MSW WhiteBat Instructions

WhiteBat & RedBat LIGHT SET HLT-100 & TLT-001 INSTRUCTIONS
Thank you for your purchase! At MSW
accessories makes a good bike ride great. We hope these lights keep you both
visible and safe on the roads.
WARNING: CYCLING CAN BE DANGEROUS. BICYCLE PRODUCTS
SHOULD BE INSTALLED AND SERVICED BY A PROFESSIONAL MECHANIC.
NEVER MODIFY YOUR BICYCLE OR ACCESSORIES. READ AND FOLLOW ALL
PRODUCT INSTRUCTIONS AND WARNINGS INCLUDING INFORMATION ON THE
MANUFACTURER'S WEBSITE. INSPECT YOUR BICYCLE BEFORE EVERY RIDE.
ALWAYS WEAR A HELMET.
Consult your local law enforcement for ordinances and laws that pertain to
riding a bicycle at night. We strongly recommend using a front and rear light
as well as wheel and pedal reflectors when riding at night. The best way to
stay safe is to ride defensively.
For additional product and safety information go to: www.mswbike.com/safety.
COMPATIBILITY & INTENDED USE
The MSW WhiteBat and RedBat Light Set is designed to install on tubes that
are between 19 and 32mm in diameter (WhiteBat headlight) and between
19 and 40mm (RedBat taillight). These lights are intended to help keep you
visible to traffic while riding.

TOOLS REQUIRED

Flathead screwdriver or coin

INSTALLING THE BATTERIES

WHITEBAT HEADLIGHT
1. To install batteries slide battery cover to the rear of the light body
(see figure 1).
Push Open
2. Insert two AA batteries according to the polarity marking on the case,
then slide the battery cover and light body back together (see figure 2).
6400 WEST 105TH STREET // BLOOMINGTON, MN 55438 // 1-855-883-6563 // WWW.MSWBIKE.COM
15736 02/16
® we believe that having essential
Figure 1
Figure 2
REDBAT TAILLIGHT
1. Place a coin into the slot on the side of your light body and separate
the lens from the light body (see figure 3).
2. Insert two AAA batteries according to the polarity markings on the case and
then press the two halves of the light body back together (see figure 4).
Figure 3
Figure 4
