Information
The SolidStep® 3.0 is a trailer entry step assembly that can be mounted to the side of any trailer, providing
an ease of entry, regardless of level ground. The suggested floor height range should be between 35-44" for
a four-step tread, 27-36" for a three-step tread, 22-28" for an economy two-step tread, 19-28" for a premium
two-step tread, and 17-22.5" for a one-step tread.
Safety
Failure to follow the instructions provided in this manual may result in death, serious injury, trailer
Always wear eye protection when performing service or maintenance to the trailer. Other safety
equipment to consider would be hearing protection, gloves and possibly a full face shield,
No repairs should be attempted by anyone other than a qualified professional. The deployment and
retraction of the step assembly can cause injury if proper precautions are not taken. The step
assembly was designed for an operational weight rating of 400 lbs.
Preparation
Resources Required
• 1 to 2 Persons, depending on task
• Cordless or electric drill or screw gun
• Appropriate drive bit
• Tape measure
1/2
• #10 - 1
" wood screws (wood floor)
1/2
• #10 - 1
" self-tapping screws (laminate floor)
Rev: 07.18.18
TABLE OF CONTENTS
damage or voiding of the component warranty.
depending on the nature of the service.
Moving parts can pinch, crush or cut. Keep clear and use caution.
Page 2
2
2
2
2
3
3
3
4
5
5
5
5
CCD-0001654
