Tools Required; Parts List; Pod Back; Pod Front - Scanstrut Scanpod Series Installation Instructions

Parts List

Pod Back

178113 620526
108111
x1 x1 x4
60535 190SPR-1
x1 x1

Bracing Plate

190SPH-5
60536
x1 x1
1
For ø25mm (1") tube: ø20mm (25/32") hole saw
For ø32mm (1 1/4") tube: ø25mm (1") hole saw
15-12-17 Issue D

Tools Required

x6
60548
x1

Pod Front

60546
x1 x4
60513 60549
x1 x4 x6
190SPR-1
4 x 620526
3
Jigsaw/Spiral 4 x
Saw
60546
4 x
Hole Saw ø20 or
25mm (25/23" or 1")
Power drill
Posidriv No. 3
Screwdriver
4mm Allen Key
3mm Allen Key
2
5
1 x 190SPH-5
7
R MIN 82mm
(3.23")
4
60513
6
Fully Tighten to lock 60535
& 60536
together
60535
60549
6 x
60548
6 x
