BarCode Decode Setup Manual Directory Setup Flow Chart: ..........9 Part I System Information ........10 1.1 Reset to default: ........10 1.2 Firmware Version: ........10 Part II System Setting ........11 2.1 Interface: ..........11 Part III Keyboard wedge parameters ....12 3.1 Terminal Type: ........
Page 3
5.2.1 Buzzer Frequency: ........ 27 5.2.2 Duration ..........27 5.2.3 Power up Buzzer: ......... 28 5.2.4 Good Read Buzzer: ......28 5.3 String ............. 29 5.3.1 Prefix and Suffix: ........29 5.3.2 Insert Character Group (G1/G2): .... 30 5.3.3 Code Type Transmit: ......31 5.4 Barcode Inverse:...
Setup Flow Chart: Scan “Start Configuration” barcode “Start Configuration” Scan the barcode you like to change to change Reset to default Hex or ASCII Code Scan two HEX digits in Appendix A to represent one ASCII code. Scan “End” barcode Scan “End Configuration”...
Part I System Information Start Configuration 1.1 Reset to default: Reset to factory default settings. The default settings are shown with < > and bold. Reset to default 1.2 Firmware Version: Scan barcode to display firmware version. Firmware Version End Configuration...
Part III Keyboard wedge parameters 3.1 Terminal Type: Start Configuration < IBM AT > End Configuration 3.2 Language Selection: Start Configuration American Italian...
Page 13
Spanish France Germany Japanese End Configuration Note: Scan the barcode to select local keyboard language, if your keyboard language can't be found, please turn on ALT Mode which is an alternate way to find your language.
3.5 Caps Lock : < Disable > Enable 3.6 Numeric Key: < Disable > Enable End Configuration Note 1: ALT Mode can emulate most of local keyboard languages in Microsoft system. Note 2: The barcode reader can emulate to enable/disable Caps Lock key. Note 3: barcode reader...
3.10 Keyboard Wedge Terminator: None < CR > End Configuration Note: Keyboard Wedge Terminator is to set up the termination character of barcode reader output to adapt to applications.
4.6 Delay After Transmit: Enable (00H, 00-0AH*100msec) 4.7 Response Delay Time: Enable (00H, 00-0AH*100msec) End Configuration Note: Response Delay Time is the time of barcode reader waiting for host to response. The delay time=setting data*100(ms).
Page 23
STX/ETX End Configuration Note: RS232- Interface Terminator is to set up the termination character of barcode reader output to adapt to applications.
Part V System Setting: 5.1 Scan Mode: Start Configuration Trigger Mode < Auto Off Mode > Continuous/Trigger Off Mode Test Mode Continuous Mode Continuous/Timeout Off Mode...
Page 25
Flash Mode Continuous/No Trigger End Configuration Note: Trigger Mode: Press trigger to turn on scanner. To turn off the scanner, just release trigger or after barcode decoded. Auto off Mode: Press trigger to turn on scanner. Scanner will be a utomatically off when time out or after barcode decoded.
Page 26
Continuous Mode: Press trigger to activate continuous scan mode, scanner will keep scanning and decoding barcodes. If the same barcode is scanned, it will only decode once and the red LED is always on. Continuous (Timeout Off) Mode: Press trigger to activate test mode. Scanner will scan and decode barcodes continuously until trigger is pressed again.
5.3 String 5.3.1 Prefix and Suffix: Start Configuration Set up (00H) prefix Set up (00H) suffix End Configuration Note: The maximum characters can be set as prefix and suffix are 10 ASCII characters, if the setting is 0 means there is no prefix or suffix. Formats of prefix and suffix are as follows: Prefix Barcode...
5.3.2 Insert Character Group (G1/G2): Start Configuration Set G1 string (00H) Set G2 string (00H) The start position of G1 string (00H) barcode to insert The start position G2 string (00H) of barcode to insert End Configuration Note: Up to 10 ASCII codes can be inserted in a group.
“set G1string” barcode. Scan ASCII code barcode in appendix B. Scan “End Configuration” Repeat step 2 and step 3 if you wish to setup G2 Insert Character. Scan “End Configuration” Position to insert character: Choose a position to insert characters, when the setting is zero, non-zero characters will not be inserted.
End Configuration Note: To transmit Code Type, you have to enable Code Type Transmit. The format is Code Type ID + Barcode Data. 5.4 Barcode Inverse: If background is back, choose Bar = White. If background is white, choose Bar = Black. Start Configuration <...
Part VI Barcode Type Setting: Enable/Disable barcode : To enable/disable different barcode symbologies decoding, scan the Enable/Disable barcode. Code ID:Set to enable to transmit Code ID of barcode type. How to set Code ID: 1. Scan “Start Configuration”. 2. Scan “Code ID”. 3.
6.1.4 Transmit Check Digit: Disable < Enable > 6.1.5 Truncate Leading Zero: < Disable > Enable 6.1.6 Truncate Leading Digits: Set up leading digits(00H, 00-0DH)
6.2.5 Truncate Leading Zero: < Disable > Enable 6.2.6 Truncate leading digits: Set up leading digits(00H, 00-0DH) 6.2.7 Truncate Ending Digits: Set up ending digits(00H, 00-0DH)
6.4.2 Code ID Setting: Set up Code ID(49H, 20-7EH) 6.4.3 Transmit Check Digit: Disable < Enable > 6.4.4 Truncate Leading Digits: Set up leading digits(00H, 00-0DH) 6.4.5 Truncate Ending Digits: Set up ending digits(00H, 00-0DH)
6.5.6 Transmit Start/End Character: < Disable > Enable 6.5.7 Min Code Length: (defult:00) Set up min code length(00H, 00-32H) 6.5.8 Max Code Length: (default:32H) Set up max code length(00H, 00-32H) 6.5.9 Truncate Leading Digits: Set up leading digits(00H, 00-32H)
6.6.7 Start/End Transmit: < Disable > Enable 6.6.8 Min Code Length: (default:00) Set up Min Code Length(00H, 00-3CH) 6.6.9 Max Code Length: (default:32H) Set up Max Code Length(00H, 00-3CH) 6.6.10 Truncate Leading Digits: Set up Leading Digits(00H, 00-3CH)
6.7.4 Transmit Check Digit: < Disable > Enable 6.7.5 Min Code Length: (default:00) Set up min code length(00H, 00-50H) 6.7.6 Max Code Length: (default:32H) Set up max code length(00H, 00-50H) 6.7.6 Truncate Leading Digits: Set up leading digits(00H, 00-50H)
6.8.8 Min Code Length: (default:00) Set up Min Code Length(00H, 00-7FH) 6.8.9 Max Code Length: (default:32H) Set up Max Code Length(00H, 00-7FH) 6.8.10 Truncate Leading Digits: Set up Leading Digits(00H, 00-7FH) 6.8.11 Truncate Ending Digits: Set up Ending Digits(00H, 00-7FH)
6.9.2 Code ID Setting: Set up Code ID(4EH, 20-7EH) 6.9.3 Check Digit: < Disable > Enable 6.9.4 Transmit Check Digit: Disable < Enable > 6.9.5 Min Code Length: (default:00) Set up Min Code Length(00H, 00-50H)
6.9.6 Max Code Length: (default:32H) Set up Max Code Length(00H, 00-50H) 6.9.7 Truncate Leading Digits: Set up Leading Digits(00H, 00-50H) 6.9.8 Truncate Ending Digits: Set up ending digits(00H, 00-50H) 6.9.9 Insert Characters: < None >...
End Configuration 6.10 Industrial 2 of 5 6.10.1 Enable/Disable Industrial 2 of 5: Start Configuration < Disable > Enable 6.10.2 Code ID Setting: Set up Code ID(4FH, 20-7EH)
6.10.3 Check Digit: < Disable > Enable 6.10.4 Transmit Check Digit: Disable < Enable > 6.10.5 Min Code Length: (default: 00) Set up Min code length(00H, 00-32H) 6.10.6 Max Code Length: (default:32H) Set up Max code length(00H, 00-32H)
6.10.7 Truncate Leading Digits: Set up leading digits(00H, 00-32H) 6.10.8 Truncate ending digits: Set up Ending digits(00H, 00-32H) 6.10.9 Insert Characters: < None > End Configuration...
6.11.4 Transmit Check Digit: Disable < Enable > 6.11.5 Min Code Length: (default: 00) Set up Min Code Length(00H, 00-50H) 6.11.6 Max Code Length: (default:32H) Set up Max Code Length(00H, 00-50H) 6.11.6 Truncate Leading Digits: Set up Leading Digits(00H, 00-50H)
6.12.4 Transmit Check Digit: Disable < Enable > 6.12.5 Min Code Length: (default:00) Set up Min Code Length(00H, 00-3CH) 6.12.6 Max Code Length: (default:32H) Set up Max Code Length(00H, 00-3CH) 6.12.6 Truncate Leading Digits: Set up Leading Digits(00H, 00-3CH)
< Enable > 6.13.5 Truncate Leading Digits: Set up leading digits(00H, 00-0AH) 6.13.6 Truncate Ending Digits: Set up ending digits(00H, 00-0AH) 6.13.7 Insert Characters: < None >...
< Enable > 6.14.4 Transmit Check Digit < Disable > Enable 6.14.5 Min Code Length: (default:00) Set up Min Code Length(00H, 00-50H) 6.14.6 Max Code Length: (default:32H) Set up Max Code Length(00H, 00-50H)
6.14.7 Truncate Leading Digits Set up Leading Digits(00H, 00-50H) 6.14.8 Truncate Ending Digits Set up Ending Digits(00H, 00-50H) 6.14.9 Insert Characters < None > End Configuration...
(default:32H): Set up Max Code Length(00H, 00-32H) 6.16.7 Truncate Leading Digits Set up Leading Digits(00H, 00-0DH) 6.16.8 Truncate Ending Digits Set up ending digits(00H, 00-0DH) 6.16.9 Insert Characters < None >...
End Configuration 6.17 China Post Code 6.17.1 Enable/Disable China post: Start Configuration < Disable > Enable 6.17.2 Code ID Setting: Set up Code ID(51H, 20-7EH)
6.17.3 Check Digit: < Disable > Enable 6.17.4 Transmit Check Digit: Disable < Enable > 6.17.5 Min Code Length: (default:00) Set up min code length(00H, 00-50H) 6.17.6 Max Code Length: (default:32H) Set up max code length(00H, 00-50H)
6.17.7 Truncate Leading Digits: Set up leading digits(00H, 00-50H) 6.17.8 Truncate Ending Digits: Set up ending digits(00H, 00-50H) 6.17.9 Insert Characters: < None > End Configuration...
