- Page 1 ARC/TIG WELDER Model No. Arc/Tig135 PART NO: 6010790 OPERATING & MAINTENANCE INSTRUCTIONS 0612...
-
Page 2: Table Of Contents
Declarations of Conformity ............27 Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machine’s data plate. -
Page 3: List Of Equipment
LIST OF EQUIPMENT When unpacking, check for damage and /or omissions etc. Any found should be reported to your CLARKE dealer where the appliance was originally purchased. The AT135 Arc/Tig welder is delivered with the following components: 1 x Welding Inverter with Shoulder Strap... -
Page 4: Principles Of Operation
PRINCIPLES OF OPERATION The ARC/TIG welder, as its name suggests, is designed to be used for both Metal ARC, AND TIG welding. To accomplish this, two sets of welding leads are required, one for each method employed. ARC WELDING Shielded Metal Arc welding is by far the most widely used of the various arc welding processes. It employs the heat of the arc to melt the base metal and the tip of a consumable flux covered electrode. - Page 5 TIG WELDING TIG welding Is primarily a DC current process, but can also utilise AC, usually for very thin materials and when welding Aluminium or other non ferrous metals. It uses a non-consumable tungsten (or tungsten alloy) electrode, held in a torch. Shielding gas (100% Argon), is fed through the torch to protect;...
-
Page 6: General Safety Precautions
GENERAL SAFETY PRECAUTIONS WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked, or ignored, personal injury to the operator may result. - Page 7 Be aware that flying sparks or falling slag can pass through cracks, along pipes, through windows or doors, and through wall or floor openings, out of sight of the goggled operator. Sparks and slag can fly 10m. To prevent fires and explosion: keep equipment clean and operable, free of oil, grease, and (in electrical parts) of metallic particles that can cause short circuits.
-
Page 8: Emc In The Workplace
ELECTROMAGNETIC INTERFERENCE (EMC) IN THE WORKPLACE Whilst this unit complies with EMC regulations, the user is responsible for installing and using the welding equipment according to the manufacturers instructions. If electromagnetic disturbances are detected then it shall be the responsibility of the user of the welding equipment to resolve the situation. -
Page 9: Welding Cables
power source so that good electrical contact is maintained between the conduit and the welding power source enclosure. 2.2 Maintenance of the welding equipment The welding equipment should be routinely maintained according to the manufacturer’s recommendations. All access and service doors and covers should be closed and properly fastened when the welding equipment is in operation. -
Page 10: Safe Operation Of Electric Arc Welders
SAFE OPERATION OF ELECTRIC ARC (MIG, TIG) WELDERS Comply with precautions above and this section. Arc welding, properly done, is a safe process, but a careless operator invites trouble. The equipment carries high currents at significant voltages. The arc is very bright and hot. Sparks fly, fumes rise, ultraviolet and infrared energy radiates, workpieces are hot. - Page 11 Fire & Explosion Prevention Do not exceed the equipment’s rated capacity or overload the arc welding equipment. It may overheat cables and cause a fire. Loose cable connections may overheat or flash and cause a fire. Never strike an arc on a cylinder or other pressure vessel. It creates a brittle area that can cause a rupture or lead to such a rupture later under rough handling.
-
Page 12: Safety Devices
Cables Frequently inspect cables for wear, cracks and damage. IMMEDIATELY REPLACE those with excessively worn or damaged insulation to avoid possibly lethal shock from bared cable. Cables with damaged areas may be taped to give resistance equivalent to original cable. Keep cable dry, free of oil and grease, and protected from hot metal and sparks. - Page 13 NEVER attempt any electrical or mechanical repair unless your are a qualified technician. If you have a problem with the machine contact your local CLARKE dealer. NEVER use or store in a wet/damp environment. DO NOT EXPOSE TO RAIN.
-
Page 14: Preparation Of The Welding Area
Avoid welding by contact with humid parts nearby combustible liquids. Least of all, do not weld upon tanks which may contain inflammable residuals. SAFETY EQUIPMENT A comprehensive range of CLARKE safety equipment for use when welding is available from your local CLARKE dealer. ELECTRICAL CONNECTIONS WARNING! THIS APPLIANCE MUST BE EARTHED. -
Page 15: Features Of The Arc/Tig135
FEATURES OF THE ARC/TIG 135 WELDER The ARC/TIG 135 welder has been designed to work with unstable input voltages. The use of power components and of electrolytic capacitors with higher voltage and a special control circuit grant a high welding current stability in spite of the mains voltage fluctuations. - Page 16 ELECTRICAL SYMBOLS DISPLAYED ON THE MACHINE The full technical specification for your inverter is to be found printed in a rating plate on the back panel or underside of the ARC/TIG 135 machine. The meaning of the markings and symbols shown are explained as follows.
-
Page 17: The Arc/Tig135 Components
THE ARC/TIG 135 COMPONENTS ON/OFF Switch Adjusting weld current potentiometer Green LED indicating power ON LED ON = Power ON, when switching the unit on, it illuminates a short while after the orange LED. Flashing LED = indicates an alarm condition due to an anomaly in the input voltage. During the green LED flashing time, the unit checks the line voltage untill it reaches an acceptable value. -
Page 18: Welding Techniques
WELDING TECHNIQUES ARC WELDING Arc welding cables are supplied with this machine. The kit comprises all necessary cables, plus a hand shield and wire brush with chipping pick. To prepare the unit for ARC welding, it is important that you follow the procedure below. With the ON/OFF switch, located on the rear panel, in the OFF position, connect the welding leads as follows:... - Page 19 Note: If the machine stops at any time and the amber light comes ON the thermal overload has intervened. The most difficult aspect of the arc welding process, particularly for beginners, is that of striking an arc. We strongly recommend that you practice on some pieces of scrap metal to get the feel of the operation, before you start on an actual welding job.
- Page 20 TIG WELDING To prepare the unit for TIG welding, it is important that you adopt the following procedure. Plug the work return lead (earth clamp) in to the +ve terminal, and secure the work clamp tothe workpiece. For good contact, the work clamp must be attached to clean bare metal. Clean with a wire brush where necessary.
- Page 21 Scratch the tip of the electrode on soon as an arc develops, quickly withdraw the electrode to maintain a gap of approx 3-4 mm, and proceed to weld. (See notes below). To stop welding, simply remove the torch from the workpiece. This method is referred to as ‘Scratch Arc’.
-
Page 22: Troubleshooting
TROUBLESHOOTING h t i . t n l i c t a l . r e y t i . t r . d l i d l . t n y t r , l i , t n , t s i d l l a i... -
Page 23: Maintenance
MAINTENANCE The ARC/TIG Inverter, requires very little maintenance other than the guidelines shown below. Under normal working conditions removing the covers and cleaning with dry compressed air at reduced pressure once a year will be quite sufficient. Cleaning at more frequent intervals is advisable however, if the unit is operating in a dusty and dirty environment. -
Page 24: Parts Lists & Diagrams
PARTS DIAGRAM... - Page 25 Additional accessories and consumables are available from your CLARKE dealer. For parts & Servicing, please contact your nearest dealer, or CLARKE International, on one of the following numbers. PARTS & SERVICE TEL: 020 8988 7400 PARTS &...
- Page 26 WIRING DIAGRAM...
-
Page 27: Declarations Of Conformity
The CE mark was first applied in: 2007 Product Description: Arc/Tig Welder Model number(s): Arc /Tig 135 Serial / batch Number: Current Manufacture. 01/05/2008 Date of Issue: Signed A.C. AIKEN Senior Manager Clarke International. ARC-TIG135-RV1.doc Page 1 of 1...
