Polarized
Pay special attention to the component's markings indicating how to place it on
Components
the breadboard. Polarized components can only be connected to a circuit in one
direction.
Wiring Diagram for the Experiment
Having a hard time seeing the circuit? Click on the wiring diagram for a closer look.
Note: The full sized breadboard power rails have a break down the middle. If you end up using the
lower half of the power rail you will need to jump between the upper end and lower end.
