Vertex High Frequency Converter ® Release 2.0 User Guide...
Page 2
Spirent Communications. The information in this document is believed to be accurate and reliable; however, Spirent Communications assumes no responsibility or liability for any errors or inaccuracies that may appear in the document.
Vertex High Frequency Converter Release 2.0 – User Guide Safety Summary If the equipment is used in a manner not specified by the manufacturer the protection provided by the equipment may be impaired. Safety Symbols The following safety symbols are used throughout this manual and may be found on the instrument.
Page 4
Vertex High Frequency Converter Release 2.0 – User Guide Résumé des règles de sécurité Si le matériel est utilisé d’une façon non conforme aux spécifications du constructeur, la protection assurée par le matériel peut être mise en défaut. Symboles de sécurité...
Cleaning ......................15 Replacing the Fuse ................16 Overview ......................16 Procedure ......................16 Remplacement du Fusible du Vertex HFC Fuse ..........18 Technical Specifications ..............19 Overview ......................19 4-Channel Vertex HFC ..................19 20-Channel Vertex HFC ..................20 Interface and Environment Characteristics ............
Page 6
Vertex High Frequency Converter Release 2.0 – User Guide Environnement d'Exploitation..............22 Dimensions et Poids ................22 www.spirent.com...
High Frequency Converter (Vertex HFC) extends the Vertex channel emulator frequency range from radio frequency (RF) band to higher millimeter wave frequency (mmW) band for 5G applications. Vertex HFC converts the signal between RF <6GHz and mmW frequency. Two models of the Vertex HFC are available: •...
Release 2.0 – User Guide Vertex HFC Diagram There is mixer on each conversion link in Vertex HFC. The RF frequency signal is mixed with the signal from internal LO or external LO and then converted to mmW frequency. The signal from mmW frequency is also converted to RF frequency with the same LO.
This section describes the front panel connectors and rear panel connectors on both models of Vertex HFC. 4-Channel Vertex HFC Connectors The 4-channel Vertex HFC provides the following connectors on the front panel: • mmW I/O ports (4 ports) – Connects to mmW frequency devices RF I/O ports (4 ports) –...
Vertex High Frequency Converter Release 2.0 – User Guide 20-Channel Vertex HFC Connectors The 20-channel Vertex HFC provides the following connectors on the front panel: mmW I/O ports (20 ports) – Connects to mmW frequency devices • RF I/O ports (24 ports) – Connects to RF frequency devices •...
Rack-Mount Configuration You can install Vertex HFC in a rack with a Vertex channel emulator and other equipment. The instructions for cabling and connecting Vertex HFC are provided in the Spirent Vertex ®...
Vertex High Frequency Converter Release 2.0 – User Guide Ventilation For proper ventilation, ensure that the rack is located in an area with the following conditions: A minimum of 18 inches of space between the sides of the rack and any objects •...
Vertex High Frequency Converter Release 2.0 – User Guide How to Contact Us To obtain technical support for any Spirent Communications product, please contact our Support Services department using any of the following methods: Americas E-mail: support@spirent.com Web: http://support.spirent.com Toll Free: +1 800-SPIRENT (+1 800-774-7368) (North America)
Vertex High Frequency Converter Release 2.0 – User Guide Access the Latest Documentation The following table lists the documentation related to Vertex HFC Release 2.0. You can access these documents from the Spirent Customer Service Center website: http://support.spirent.com. Document Part Number ®...
2. Care and Maintenance Cleaning Cleaning Vertex HFC is typically not required. However, for good RF performance, it is important to keep the RF connectors on the front and rear panels free of dust and debris. Also, for proper internal airflow, ensure that the fan vent on the rear panel is clear of debris and not blocked by an object.
Disconnect the power cord before replacing fuses. Perform the following steps to replace fuses in Vertex HFC: 1. Unplug the Vertex HFC power cord from the wall outlet, or unplug the power cord from the receptacle on the rear panel of Vertex HFC.
Page 17
8. Proceed with normal power up. NOTE: If the fuses blow again, disconnect the power cord, and do not use Vertex HFC. Contact Spirent Global Services at http://support.spirent.com. See “How to Contact Us” on page 13 for more information about contacting Spirent Global Services.
Débrancher le cordon d'alimentation avant de remplacer les fusibles. Procédez comme suit pour remplacer les fusibles: 1. Débranchez le cordon d'alimentation du Vertex HFC de la prise murale, ou débranchez le cordon d'alimentation de la prise électrique sur le panneau arrière du Vertex HFC.
Release 2.0 – User Guide 4. Technical Specifications Overview This section provides the technical specifications for Vertex HFC. NOTE: All technical specifications are typical and subject to change without notice. Unless otherwise indicated, the specifications are measured at room temperature, and the instrument has been booted up for more than 30 minutes.
Vertex High Frequency Converter Release 2.0 – User Guide Les Indicateurs du Panneau Avant Power 1 LED verte Status 1 LED verte Exigences en Matière d'Alimentation La Tension 100-240 VAC (Détection automatique de la) Fréquence 50-60 Hz Puissance 110 VAC Quatre canaux 0.3A, 20 Watts (Max)
