack(s) for evidence of shipping damage.
•
The generator and the membrane control console (if applicable) are shipped in one pack.
•
The optional touchscreen console is shipped in a separate pack from the generator.
If there is evidence of shipping damage, note this in the event that a damage claim is justified.
Taking pictures of the damage is also recommended.
2. Remove the cardboard outer pack from the generator. See the cautionary note below before
removing the pack.
CAUTION:
3. Set aside the cardboard pack.
WARNING:
4. Remove and unpack the membrane control console, if included. This is strapped to the top of the
generator. Then carefully lift the generator from the pallet.
Remove and unpack the optional hand switch and the optional mini-console control unit, if
5.
included.
6.
If applicable, unpack the
7. Inspect all items for shipping damage, including loose hardware if applicable.
8. Unpack the manuals and any other paperwork that may be packed with the generator.
9. Keep the shipping packs. In case of shipping damage, place the unit(s) back in their shipping
pack(s) and notify the carrier and the customer support department as described in chapter 1 of
this manual.
2.3.0

REMOVING THE GENERATOR COVER

1. Remove and set aside the screws and washers securing the cover to the generator chassis.
2. Carefully lift the cover off the chassis.
Use and disclosure is subject to the restrictions on the title page of this CPI document.
Page 2-2
OPEN THE CARDBOARD PACK (S) CAREFULLY. SHARP TOOLS MAY DAMAGE
THE CONTENTS.
THE GENERATOR MAIN CABINET (WITH HV MODULE) WEIGHS APPROXIMATELY
135 POUNDS (61 KG). ONE PERSON SHOULD NOT ATTEMPT TO LIFT OR MOVE
THIS ASSEMBLY WITHOUT PROPER EQUIPMENT OR ASSISTANCE.
optional touchscreen console along with the base and console cables.

CMP 200 X-Ray Generator Service Manual
CPI Canada Inc.
 
and CMP 200 DR X-ray
Ch # 901476-02 Rev. P
