BitaTek Cyclops-II BTS 700 Settings Manual

Bluetooth scanner
Hide thumbs Also See for Cyclops-II BTS 700:
Table of Contents

Advertisement

Quick Links

Setting Guide
Version 1.0
September / 22/ 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cyclops-II BTS 700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BitaTek Cyclops-II BTS 700

Summary of Contents for BitaTek Cyclops-II BTS 700

  • Page 1 Setting Guide Version 1.0 September / 22/ 2014...

  • Page 2: Table Of Contents

    Table of Contents Device Descriptions ......................4 Operation Modes ........................ 6 Key Function Description ....................7 LED , Buzzer and Vibration ....................8 Bluetooth Connect Description ..................10 5.1. Specification ......................10 5.2. Data transfer via Bluetooth Under Batch mode ........... 10 5.3.
  • Page 3 9.2.3. SPP Communication Setting ..............39 9.2.4. Batch mode setting ................... 43 9.2.5. Barcode Data and Scanner Setting ............47 9.2.6. Alpha-Numerical Setting barcode ............69 Appendix 1 ....................... 74 Appendix 2 ....................... 75 Cyclops-II BlueTooth Scanner Configuration Guide...

  • Page 4: Device Descriptions

    1. Device Descriptions Scan Windo Bluetooth LED Scan LED Power LED SCAN Key FUNCTION Key Battery Strap Post USB Port & Reset button Table - 1 Item Descriptions Scan Window Scanner scans barcode via this window ( DO NOT SCRATCH or BLOCK ) Power LED Battery Status...
  • Page 5 Blue slow-blinking: Successful Connection USB Connection Status( Bluetooth Mode ) Blue ON: USB Connected Blue slow-blinking: Data Transmitting Press and hold more then 3 seconds： Power On Scan Key Press：Barcode Scan Function Key According difference mode it will have difference function, Please reference【3.

  • Page 6: Operation Modes

    2. Operation Mode This device have three action mode, the default action mode is real mode. The mode can be changed by scan setting barcode. But, the customer can not change the mode If the data file（data.txt）have some records not be send out . The description of mode, please see the follow table.

  • Page 7: Key Function Description

    3. Key Function Description The follow table descript the motion of the status and key function. Table – 3 Motion status Power Bath mode Real mode Hybrid mode Disconnect SPP Disconnect Scan Power — — — Key( press more then 3 seconds) Scan Key Bluetooth...

  • Page 8: Led , Buzzer And Vibration

    4. LED , Buzzer and Vibration The following table is description of the LED display and sound on the different issue. Data collect status Scan LED Vibration Battery Bluetooth Sound User good scan Green (50ms) Vibrate 100ms User bad Scan Red( 300ms) Bi, Bi, Bi (default 5s scan...
  • Page 9 Red Flash Battery Charging fail On ： 100 ms Off：100ms Battery Charging finish Green Red Flash Batter low On ： 200 ms Off：800ms Bluetooth Paring Quickly Blue Flash wait enter the PIN Quickly Blue Bi~, Bi~ until Flash paring ok or code when Bluetooth Time out paring ( 60 second...

  • Page 10: Bluetooth Connect Description

    5. Bluetooth Connect Description 5.1. Specification This BT700 is a wireless interface device, it is follow Bluetooth ver2.1+EDI Class II specification, include the SPP ( Serial Port Profile ) and HID ( Human Interface Device Profile) on this device, It must install the same profile on the paring device (ex. iPhone, iPad or PC ) too for Bluetooth communication.

  • Page 11: Spp Communication

    mode The customer can get the data that be saved under Batch mode by Bluetooth。 The BTS700 must change to Bluetooth data transfer mode, you can reference the「5.3 SPP communication」 Item Description How to transfer the Two method of transfer ...

  • Page 12: Host Command

    The data format of SPP transfer of BTS700 as follow for handshake with Host application： [Prefix][Digit][Data][Checksum][Suffix] Item Byte Value Description Number Prefix STX(0x02) The start bit of SPP communication. Digit The size of Data Data The scan data Check Sum The check sum of Data Suffix ETX(0x03) The Stop bit of SPP communication.
  • Page 13 [Start][Command][,][Response][End] Field Format Description Start The start character of response after executed host command. Command 1 ~ 8 The response after execute host command number. ， Separation Response The result after execute host command YYMMDDHHMM The date & time of BTS700 for host command 3 The battery status of BTS700 for host command 4...

  • Page 14: Hid Communication

    is data format NG , ex “201304312300”) Read Date of !3<CRLF> RE3, BTS700 will return date BTS700 YYYYMMDDHHMM & time according to host <CRLF> device. Power status !4<CRLF> RE4,F<CRLF> BTS700 will return RE4,M<CRLF> battery status to host RE4,L< CRLF> device. F is Full power M is Middle power L is Low power.
  • Page 15 After BTS700 connect with iPhone, iPad complete. ※ If BTS700 want connect with the iPhone, iPad of Apple product, the iOS of iphone , iPad must lately of version 5.0. ※ If BTS700 want connect with the product of Android smart phone, the OS of Android must lately of version 4.0.

  • Page 16: Usb Connect

    6. USB connect 6.1. Specification This device （BTS700）have a USB port , it will not support charge when you use USB cable to connect with BTS700 and PC host. Specification description Communication USB 2.0 Full speed  USB Mass Storage support. Spec ...

  • Page 17: The Data Format Of Data File

    Data.txt ：Under batch mode, the scan data will be saved to this file, if user use USB cable to connect between PC and BTS700, the user can read this file or delete this file. System.cfg ：This is a setting file of BTS700. When this file be updated, and repower on this device, the system will be start up and be set according this file.

  • Page 18: Usb-Hid Communication

    Termination record. 6.3. USB-HID communication Description Setting Setting Barcode Cord Change to Enable A114A0 USB-HID mode Change to Enable A114A1 Bluetooth mode If set “change to USB-HID mode” , after connect the USB cable , the device like a USB scanner .

  • Page 19: The Suitable Use Method

    7. The Suitable use method The user can follow the follow chart to select the best mode for use. Start The scan data must be save to memory and Selsect Batch mode doesn’t need pairing (reference 8.1 Batch mode setting) with smart phone or PC via Bluetootn? Use Bluetooth...

  • Page 20: Simple Setting

    8. Simple Setting The use choice the best mode according【7. The Suitable use method】 8.1. Batch Mode setting If the user want scan the barcode data and be saved into the memory of BTS700, please use Batch Action mode. The user can get the record of memory on the BTS700 by different method, according User setting.

  • Page 21: Data Transfer By Spp Slave Mode Situation

    Enter the physical Imput B001A address of BT module Communication Enter SPP A001B start Master mode Action mode setting Batch mode A014A2 Wait host command Start data A033A under Bluetooth transfer by communication Bluetooth communic ation ※please reference 【The Setting barcode about Bluetooth Device name of BTS700】of【9.2.1 System mode Setting】...

  • Page 22: Real Mode Setting Under Hid Communication

    8.2. Real mode setting under HID communication The BTS700 pairing with iPhone, iPad of Apple product or pairing with terminal host like Android smart phone、tablet、PC，and the BTS700 is a keyboard interface of those terminal host, Please use Real mode under HID communication. The real mode and HID mode are factory default mode of BTS700, so those host can quickly pairing with the BTS700.

  • Page 23: Real Mode Setting Under Spp Master Mode

    phone、PC) . please reference【5. Bluetooth Connect Description】 8.3.1. Real mode setting under SPP master mode Description Setting Setting Barcode Cord Enter the Input B001A physical address of BT module Communication Enter A001B start Master mode Action mode Real A014A1 setting mode please reference 【The Setting barcode about Bluetooth Device name of BTS700】...

  • Page 24: Hybrid Mode Setting Under Spp Master Mode

    communication Because out of the communication or other reason that the Bluetooth disconnect, in order to avoid the lost of data, the system will save the scan data into the data file of memory of BTS700 on the Hybrid mode, so Hybrid mode have higher dependability the Real mode. Once after the Bluetooth reconnect complete, the system in accordance with storing in the order in the storing device file, and then pass back and give the end a not host computer.
  • Page 25 Action mode Hybrid A014A3 setting mode Cyclops-II BlueTooth Scanner Configuration Guide...

  • Page 26: System Detail Setting

    9. System Detail Setting 9.1. Factory Default Setting BTS700 Factory Default setting as following tables. Item Default BTS700Action Mode Real Mode Communication Mode HID mode Device Name BTS700+last 4 digital of BT MAC Address Authentication Disable Encryption Disable “0000” PIN Code Power off time out 3 minutes Beep on Reconnect/Disconnect...
  • Page 27 ※ Setting ※ On the Real mode、Batch mode the “ACK/NAK handling of SPP communication setting” can be set enable / disable, The Hybrid mode must enable can not change to disable。 The default value of Batch mode as follow table。 Those setting will not influence about Real mode initial.
  • Page 28 EAN-13 / JAN-13 Enable Bookland EAN Disable Bookland ISBN Format ISBN-10 UPC/EAN supplemental (Add On) None UPC/EAN/JAN supplemental Combined AIM Code ID format UPC-A check digit Enable UPC-E check digit Enable UPC-E1 check digit Enable UPC-A preamble System UPC-E preamble System UPC-E1 preamble System...
  • Page 29 I2 of 5 convert to EAN13 Disable Discrete 2 of 5 Disable Chinese 2 of 5 Disable Matrix 2 of 5 Disable Matrix 2 of 5 check digital verify Disable Matrix 2 of 5 check digital transfer Disable Codabar(NW7) Enable CLSI Editing Disable NOTIS Editing...

  • Page 30: The Setting Barcode Of System

    PDF 417 Enable Micro PDF 417 Disable Code128 Emulation Disable Data Matrix Enable Data Matrix Inverse regular Decode Mirror Images(Data Matrix Auto only) Maxicode Disable QR code Enable QR Inverse Regular Aztec Enable Aztec Inverse Regular 9.2. The setting Barcode of System Having recorded the establishment bar code that this machine uses as follows, this machine is dispatched from the factory the setting up value and please reference [9.1 Factory Default setting], the user can scan the following establishment barcode to change the setting of BTS-600.

  • Page 31: Batch Mode

    nication A014A1 mode A002A Slave commu nication A014A1 mode A014A1 commu nication mode A003A ※ Please enter the physical address of BT module of the Host device first, when use SPP Master communication mode. Please reference【The Setting barcode about physical address of Bluetooth module】 Batch mode：...
  • Page 32 commun ication mode Data A002A transmis sion mode A014A2 under Slave commun ication mode Hybrid Mode： Descriptio Setting Setting Barcode Cord Hybrid A001B Mode Master Communi cation A014A3 mode SPP Slave A002A communic ation mode A014A3 ※ Please enter the physical address of BT module of the Host device first, when use SPP Master communication mode.
  • Page 33 and fast connect with host computer. The physical address of Bluetooth module is 12 digital, you can and only enter 0~9, A~F。 Please use barcode of 【9.2.6 Alpha-Numerical Setting barcode】to enter the physical address of Bluetooth module。 Description Setting Setting Barcode Cord Enter the Input...
  • Page 34 Description Setting Setting Barcode Cord ID Bluetooth Enable A009A Encryption setting Disable A009B The Setting barcode of PIN code The customer can enter 16 character for PIN code, you can and only enter 0~9, A~Z, a~z。 Please use barcode of 【9.2.6 Alpha-Numerical Setting barcode】to enter the PIN code。 Description Setting Setting Barcode...
  • Page 35 A004A4 minutes A004A5 minutes A004A6 minutes A004A7 minutes A004A8 minutes The Setting Barcode of Beep on Reconnect/Disconnect Description Setting Setting Barcode Cord The Beep on Enable A005A reconnect / disconnect setting Disable A005B The Setting Barcode of Beep for bad scan Description Setting Setting Barcode...

  • Page 36: Hid Communication Setting

    The Setting Barcode of Sound volume Description Setting Setting Barcode Cord The sound A010A0 volume setting A010A1 Middle A010A2 High A010A3 The Setting Barcode of restore Factory Default Setting Setting Barcode Cord ID Restore Factory default A012A setting 9.2.2. HID Communication Setting This is advanced establishment when Real mode under HID communicates。...
  • Page 37 For example, Scan the barcode Id 「 B019B」 first, then 「2」 、 「0」 、 「EOC」 , The Key Code is 『＃』 Please use barcode of 【9.2.6 Alpha-Numerical Setting barcode】to enter the additional characters。 HID termination character setting Description Setting Setting Barcode Cord ID Input B021A...
  • Page 38 The setting barcode for the association key code that will be sent while pushing Fn key Description Setting Setting Barcode Cord ID Normal Input B022A Function Key Code Setting under HID real mode setting Input B022B Function Key + Shift Code Key code Setting under...

  • Page 39: Spp Communication Setting

    200 ms A023A2 300 ms A023A3 500 ms A023A4 The setting barcode delay time between characters under BT communication Description Setting Setting Barcode Cord ID none A024A0 The delay time between characters of sending data A024A1 can be set. A024A2 A024A3 9.2.3.
  • Page 40 A007A2 A007A3 A007A4 A007A5 A007A6 A007A7 A007A8 The transfer data format setting under SPP communication When set up into Batch mode、 Hybrid mode, if still there are records to exist in Data.txt file in the memory of BTS700, The follow settings that can not be changed。 The setting barcode of Prefix The prefix setting must 2 digital word, and the word can only 0~9, A ~ F.
  • Page 41 Description Setting Setting Barcode Cord ID Digital Digital A019A Setting exist No Digital A019B Description Setting Setting Barcode Cord ID Checksum Checksum A019C Setting exist A019D Checksum The setting barcode of Suffix The suffix setting must 2 digital word, and the word can only 0~9, A ~ F. For example, Scan the barcode Id「B019A」...
  • Page 42 ACK /NAK Enable A020A of SPP communicati on setting Disable A020B The setting barcode for time out of ACK/NAK of SPP communication Description Setting Setting Barcode Cord ID 100 ms A020C1 Time out of ACK /NAK of SPP communicati 200 ms A020C2 setting 300 ms...

  • Page 43: Batch Mode Setting

    None A020D0 Retry cycle of ACK /NAK of SPP communicati 1 cycle A020D1 setting 2 cycles A020D2 3 cycles A020D3 The setting barcode for key code send when press Fn Key The Key code setting must 2 digital word, and the word can only 0~9, A ~ F. For example, Scan the barcode Id「B019A」...
  • Page 44 Time stamp Disable A027A0 Setting (_____# ____) ※_ is space Enable A027A1 (YYYY/ MM/DD# hh:mm:ss) ※ The “#” is a termination character, please reference 「Termination Character Setting」 on the following table Description Setting Setting Barcode Cord ； A028A1 Termination Character Setting Space A028A2...
  • Page 45 CRLF A026A5 A026A6 The Setting barcode for RTC time clock Description Setting Setting Barcode Cord ID Read RTC Start A034A date Setting Year：please set up 4 digital，Pleas use AD. Month：please set up 2 digital。 Date：please set up 2 digital。 Please use barcode of 【9.2.6 Alpha-Numerical Setting barcode】to enter the Date。 Description Setting Setting Barcode...
  • Page 46 Change Data setting Transmission Mode ※ This is same with press Scan + Fn Key Description Setting Setting Barcode Cord A038A1 Data transfer From top sequence setting Unsent data A038A2 only Description Setting Setting Barcode Cord Memory Enable A030A Initialization Setting After Data Disable...

  • Page 47: Barcode Data And Scanner Setting

    A029A Memory Initialization 9.2.5. Barcode Data and Scanner Setting Description Setting Setting Barcode Cord Disable A127A0 Pick list Enable A127A1 Disable A129A0 Fuzzy 1D Processing Enable A129A1 Disable A130A0 Decoding AIM Pattem Enable A130A1 Inverse 1D Regular A098A0 Only A098A1 Inverse Barcode Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 48 Auto A098A2 Code ID None A112A0 AIM Code A112A1 Symbol A112A2 Code ID UPC-A Disable A042A0 Enable A042A1 UPE-E Disable A043A0 Enable A043A1 UPE-E1 Disable A044A0 Enable A044A1 Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 49 EAN-8 Disable A045A0 Enable A045A1 EAN-13 Disable A046A0 Enable A046A1 Bookland Disable A047A0 Enable A047A1 Bookland ISBN-10 A048A0 ISBN format ISBN-13 A048A1 Decode Ignore A049A0 UPC/EAN supplemental Supplementals A049A1 Decode with supplemental Autodiscrimin A049A2 ate UPC/EAN supplemental A049A3 Enable smart supplemental mode Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 50 A049A4 Enable 378/379 supplemental mode Enable A049A5 978/979 supplemental mode Enable A049A6 414/419/434/ supplemental mode Enable 977 A049A7 supplemental mode A049A8 Enable 491 supplemental mode Supplemental A049A9 user-program mable Type 1 A049AA Supplemental user-program mable Type 1 and 2 Smart A049AB supplemental plus...
  • Page 51 UPC/EAN/J Separate A051A0 AN AIM Code ID format Combined A051A1 Separate A051A2 Transmissio UPC-A check Disable A052A0 Digital Transfer Enable A052A1 UPC-E check Disable A053A0 digital Transfer Enable A053A1 UPC-E1 Disable A054A0 check digital Transfer Enable A054A1 UPC-A None A055A0 preamble System A055A1...
  • Page 52 UPC-E None A056A0 preamble System A056A1 Country A056A2 code UPC-E1 None A057A0 preamble System A057A1 Country A057A2 code UPC-E Disable A058A0 convert to UPC-A Enable A058A1 UPC-E1 Disable A059A0 convert to UPC-A Enable A059A1 EAN-8 Disable A060A0 convert to EAN-13 Enable A060A1 Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 53 Disable A062A0 UCC Coupon Extended Code Enable A062A1 Coupon Old coupon A063A0 Report report New coupon A063A1 report Both A063A2 Coupon ISSN EAN Disable A064A0 Enable A064A1 Code128 Disable A065A0 Enable A065A1 GS1-128 Disable A067A0 Enable A067A1 ISBT 128 Disable A068A0 Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 54 Enable A068A1 Disable ISBT A069A0 Concatenation Enable A069A1 Auto A069A2 Disable Check ISBT A070A0 Table Enable A070A1 Code 39 Disable A071A0 Enable A071A1 Disable Trioptic Code A072A0 Enable A072A1 Disable Convert A073A0 Code39 to Code32 Enable A073A1 Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 55 Disable A074A0 Code32 Prefix Enable A074A1 Disable Code39 Check A076A0 Digit Verification Enable A076A1 Disable Transmit A077A0 Code39 Check Digit Enable A077A1 Disable Code39 Full A078A0 ASCII Enable A078A1 Code 93 Disable A079A0 Enable A079A1 Code 11 Disable A081A0 Enable A081A1 Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 56 Disable A083A0 Code11 Check Digit Verification One Digital A083A1 Two Digital A083A2 Disable Transmit A084A0 Code11 Check Digit Enable A084A1 Interleaved 2 Disable A085A0 of 5 Enable A085A1 I 2 of 5 Check Disable A087A0 Digit Verification USS check A087A1 digit A087A2 OPCC check...
  • Page 57 Disable A089A0 Convert I 2 of 5 to EAN-13 Enable A089A1 Disable Discrete 2 of 5 A090A0 Enable A090A1 Disable Chinese 2 of 5 A092A0 Enable A092A1 Disable Matrix 2 of 5 A093A0 Enable A093A1 Disable Matrix Check A096A0 Digit Verification Enable A096A1...
  • Page 58 Disable A099A0 Codabar(NW7 Enable A099A1 Disable CLSI Editing A101A0 Enable A101A1 Disable NOTIS Editing A102A0 Enable A102A1 Disable A103A0 Enable A103A1 Disable MSI Check A105A0 Digits Enable A105A1 Disable Transmit MSI A106A0 Check Digit Enable A106A1 Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 59 Disable A107A0 MSI Check Digit Algorithm Enable A107A1 Disable GS1-DataBar A108A0 Enable A108A1 Disable GS1 DataBar A109A0 Limited Enable A109A1 Disable GS1 DataBar A110A0 Expanded Enable A110A1 Disable Convert GS1 A111A0 DataBar to UPC/EAN Enable A111A1 Micro QR Disable A126A0 code Enable A126A1...
  • Page 60 Korean 2 of 5 Disable A132A0 Enable A132A1 US postnet Disable A133A0 Enable A133A1 US Planet Disable A134A0 Enable A134A1 Transmit US Disable A135A0 Postal check digital Enable A135A1 UK Postal Disable A136A0 Enable A136A1 Transmit UK Disable A137A0 Postal check digital Enable A137A1...
  • Page 61 Japan Postal Disable A138A0 Enable A138A1 Australia Disable A139A0 Postal Enable A139A1 Australia Auto A140A0 Postal Discriminat Format Raw Format A140A1 Alphanumer A140A2 ic Encoding Numeric A140A3 Encoding Netherlands Disable A141A0 KIX code Enable A141A1 USPS Disable A142A0 4CB/One code/Intelige nt Mail Enable A142A1...
  • Page 62 UPS FICS Disable A143A0 Postal Enable A143A1 GS1 DataBar Level 1 A144A0 Limited security Level Level 2 A144A1 Level 3 A144A2 Level 4 A144A3 Composite Disable A145A0 CC-C Enable A145A1 Composite Disable A146A0 CC-A/B Enable A146A1 Composite Disable A147A0 TLC-39 Enable A147A1 Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 63 UPC Never A148A0 Composite linked Mode UPC always A148A1 Linked Auto A148A2 Discriminat e UPC composite GS1-128 Disable A149A0 Emulation mode for UCC/EAN Enable A149A1 composite codes PDF 417 Disable A150A0 Enable A150A1 Micro PDF Disable A151A0 Enable A151A1 Code 128 Disable A152A0 Emulation...
  • Page 64 Enable A153A1 Data Matrix Regular A154A0 Inverse Inverse A154A1 Only Inverse A154A2 Autodetect Decode never A155A0 Mirror Image (Data Matrix only) always A155A1 Auto A155A2 Maxicode Disable A156A0 Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 65 Enable A156A1 QR Code Disable A157A0 Enable A157A1 QR Invers Regular A158A0 Inverse A158A1 Only Inverse A158A2 Auto Detect Aztec Disable A159A0 Enable A159A1 Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 66 Aztec Inverse regular A160A0 Inverse A160A1 Only Inverse A160A2 Auto Detect Redundancy Level 1 A161A0 Level Level 2 A161A1 Level 3 A161A2 Level 4 A161A3 Security Level 0 A162A0 Level Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 67 Level 1 A162A1 Level 2 A162A2 Level 3 A162A3 Inter Normal A163A0 character gap character size gap size Large A163A1 character gap size Decode Decode A164A0 Illumination Illumination Decode A164A1 Illumination Character No convert A165A0 string setting Convert all A165A1 letters to Upper case Convert all...
  • Page 68 Level 2 A166A1 Level 3 A166A2 Level 4 A166A3 Level 5 A166A4 Level 6 A166A5 Level 7 A166A6 Level 8 A166A7 Level 9 A166A8 Level 10 A166A9 All barcode A167A0 Symbologies Symbologie be disable s be disable A167A1 Symbologie s return to default Cyclops-II BlueTooth Scanner Configuration Guide...

  • Page 69: Alpha-Numerical Setting Barcode

    9.2.6. Alpha-Numerical Setting barcode This item is for input of Alpha Numerical setting. Descript Setting Barcode Code ID Stop Input Cancel Descript Setting Barcode Code ID Setting Barcode Code ID Numerical （ Include Hex） Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 70 Descript Setting Barcode Code ID Setting Barcode Code ID Alphabetic Letter Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 71 Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 72 Cyclops-II BlueTooth Scanner Configuration Guide...
  • Page 73 Cyclops-II BlueTooth Scanner Configuration Guide...

  • Page 74: Appendix 1

    10. Appendix 1 How to make the setting Code The code type of BTS700 setting code is Code128 The customer can make the setting code of BT drive address and BT device name by yourself. How to make the setting barcode of Bluetooth Driver Address Start Code Setting ID Address ( Alpha numerical )

  • Page 75: Appendix 2

    11. Appendix 2 About Key Code Function key is pressed during Real mode under HID connection, Function Key code Setting will set up the key code when press Fn key on the Real mode under HID communication. The Kye code for terminal host ( Android , iPhone, iPad ) as follow Key Code(Hex) Normal +Shift...
