Ready to start hooking everything up? Check out the wiring diagram and hookup table below to see
how everything is connected.
Polarized
Pay special attention to the component's markings indicating how to place it on
Components
the breadboard. Polarized components can only be connected to a circuit in one
direction.
Wiring Diagram for the Experiment
Having a hard time seeing the circuit? Click on the wiring diagram for a closer look.
