DPT-OA
Parts List
x4
M6x16mm
60617
x4
M10 Nylon Shoulder washer
64004
**APPLY BONDLOC B243 TO 6x M8x16mm**
610825
6x
60085
6x
60080
6x
60857
6x
ø50-70mm (2" - 2.75")
x2
Cable Grommet
101819
x1
Blanking Plug
101816
Satcom / Camera Plate
Radar Plate
101819
2x
Forward
22-01-18 Issue 2
x1
DPT gasket
19070
x1
Base Seal
19008
610816
6x
64026
6x
19070
Installation Instructions
Dual PowerTower®
Tools Required
Hole Saw
ø50-70mm (2" - 2.75")
Power drill
ø10.5mm (27/64") Drill Bit
8-10mm Flat Screwdriver
13mm Spanner
Parts Required
101816
Optional Light bar
64004
4x
(Bolts not supplied)
19008
M10 x 25mm+
x4
®
