Data recorder and data reader for KISTOCK
KEY POINTS
- Compatible with wireless Kistocks, wired kistocks 2010 and previous
ranges
- Possibility to record up to 50 datasets
- Possibility to view real-time measurements from a kistock datalogger
TECHNICAL FEATURES
Storage capacity
Speed of data transfer
Operating temperature
Storage temperature
Radio span (in free field)
Frequency
Data storage
DIMENSIONS (mm)
Top view
•
80.8
Kattreppeln 28 • 38154 Königslutter •
dataloggers
500 000 points or 50 data sets
From kistock to data recorder : 400 values/second
From data recorder to PC : 1000 values/second
From 0 to 50°C
From-20 to +80°C
300 m
868 MHz
In the data recorder until downloading on PC
•
Front view
05353 / 9545 - 0 •
ELMTEC
KNT 310
•
Side view
57.4
05353 / 9545 - 45 •
FEATURES OF HOUSING
Weight
340 g
Display
Graphic display 128 x 128 pixels
Dimensions : 50 x 54 mm
Blue backlight
keypad
Metal-coated
5 keys and 1 joystick
Conformity
Electromagnetical compatibility
(as per NF EN 61326-1 standard)
Material
Compatible with food-industry
environment
Shock-proof ABS housing
Protection
IP54
Power supply
4 alkaline batteries 1,5V LR6
Environment
Air and neutral gases
Auto shut-off
Adjustable from 0 to 120 mn
info@elmtec.de
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kimo KNT-310
Summary of Contents for Kimo KNT-310
- Page 1 ELMTEC KNT 310 Data recorder and data reader for KISTOCK dataloggers FEATURES OF HOUSING KEY POINTS - Compatible with wireless Kistocks, wired kistocks 2010 and previous Weight ranges 340 g - Possibility to record up to 50 datasets Display - Possibility to view real-time measurements from a kistock datalogger Graphic display 128 x 128 pixels Dimensions : 50 x 54 mm Blue backlight...
- Page 2 Data downloading from a wireless kistock to data recorder ● Before downloading data stored from a kistock datalogger, this kistock has to registered in the data recorder. See kilog RF user manual to register a datalogger in the data recorder. Turn on the data recorder.
- Page 3 Discharge stored dataset from the data recorder to a computer ● Connect the data recorder on the base. ➢ Turn on the data recorder. ➢ Launch Kilog RF software. ➢ Select as communication support the data recorder. ➢ Click on “Transmit data” button. ➢...
- Page 4 Activate or deactivate beep : Go to “BEEP” line with up and down arrows then press OK. ➢ Select ON to activate or OFF to deactivate the beep of the keys. ➢ Press OK to validate. ➢ Activate or deactivate auto shut-off of the data recorder : Go to “Extinction”...
