Using Video Generator Manager

About VGM
Video Generator Manager (VGM) is a Windows-based application for creating and editing formats and
test sequences. As many as 132 formats and one test sequence can be stored in the generator.
VGM was originally created for use with Quantum Data 80x video generators. The 700-Series
generators support only some VGM features. For information about using VGM, see the VGM help file.
VGM Quick Tour
1.
Connect the generator to your computer using a null modem serial cable.
2.
Start VGM, and then select Generator > Connect.
3.
In the Select Port dialog box, select the Serial option, and then click OK.
The name of the connected generator is listed in the bottom half of the VGM window.
4.
Click the View Formats icon
click the format you want the generator to use.
5.
Click the
Image List icon to view the available images, and then double-click the image you
want the generator to use.
to view the formats available in the generator, and then double-
15
