  • Page 1 Quick Start Guide i.MX 8M Nano EVK...
  • Page 2 Display: MIPI-DSI IR Receiver Camera: MIPI-CSI Power Switch JTAG CPU Board Expansion Connector BOOT Switches C Connector Wi-Fi/BT Antenna USB MicroB Debug Port Type C Type C Ethernet Audio Port1 Port2 Lineout Figure 1: Top view i.MX 8M Nano EVK board...
  • Page 3 GET TO KNOW THE i.MX 8M NANO EVK CONTINUED MicroSD Card Connector Audio Board Connector Figure 2: Back view i.MX 8M Nano EVK board...
  • Page 4 Quick Start Guide GET TO KNOW THE i.MX 8M NANO EVK CONTINUED Mini SAS HDMI connector connector Figure 3: MIPI-DSI to HDMI Adaptor Card (included in the EVK) Note: (Color of the adaptor card may differ)
  • Page 5: Compute Module

    ABOUT THE I.MX 8M NANO EVK The i.MX 8M Nano applications processor is a member of the i.MX 8M family of products focused on delivering the latest and greatest media and machine learning experience combining state-of-the-art capabilities with high-performance processing optimized for low-power consumption.
  • Page 6: Getting Started

    The i.MX 8M Nano EVK (8MNANOD4- The following items in Table 2 are EVK) is shipped with the items listed in recommended to run the i.MX 8M Nano Table 1. Ensure the items are available in EVK. the EVK box.
  • Page 7 The following are available on the website: Table 3 Software and Tools ITEM DESCRIPTION • Schematics, layout and Gerber files • i.MX 8M Nano EVK Board Hardware User’s Guide Documentation • Quick Start Guide • Hardware Design Guide • Power Consumption Measurement...
  • Page 8: Setting Up The System

    The following will describe how to run If the serial port is not recognized, the pre-loaded Android image on the download and install updated drivers as i.MX 8M Nano EVK. listed in the section Debug Serial Console below. Confirm Boot Open the terminal window (i.e., Hyper...
  • Page 9 www.nxp.com SETTING UP THE SYSTEM CONTINUED Connect HDMI Connect Display Mouse The MIPI-DSI to HDMI accessory card and Connect the mouse to J301 (USB Type-C mini SAS cable are needed for evaluating Port1) through the USB Type-C to A HDMI. adapter.
  • Page 10: Additional Information

    Quick Start Guide ADDITIONAL INFORMATION Boot Switches SW1101[1-4] are the boot configuration switches, the default boot device is eMMC/ uSDHC3, as shown in Table 4. If you want to try other boot devices, you need to change the boot switches to corresponding values as listed in Table 4. Table 4 Boot Device Settings BOOT DEVICE SW1101...
  • Page 11: Warranty

    www.nxp.com ADDITIONAL INFORMATION CONTINUED Do more with Accessory boards MX8-DSI-OLED1: MINISASTOCSI: MIPI MINI-SAS OLED DISPLAY MIPI-CSI CAMERA MODULE Use this camera MIPI-CSI camera module for machine Use this OLED display for touchscreen support. vision, video streaming and recording . SUPPORT WARRANTY Visit www.nxp.com/support for a list Visit www.nxp.com/warranty for...
  • Page 12 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
