BitaTek Cyclops 1D Settings Manual

Bluetooth data handheld scanner-reader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Setting Guide
Version 1.3
Oct / 15/ 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cyclops 1D and is the answer not in the manual?

Questions and answers

Related Manuals for BitaTek Cyclops 1D

Summary of Contents for BitaTek Cyclops 1D

  • Page 1 Setting Guide Version 1.3 Oct / 15/ 2015...

  • Page 2: Table Of Contents

    Table Of Contents Layout Descript ........................4 Action Mode........................6 Key Function Description ....................7 LED Display and Buzzer....................8 Bluetooth Connect Description ..................11 5.1. Specification......................11 5.2. Data transfer via Bluetooth Under Batch mode ........... 12 5.3. SPP Communication..................... 12 5.3.1.
  • Page 3 9.2.5. Barcode Data and Scanner Setting ............51 9.2.6. Alpha-Numerical Setting barcode ............68 Appendix 1 ....................... 73 Appendix 2 ....................... 74 Appendix 3 ....................... 75 BlueTooth Scanner Setting Guide...

  • Page 4: Layout Descript

    1. Layout Descript Item Description Scan Window The widows of Scanner for read. Battery / Charging Battery Status Green On： ： ： ： Charging Finish Green Off： ： ： ： Battery Low Red On： ： ： ： Charging Red Off： ： ： ： Battery fail Scan LED Barcode Read status Green：...
  • Page 5 Green slow flash： ： ： ： Bluetooth is Connected ok USB Connect Status Green On： ： ： ： USB connected Green slow flash： ： ： ： Data is transferring Press and hold more then 3 seconds： ： ： ： Power On Scan Key Press：...

  • Page 6: Action Mode

    2. Action Mode This device have three action mode for Bluetooth SPP communication, the default action mode is real mode. The mode can be changed by scan setting barcode. But, the customer can not change the mode If the data file（data.txt）have some records not be send out . The description of mode, please see the follow table.

  • Page 7: Key Function Description

    3. Key Function Description The follow table descript the motion of the status and key function. Motion status Power Bath mode Real mode Hybrid mode Disconnect SPP Disconnect Scan Power Key( press — — — more then 3 seconds) Scan Key Bluetooth data transfer —...

  • Page 8: Led Display And Buzzer

    4. LED Display and Buzzer The following table is description of the LED display and sound on the different issue. Data collect status Scan LED Battery Bluetooth Sound User good scan Green (50ms) User bad Scan ( 5 Red( 300ms) Bi, Bi, Bi second time out) Configuration good...
  • Page 9 It is not found that Bu, Bu, Bu press Fn key to delete one record Under Batch mode. The record format of Red( 300ms) Bu, Bu, Bu data file on memory be changed Battery Charging Battery Charging fail Red Flash On：100 ms Off：100ms Battery Charging...
  • Page 10 transmit under Hybrid transmitting ) mode USB connected Blue On USB data transmit Quick Blue Flash Press Fn Key to wait Blue On 6 seconds while Bluetooth reconnect. Firmware Updating Orange Flash Firmware Update Orange finish Tone Bi： short、High tone Bi~ ：Long、High tone Bu：short、Low tone Bu~：Long、Low tone...

  • Page 11: Bluetooth Connect Description

    5. Bluetooth Connect Description 5.1. Specification This BT600 is a wireless interface device , it is follow Bluetooth ver2.1+EDI Class II specification, include the SPP( Serial Port Profile ) and HID( Human Interface Device Profile) on this device, It must install the same profile on the paring device (ex. iPhone, iPad or PC ) too for Bluetooth communication.

  • Page 12: Data Transfer Via Bluetooth Under Batch Mode

    5.2. Data transfer via Bluetooth Under Batch mode The customer can get the data that be saved under Batch mode by Bluetooth。 The BTS600 must change to Bluetooth data transfer mode, you can reference the「5.3 SPP communication」 Item Description How to transfer the Two method of transfer Press Key（Scan Key + Fn Key）...

  • Page 13: Host Command

    Port, So the host device must install and execute an application to handle the handshake with BTS600. The data format of SPP transfer of BTS600 as follow： [Prefix][Digit][Data][Checksum][Suffix] Item Byte Value Description Number Prefix STX(0x02) The start bit of SPP communication. Digit The size of Data Data...
  • Page 14 Start The start character of response after executed host command. Command 1 ~ 8 The response after execute host command number. Separation ， Response The result after execute host command YYMMDDHHMM The date & time of BTS600 for host command 3 The battery status of BTS600 for host command 4 *******...

  • Page 15: Hid Communication

    RE4,L< CRLF> device. F is Full power M is Middle power L is Low power. Send the scan !5<CRLF> None BTS600 will send all data file of records of the data.txt on BTS600 Memory to host device. Delete the scan !6<CRLF>...
  • Page 16 Nots： If you want the BTS600 be the key board interface of iPhone, iPad, Please set to“English”mode on the keyboard setting of iPad, iPhone first. If you does not set to “English”mode, it will display other character on iPhone, iPad after you use BTS600 scan a barcode data.

  • Page 17: Usb Connect

    6. USB connect 6.1. Specification This device（）have a USB port , it will support charge when you use USB cable to connect with and PC host. Specification description Communication USB 2.0 Full speed Spec USB Mass Storage support Cable Micro USB type B Charging DC5V Use an AC adapter for charge, Please use this machine...

  • Page 18: Usb Data Transfer Mode

    6.2. USB data transfer mode Under Batch mode, the scan data will be saved into the data.txt file of memory. User can obtain data.txt file that stored in memory of with USB thread. Specification Description Connect with PC： Transfer When the connect with PC via USB cable, the USB memory of will be a disk of PC.
  • Page 19 Use 2 digital of ASCII code Delimiter Separate mark Time stamp YYYY/MM/DD,hh:mm:ss Date & time The separate of data & time, It is same with Delimiter field. Delimiter Separate mark Data Scan data, If data length at the full 100 Bytes, will fill blank in order to mend all over 100bytes behind data...

  • Page 20: The Suitable Use Method

    7. The Suitable use method The user can follow the follow chart to select the best mode for use. BlueTooth Scanner Setting Guide...

  • Page 21: Simple Setting

    8. Simple Setting The use choice the best mode according【7. The Suitable use method】 8.1. Batch Mode setting If the user want scan the barcode data and be saved into the memory of , please use Batch Action mode. The user can get the record of memory on the by different method, according User setting.

  • Page 22: Data Transfer By Spp Slave Mode Situation

    Enter the Imput B001A physical address of BT module Communication Enter SPP A001B start Master mode Action mode Batch A014A2 setting mode Wait host Start data A033A command transfer under Bluetooth Bluetoot communication commun ication ※ please reference 【The Setting barcode about Bluetooth Device name of 】of 【9.2.1 System mode Setting】...

  • Page 23: Real Mode Setting Under Hid Communication

    Wait host Start data A033A command transfer under Bluetooth Bluetoot communication commun ication 8.2. Real mode setting under HID communication pairing with iPhone, iPad of Apple product or pairing with terminal host like Android smart phone、tablet、PC，and the is a keyboard interface of those terminal host, Please use Real mode under HID communication.

  • Page 24: Real Mode Setting Under Spp Communication

    8.3. Real mode setting under SPP communication If the customer want to raise the fault-tolerant of communication, the customer can choice the real mode and SPP communication mode. The real mode under SPP communication, it is virtual serial port data communication between and host device.

  • Page 25: Real Mode Setting Under Spp Slave Mode

    8.3.2. Real mode setting under Spp Slave mode Description Setting Setting Barcode Cord Communication A002A setting slave mode Action mode Real A014A1 setting mode 8.4. Hybrid mode setting under SPP communication Because out of the communication or other reason that the Bluetooth disconnect, in order to avoid the lost of data, the system will save the scan data into the data file of memory of on the Hybrid mode, so Hybrid mode have higher dependability the Real mode.

  • Page 26: Hybrid Mode Setting Under Spp Slave Mode

    Communication Enter A001B start Master mode Action mode Hybrid A014A3 setting mode 8.4.2. Hybrid mode setting under SPP Slave mode Description Setting Setting Barcode Cord Communication A002A setting slave mode Action mode Hybrid A014A3 setting mode BlueTooth Scanner Setting Guide...

  • Page 27: System Detail Setting

    9. System Detail Setting 9.1. Factory Default Setting Reader Factory Default setting as following tables. Item Default Action Mode Real Mode Communication Mode HID mode Device Name Reader+last 4 digital of BT MAC Address Disable Authentication Disable Encryption PIN Code “0000”...
  • Page 28 ※ On the Real mode、Batch mode the “ACK/NAK handling of SPP communication setting” can be set enable / disable, The Hybrid mode must enable can not change to disable。 The default value of Batch mode as follow table。 Those setting will not influence about Real mode initial. Item Default Time Stamp format...
  • Page 29 UPC-E1 preamble System UPC-E convert to UPC-A Disable UPC-E1 convert to UPC-A Disable EAN-8 convert to EAN-13 Disable UPC/EAN security level Level 3 UCC coupon expend code Disable Coupon Report Both Coupon ISS EAN Disable Code 128 Enable GS1-128 Enable ISBT-128 Enable ISBT- connect...

  • Page 30: The Setting Barcode Of System

    Disable MSI check digital MSI check digital transfer Disable MSI check digital algorithm MOD 10 /mod 10 GS1 Databar omnidirectional Enable GS1 DataBar Limited Enable GS1 DataBar Expanded Enable GS1 DataBar Disable 9.2. The setting Barcode of System Having recorded the establishment bar code that this machine uses as follows, this machine is dispatched from the factory the setting up value and please reference [9.1 Factory Default setting], the user can scan the following establishment barcode to change the setting of Reader.
  • Page 31 A002A Slave commu nication mode A014A A014A commu nication mode A003A ※ Please enter the physical address of BT module of the Host device first, when use SPP Master communication mode. Please reference【The Setting barcode about physical address of Bluetooth module】 Batch mode：...
  • Page 32 under A014A Master commun ication mode Data A002A transmis sion mode under A014A Slave commun ication mode Hybrid Mode： ： ： ： Descriptio Setting Setting Barcode Cord Hybrid A001B Mode Master Communi cation mode A014A SPP Slave A002A communic ation mode A014A BlueTooth Scanner Setting Guide...
  • Page 33 ※ Please enter the physical address of BT module of the Host device first, when use SPP Master communication mode. Please reference【The Setting barcode about physical address of Bluetooth module】 The Setting barcode about physical address of Bluetooth module The originally setting barcode for the Reader to set up SPP Master mode, then Reader can know and fast connect with host computer.
  • Page 34 Authentication Enable A008A Setting Disable A008B The Setting barcode of Bluetooth Encryption Description Setting Setting Barcode Cord ID Bluetooth Enable A009A Encryption setting Disable A009B The Setting barcode of PIN code The customer can enter 16 character for PIN code, you can and only enter 0~9, A~Z, a~z。 Please use barcode of 【9.2.6 Alpha-Numerical Setting barcode】to enter the PIN code。...
  • Page 35 Return default PIN code A017A setting The Setting Barcode of Power off time out Description Setting Setting Barcode Cord Power off A004A1 time out minutes setting. A004A2 minutes A004A3 minutes A004A4 minutes A004A5 minutes A004A6 minutes A004A7 minutes BlueTooth Scanner Setting Guide...
  • Page 36 A004A8 minutes The Setting Barcode of Beep on Reconnect/Disconnect Description Setting Setting Barcode Cord The Beep on Enable A005A reconnect / disconnect setting Disable A005B The Setting Barcode of Beep for bad scan Description Setting Setting Barcode Cord ID The Beep for Enable A006A bad scan...

  • Page 37: Hid Communication Setting

    A010A1 Middle A010A2 High A010A3 The Setting Barcode of restore Factory Default Setting Setting Barcode Cord ID Restore Factory default A012A setting 9.2.2. HID Communication Setting This is advanced establishment when Real mode under HID communicates。 HID termination character setting Description Setting Setting Barcode...
  • Page 38 is 『＃』 Please use barcode of 【9.2.6 Alpha-Numerical Setting barcode】to enter the additional characters。 HID termination character setting Description Setting Setting Barcode Cord ID Input B021A Normal Key setting additional Input B021B characters +Shift Key setting additional Input B021C characters +Alt setting additional Input...
  • Page 39 communicatio Enable A022B n setting The setting barcode for the association key code that will be sent while pushing Fn key Description Setting Setting Barcode Cord ID Normal Input B022A Function Key Code Setting under HID real mode setting Input B022B Function Key + Shift...
  • Page 40 None A023A0 The delay time before sending data of each record can be 100 ms A023A1 200 ms A023A2 300 ms A023A3 500 ms A023A4 The setting barcode delay time between characters under BT communication Description Setting Setting Barcode Cord ID none A024A0 The delay time...
  • Page 41 A024A3 Data Format Setting Under HID Communication Mode When CYCLOPS-II is in HID Mode. HID mode Header Character Setting Description Setting Setting Barcode Code ID HID Mode A115A Header Setting Barcode for Header Header setting must be 2-digit word and the word can only be 0~9 and A ~ F. For example, scan the barcode ID”B115B”...

  • Page 42: Spp Communication Setting

    HID mode Footer Character Setting Description Setting Setting Barcode Code ID HID Mode None A116A Footer Setting Barcode of Footer Footer setting must be 2-digit word and the word can only be 0~9 and A ~ F. For example, scan the barcode ID”B116B” first, then, “0”,”4”, and “EOC”. The footer set will be “A”.
  • Page 43 SPP Master None A007A0 reconnect time interval setting A007A1 A007A2 A007A3 A007A4 A007A5 A007A6 A007A7 A007A8 BlueTooth Scanner Setting Guide...
  • Page 44 The transfer data format setting under SPP communication When set up into Batch mode、 Hybrid mode, if still there are records to exist in Data.txt file in the memory of Reader, The follow settings that can not be changed。 The setting barcode of Prefix The prefix setting must 2 digital word, and the word can only 0~9, A ~ F.
  • Page 45 The setting barcode of Suffix The suffix setting must 2 digital word, and the word can only 0~9, A ~ F. For example, Scan the barcode Id「B019A」 first, then 「3」 、 「3」 、 「EOC」, Suffix is 『，』 Please use barcode of 【9.2.6 Alpha-Numerical Setting barcode】to enter the Suffix。 Description Setting Setting Barcode...
  • Page 46 200 ms A020C2 setting 300 ms A020C3 500 ms A020C4 A020C5 seconds A020C6 seconds A020C7 seconds A020C8 seconds The Setting barcode for retry cycle of ACK/NAK of SPP communication Description Setting Setting Barcode Cord ID None A020D0 Retry cycle of ACK /NAK of SPP communicati...

  • Page 47: Batch Mode Setting

    1 cycle A020D1 setting 2 cycles A020D2 3 cycles A020D3 The setting barcode for key code send when press Fn Key The Key code setting must 2 digital word, and the word can only 0~9, A ~ F. For example, Scan the barcode Id 「B019A」 first, then 「3」 、 「3」 、 「EOC」 , Key code is 『，』 Please use barcode of 【9.2.6 Alpha-Numerical Setting barcode】to enter the Key code。...
  • Page 48 Time stamp Disable A027A0 Setting (_____# ____) ※ _ is space Enable A027A1 (YYYY/ MM/DD# hh:mm:ss) ※ The “#” is a termination character, please reference 「Termination Character Setting」 on the following table Description Setting Setting Barcode Cord A028A1 Termination ； Character Setting Space...
  • Page 49 Space A026A2 A026A3 A026A4 CRLF A026A5 A026A6 The Setting barcode for RTC time clock Description Setting Setting Barcode Cord ID Read RTC Start A034A date Setting Year：please set up 4 digital，Pleas use AD. Month：please set up 2 digital。 Date：please set up 2 digital。 Please use barcode of 【9.2.6 Alpha-Numerical Setting barcode】to enter the Date。...
  • Page 50 Hour：please set up 2 digital。 Minutes：please set up 2 digital。 Please use barcode of 【9.2.6 Alpha-Numerical Setting barcode】to enter the Time。。 Description Setting Setting Barcode Cord ID Set RTC input B036A time setting The Setting Barcode about Bluetooth data transfer Description Setting Setting Barcode...

  • Page 51: Barcode Data And Scanner Setting

    Enable A030A Memory Initialization Setting After Data Disable A030B Transmission Setting The setting Barcode of Fn key Description Setting Setting Barcode Cord Enable A037A Func. Key Setting Disable A037B The setting barcode for USB memory initialization The data file will be deleted on the USB memory include Data.txt and system.cfg Description Setting Barcode Cord...
  • Page 52 Level A040A0 Trigger Mode Continuous A040A1 Level 1 A041A1 Linear Code Type Security Level Level 2 A041A2 Codabar Discrete2of5 Interleaved2of5 Level 3 A041A3 Level 4 A041A4 A098A0 Inverse 1D Regular Only A098A1 Inverse Barcode BlueTooth Scanner Setting Guide...
  • Page 53 Auto A098A2 Code ID None A112A0 AIM Code A112A1 Symbol A112A2 Code ID UPC-A Disable A042A0 Enable A042A1 UPE-E Disable A043A0 Enable A043A1 BlueTooth Scanner Setting Guide...
  • Page 54 UPE-E1 Disable A044A0 Enable A044A1 EAN-8 Disable A045A0 Enable A045A1 EAN-13 Disable A046A0 Enable A046A1 Bookland Disable A047A0 Enable A047A1 Bookland ISBN-10 A048A0 ISBN format BlueTooth Scanner Setting Guide...
  • Page 55 ISBN-13 A048A1 A049A0 Decode Ignore UPC/EAN supplemental Supplementals A049A1 Decode with supplemental A049A2 Autodiscrimin ate UPC/EAN supplemental A049A3 Enable smart supplemental mode A049A4 Enable 378/379 supplemental mode A049A5 Enable 978/979 supplemental mode A049A6 Enable 414/419/434/4 supplemental mode A049A7 Enable 977 supplemental mode BlueTooth Scanner Setting Guide...
  • Page 56 A049A8 Enable 491 supplemental mode UPC/EAN/J Separate A051A0 AN AIM Code ID format Combined A051A1 Separate A051A2 Transmissio UPC-A check Disable A052A0 Digital Transfer Enable A052A1 UPC-E check Disable A053A0 digital Transfer Enable A053A1 UPC-E1 Disable A054A0 check digital Transfer BlueTooth Scanner Setting Guide...
  • Page 57 Enable A054A1 UPC-A None A055A0 preamble System A055A1 Country A055A2 code UPC-E None A056A0 preamble System A056A1 Country A056A2 code UPC-E1 None A057A0 preamble System A057A1 BlueTooth Scanner Setting Guide...
  • Page 58 Country A057A2 code UPC-E Disable A058A0 convert to UPC-A Enable A058A1 UPC-E1 Disable A059A0 convert to UPC-A Enable A059A1 EAN-8 Disable A060A0 convert to EAN-13 Enable A060A1 UPC/EAN Level 0 A061A0 security level Level 1 A061A1 BlueTooth Scanner Setting Guide...
  • Page 59 Level 2 A061A2 Level 3 A061A3 UPC coupon Disable A062A0 extend code Enable A062A1 Coupon Old coupon A063A0 Report report New coupon A063A1 report Both A063A2 Coupon ISSN EAN Disable A064A0 Enable A064A1 BlueTooth Scanner Setting Guide...
  • Page 60 Code128 Disable A065A0 Enable A065A1 GS1-128 Disable A067A0 Enable A067A1 ISBT 128 Disable A068A0 Enable A068A1 Disable A069A0 ISBT Concatenation Enable A069A1 Auto A069A2 BlueTooth Scanner Setting Guide...
  • Page 61 Disable A070A0 Check ISBT Table Enable A070A1 Code 39 Disable A071A0 Enable A071A1 Disable A072A0 Trioptic Code Enable A072A1 Disable A073A0 Convert Code39 to Code32 Enable A073A1 Disable A074A0 Code32 Prefix BlueTooth Scanner Setting Guide...
  • Page 62 Enable A074A1 Disable A076A0 Code39 Check Digit Verification Enable A076A1 Disable A077A0 Transmit Code39 Check Digit Enable A077A1 Disable A078A0 Code39 Full ASCII Enable A078A1 Code 93 Disable A079A0 Enable A079A1 BlueTooth Scanner Setting Guide...
  • Page 63 Code 11 Disable A081A0 Enable A081A1 Disable A083A0 Code11 Check Digit Verification One Digital A083A1 Two Digital A083A2 Disable A084A0 Transmit Code11 Check Digit Enable A084A1 Disable A085A0 Interleaved 2 of Enable A085A1 BlueTooth Scanner Setting Guide...
  • Page 64 Disable A087A0 I 2 of 5 Check Digit Verification A087A1 USS check digit A087A2 OPCC check digit Disable A088A0 Transmit I 2 of 5 Check Digit Enable A088A1 Disable A089A0 Convert I 2 of 5 to EAN-13 Enable A089A1 Disable A090A0 Discrete 2 of 5 Enable...
  • Page 65 Disable A092A0 Chinese 2 of 5 Enable A092A1 Disable A093A0 Matrix 2 of 5 Enable A093A1 Disable A095A0 Matrix 2 of 5 Redundancy Enable A095A1 Disable A096A0 Matrix Check Digit Verification Enable A096A1 Disable A097A0 Transmit Matrix Check Digit BlueTooth Scanner Setting Guide...
  • Page 66 Enable A097A1 Disable A099A0 Codabar(NW7) Enable A099A1 Disable A101A0 CLSI Editing Enable A101A1 Disable A102A0 NOTIS Editing Enable A102A1 Disable A103A0 Enable A103A1 BlueTooth Scanner Setting Guide...
  • Page 67 Disable A105A0 MSI Check Digits Enable A105A1 Disable A106A0 Transmit MSI Check Digit Enable A106A1 Disable A107A0 MSI Check Digit Algorithm Enable A107A1 Disable A108A0 GS1-DataBar Enable A108A1 Disable A109A0 GS1 DataBar Limited BlueTooth Scanner Setting Guide...

  • Page 68: Alpha-Numerical Setting Barcode

    Enable A109A1 Disable A110A0 GS1 DataBar Expanded Enable A110A1 Disable A111A0 Convert GS1 DataBar to UPC/EAN Enable A111A1 9.2.6. Alpha-Numerical Setting barcode This item is for input of Alpha Numerical setting. Descript Setting Barcode Code ID Stop Input Cancel BlueTooth Scanner Setting Guide...
  • Page 69 Descript Setting Barcode Code ID Setting Barcode Code ID Numerical （ Include Hex） Descript Setting Barcode Code ID Setting Barcode Code ID BlueTooth Scanner Setting Guide...
  • Page 70 Alphabetic Letter BlueTooth Scanner Setting Guide...
  • Page 71 BlueTooth Scanner Setting Guide...
  • Page 72 BlueTooth Scanner Setting Guide...

  • Page 73: Appendix 1

    10. Appendix 1 How to make the setting Code The code type of Reader setting code is Code128 The customer can make the setting code of BT drive address and BT device name by yourself. How to make the setting barcode of Bluetooth Driver Address Start Code Setting ID Address ( Alpha numerical )

  • Page 74: Appendix 2

    11. Appendix 2 About Key Code Function Key code Setting will Function key is pressed during Real mode under HID connection, set up the key code when press Fn key on the Real mode under HID communication. The Kye code for terminal host ( Android , iPhone, iPad ) as follow Key Code(Hex) Normal +Shift...

  • Page 75: Appendix 3

    12. Appendix 3 USB HID Key Code Definition BlueTooth Scanner Setting Guide...
