Sun
Ultra
450 Product Notes
™
™
Sun Microsystems Computer Company
A Sun Microsystems, Inc. Business
901 San Antonio Road
Palo Alto, CA 94303-4900 USA
1 650 960-1300
fax 1 650 969-9131
Part No. 805-2321-14
Revision A, June 1998
Send comments about this document to: smcc-docs@sun.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sun Microsystems Ultra 450
Summary of Contents for Sun Microsystems Ultra 450
- Page 1 Ultra 450 Product Notes ™ ™ Sun Microsystems Computer Company A Sun Microsystems, Inc. Business 901 San Antonio Road Palo Alto, CA 94303-4900 USA 1 650 960-1300 fax 1 650 969-9131 Part No. 805-2321-14 Revision A, June 1998 Send comments about this document to: smcc-docs@sun.com...
- Page 2 Sun Microsystems, Inc. The OPEN LOOK and Sun™ Graphical User Interface was developed by Sun Microsystems, Inc. for its users and licensees. Sun acknowledges the pioneering efforts of Xerox in researching and developing the concept of visual or graphical user interfaces for the computer industry. Sun holds a non-exclusive license from Xerox to the Xerox Graphical User Interface, which license also covers Sun’s licensees who implement OPEN...
- Page 3 If there is any doubt about whether the system requires a second power supply, you are strongly urged to calculate the system’s total power requirements (see the Sun Ultra 450 Workstation Owner’s Guide) or to simply install a second power supply before adding additional internal components.
-
Page 4: System Software Requirements
Sun Ultra 450 Workstation Owner’s Guide concerning main logic board jumpers: The clock mode select jumper (J2701) is no longer used on Sun Ultra 450 systems. No shunt should be installed on jumper J2701. The main logic board is hardwired to provide the correct clock mode for UltraSPARC II CPU modules. - Page 5 PCI SCSI host bus adapters (HBAs) and the use of newer SPARCstorage™ MultiPack (SMP) units that may contain UltraSCSI (Fast-20) capable drives. The HBAs available on Sun Ultra 450 systems default to use UltraSCSI operation when UltraSCSI devices are present. However, SPARCstorage MultiPack units (both 6- and 12-drive versions) do not support UltraSCSI operation.
-
Page 6: Elite3D Graphics Card
Elite3D Graphics Card The Sun Ultra 450 workstation supports one or two Elite3D m6 graphics cards. To install or remove an Elite3D card, see the following sections of the Sun Ultra 450 Workstation Owner’s Guide: “How to Remove a UPA Graphics Card”—page 134 “How to Install a UPA Graphics Card”—page 136... - Page 7 SCSI Drive Data Cable The Sun Ultra 450 Workstation Owner’s Guide and ShowMe How Multimedia application incorrectly show how to install the SCSI drive data cable in the removable media assembly. Procedures documented in both show that the connectors at each end of the cable should be connected to the SCSI devices, and the two connectors in the middle of the cable should attach to the removable media backplane.
- Page 8 Product Notes. Attaching an Alphanumeric Terminal The illustration on page 24 of the Sun Ultra 450 Workstation Owner’s Guide incorrectly identifies the location of the serial port connector on the system’s back panel. The correct location is shown below.
- Page 9 Expansion Cabinet, be sure to remove the kick plate at the bottom rear of the cabinet. Removing the kick plate allows two Sun Ultra 450 workstations to fit inside the cabinet. For additional details, see the documentation supplied with the Sun Enterprise Expansion Cabinet.
- Page 10 Attach the other end to the ground screw on the Sun Ultra 450 workstation, as shown below. Be sure to tighten the ground screw completely to ensure a good connection.
- Page 11 Power Supply Memory Latch Function The Sun Ultra 450 power supply has a memory latch function that allows the power supply to “remember” its last power on/off state in response to a power outage or removal of the AC power cord.
- Page 12 Sun Ultra 450 Product Notes • June 1998...
