- Page 1 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com testo 400 - Universal IAQ instrument Short instructions...
-
Page 3: Table Of Contents
Rear view ......................8 Probe connections ....................9 Commissioning ..................9 Power supply / Battery ..................9 Turning the testo 400 on and off ............... 10 Display – user interface ..................11 Using the product ................12 Overview of main menu ( )................ -
Page 5: About This Document
About this document • The instruction manual is an integral part on the instrument. • Keep this documentation to hand so that you can refer to it when necessary. • Please read this instruction manual carefully and familiarize yourself with the product before use. -
Page 6: Data Protection
Data protection The testo 400 measuring instrument makes it possible to input and store personal data such as name, company, customer number, address, telephone number, e-mail address and website. Please be aware that your use of the functions offered here is entirely your own responsibility. -
Page 7: Product Description
Product description Front view 1 On/Off button 2 Display – user interface (see section 6.3) 3 USB interface/ 4 Probe connections (see section power connection 5.3) -
Page 8: Rear View
Rear view 1 Camera 2 Differential pressure measurement connections (+/- marking) 3 Magnets 4 Attachment point for carrying strap 5 USB interface/ power connection CAUTION Make sure the pressure tube does not pop off the connection socket. Risk of injury! - Ensure correct connection. -
Page 9: Probe Connections
Probe connections 1 Thermocouple probe type K 2 Connection for probes with connection (T1 and T2) TUC (Testo Universal Connector) connector (A and B) Commissioning Power supply / Battery The measuring instrument is supplied with a rechargeable battery. Fully charge the battery before use. If plugged in, the measuring instrument is automatically powered via the power supply. -
Page 10: Turning The Testo 400 On And Off
Turning the testo 400 on and off Current Action Function status Instrument off Press and hold down the Instrument is turned on button (> 3 sec) When the measuring instrument is started for the first time, the setup wizard guides you through the following setting parameters step by... -
Page 11: Display - User Interface
Display – user interface Open main menu Measurement time Display of calculated measurement results Number of connected probes Reading for each probe Can be controlled with different function keys Instrument status bar Configure measurement Edit reading display Further symbols on the user interface One level back Exit view Share report... -
Page 12: Using The Product
More information Display report Multiple selection Using the product Overview of main menu ( ) Menu Description Measuring List with various application-specific menus Customer Create, edit and delete customer and system information. Memory Call up, edit, send, export (different formats possible) and delete measurements that have been carried out. - Page 13 Menu Description Settings Instrument settings Language and country Date & Time Units Own company address WiFi Help & Information Aids Device Registration Device information (serial number, app version, firmware version, update information) Tutorial Instruction manual Startup wizard Additional Apps Additional applications Settings Camera Clock...
-
Page 14: Overview Of Measurement Types ( )
Overview of measurement types ( ) Measuring Basic view Volume flow - Duct Volume flow rate – grid measurement as per EN 12599 Volume flow – grid measurement as per ASHRAE 111 Volume flow - Outlet Volume flow - funnel Volume flow –... -
Page 15: Getting The Readings In 5 Steps
These changes are saved for the next measurement. Zero pressure sensor Once the testo 400 has been brought into the operating position for a (Zero pressure sensor) differential pressure measurement, the sensor should be zeroed against ambient air. - Page 16 Connect probe via cable or Bluetooth ® Place probe in the application. Start measurement and read off measuring values. Save and send readings...
-
Page 17: Software
Software The testo 400 has a USB port, via which the measuring instrument can be connected to the PC. Knowledge of Windows ® operating systems is required to work with the software. Purpose The testo DataControl software enhances the functionality of the testo 400 measuring instrument with lots of useful functions: •... -
Page 18: First Steps
• Screen with a resolution of at least 800 x 600 pixels First steps Installing the software/driver Insert the program CD into the CD-ROM drive of the computer. Download the program and unpack the zip file using a suitable compression tool. Launch the TestoDataControlPCsetup.exe file. -
Page 19: Using The Product
Using the product Overview Connection status of the 1 Main menu measuring instrument 2 Update notification 4 Multi-function bar 5 Display area Operation of the software is based on the same functional principle as the instrument firmware for the testo 400. -
Page 20: Synchronizing Data
Synchronizing data 1 Synchronization status 2 Display area The data can be synchronized selectively per customer or as a whole across all customers simultaneously. Technical data General Feature Value Probe connections - 2x type K thermocouple - 2x Testo Universal Connector (TUC) for connecting cable probes to the corresponding plug - 1x differential pressure... -
Page 21: Product-Specific Approvals
