MENU Dispaly (Note: Version for up to V3.8)
No.
1
Adjustment Forward
2
Adjustment Reverse
3
Adjustment Time Base
4 LCD DIM (Back Light Time)
5
* Supplier, the product will add functionality without having to give notice
• Set & Save:
1. Press MENU [Blue button]
2. Press F1 [Red button)(Select 1-5 Funtion)
3. Press [Blue button] ( - ), [Yellow button] (+)
4. Press the [Red button ]for 2 seconds
5. Press the [Blue button] to SAVE and EXIT

• How to check the S.W.R. of your Antenna :

Connect to "TX" on Radio output and Antenna to "ANT". Proper adaptor/cable is required if your device has
different type of connectors.
1. Measurement V.S.W.R. : (see Pic.1)
2. SW-102 TX connect Radio RF out
3. Radio TX , SW-102 with display S.W.R. measure data.
Do not affect the test in the following cases, there are objects nearby, placed horizontally.

• How to check the output Watt of your transceiver :

Connect to "TX" on Radio output and dummy Load to "ANT". Proper adaptor/cable is required if your device has
different type of connectors.
1. Measurement Power: (see Pic.2)
2. SW-102 TX connect Radio RF out
3. SW-102 ANT connect 50 ohm Dummy Load
4. Push Radio TX , SW-102 display is Power measure data.
(SW-102 is not for DMR system)

Package Contents

• 1x SURECOM SW-102-UV Power & SWR Meter (SO239 - connector)
• 1x Power PSU 100-240V
• 1x Charger Cable
1x English Users Manual
OLD VERSION : V3.8 ,V4.5,V4.9 ,V5.0,V5.1
Mode
POWER OFF
Adj
Default Setting
-99 to +99
0
-99 to +99
0
-99 to +99
0
0-9
1
0-9
3
Content
Fine Tune Level %
Fine Tune Level %
Frequency Counter ,OSC Time Base
"0" is always on, 1 min to 9 mins
"0" is always on, 1 min to 9 mins
