4. Installation
4.1 Installation of Deadbolt
NextBolt User Manual
For support contact us a 1-800-408-7101 ext. 102
http://www.advancedactuators.com
A. Insert the deadbolt latch into the hole
in the edge of the door (follow the UP
sign), keeping it parallel to the face of
the door. Mark the outline of the face
plate and remove the deadbolt.
B. Then chisel 1/8‖ deep rectangular
shape, per your marking (or until the
faceplate is flush with the door edge).
C. Insert the deadbolt latch; make sure
the deadbolt UP sign is facing
upwards. Then fasten the screws.
9
