Surecom SW-102-UV Quick Start Manual

SW-102-UV Digital VHF/UHF Power & SWR Meter & Frequency counter

V.S.W.R. meter Introduction

VSWR. Forward and reflected power direct digital readout, without any calibration.
Maximum measurable power range up to 120W.
low insertion loss (0.3 decibels or less) structure allows it to be permanently connected.
Build in Frequency counter .
All Funtion display ( Frequency,Power , SWR,FW,RW,Battery Level)
Feature & Specification
Frequency range: 125 - 525MHz
Measurable power range: 0.5 - 120W(+-0.5%)
Input read frequency counter (must be < 0.5 W)
Maximum power: 120W
Impedance: 50Ω
Size: W 76 X H 77 X D35 mm.
Weight: < 220 grams
Battery : 3.7V Li-ion Rechargeable Battery
* Not for the DMR digital radio.
Interface: SO239
MAX. Power in
V.S.W.R
Frequency Ranger
Insertion Loss
Temperature
Frequency counter
Battery Display
Battery Build-in
Auto Power Off
Size
Charger in
Backlight
Interface (in and out ) SO239
Weight
• Power ON/OFF:
Press 2 second the [Red button] to power on or power off
120 W (Measurable power,Radio must
be ANALOG)
1.00~19.9
COVER : 125MHz~525MHz
< 0.15dB(VHF) , < 0.25dB(UHF)
0 ~60 ℃ ℃
Yes ( TX input must be minimum 0.5W + - 0.5%)
Yes
3.7V Li-ion Battery
1-9 mins
66*68*37 (mm)
5V (micro usb)
AUTO OFF
220g (include battery)
